snom 300

VoIP Business Phone
© 2006 snom technology AG
All rights reserved.
Version 1.00
Quick Installation
Kurzanleitung
www.snom.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 300 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Snom 300

Summary of Contents for Snom 300

  • Page 1: Snom 300

    300 VoIP Business Phone Quick Installation Kurzanleitung © 2006 snom technology AG All rights reserved. www.snom.com Version 1.00...

  • Page 2: Note To The Reader

    Gradestr. 46 12347 Berlin, Germany Note to the reader This is a quick guide to the installation and operation of the snom 300. The full manual is available on our web page, www.snom.com/wiki. © 2006 snom technology Aktiengesellschaft. All Rights Reserved. This document is supplied by snom technology AG. No...

  • Page 3: Table Of Contents

    Setting the Netmask ..............18 Setting the IP Gateway .............. 18 Setting the DNS Server ............. 19 Selecting the Tone Scheme ............19 Selecting the Timezone ............. 19 Logging on the fi rst account ............20 Index ...............23 snom technology AG • 3...
  • Page 4 4 •...

  • Page 5: Installation

    They are crucial for the safe and reliable operation of the device. Power supply The snom 300 is powered by the external 5-V power supply included in the package. Other power supplies may cause damage to the phone, affect its behavior or induce noise.

  • Page 6: Setting Up The Phone

    N S T A L L A T I O N Setting up the Phone Your snom 300 is delivered with the footstand (shaded light gray in Fig. 1) attached to the phone’s bottom shell in the position for desktop placement. Place the snom 300 on an even, horizontal surface that gives the rubber pads a secure grip.

  • Page 7: Wall Mounting

    N S T A L L A T I O N Wall Mounting It is also possible to mount the snom 300 on the wall. In order to do this, detach the footstand from the bottom shell and attach it in the appropriate position for wall mounting, as described in steps 1 through 4, below.
  • Page 8 3 0 0 Q V 1 . 0 0 ] S N O M U I C K N S T A L L A T I O N Rotate the footstand 180° around its vertical axis. Insert the outside, rear snap-fi ts into the mounting holes on the bottom shell (Fig.

  • Page 9: Cleaning

    Fig. 6. Fig. 5 Fig. 6 Cleaning To clean the snom 300, use an anti-static cloth. Please avoid cleaning liquids as they might damage the surface or the internal electronics of the phone. snom technology AG • 9...
  • Page 10 3 0 0 Q V 1 . 0 0 ] S N O M U I C K N S T A L L A T I O N 10 • Installation...

  • Page 11: Connecting The Phone

    Fig. 7 shows the connected phone with the footstand attached in the position for desktop placement. Fig. 8 shows the connected phone with the footstand attached in the position for wall mounting. Fig. 7 Fig. 8 snom technology AG • 11...
  • Page 12 3 0 0 Q V 1 . 0 0 ] S N O M U I C K N S T A L L A T I O N 12 • Connecting the phone...

  • Page 13: Keypad

    ENTER key - to confi rm actions, selections and inputs CANCEL key - to cancel actions or input LED for MWI (message waiting indication) Adjusts the volume (lower/higher) Turns the casing speaker on/off snom technology AG • 13...
  • Page 14 3 0 0 Q V 1 . 0 0 ] S N O M U I C K N S T A L L A T I O N The numeric keypad with the keys 0 to 9, *, and # is used to enter digits and letters.
  • Page 15 TRANSFER key. Blind transfer: With the caller on the line, press the TRANSFER key, then dial the phone number the call is to be transferred to and press Mute microphone (on/off) snom technology AG • 15...
  • Page 16 3 0 0 Q V 1 . 0 0 ] S N O M U I C K N S T A L L A T I O N 16 • Keypad...

  • Page 17: Initialization

    (Netmask, IP gateway, DNS server) from the DHCP server. If your network does not support DHCP, press when the above screen appears. The user will subsequently be asked for the following settings: snom technology AG • 17...

  • Page 18: Setting The Ip Address

    3 0 0 Q V 1 . 0 0 ] S N O M U I C K N S T A L L A T I O N Setting the IP Address The user can provide a static IP address for the phone if DHCP is not used.

  • Page 19: Setting The Dns Server

    If the settings explained above are set up properly, the phone will ask for the fi rst account registration. snom technology AG • 19...

  • Page 20: Logging On The Fi Rst Account

    3 0 0 Q V 1 . 0 0 ] S N O M U I C K N S T A L L A T I O N Logging on the fi rst account If no number is assigned to the phone yet, you will be prompted to type in your account name.
  • Page 21 If, however, the letters „NR“ are shown instead, the registration has not been successful. When the time server has been successfully contacted, the time is also shown on the display. The complete manual is available on our web page, www.snom.com/wiki. snom technology AG • 21...
  • Page 22 3 0 0 Q V 1 . 0 0 ] S N O M U I C K N S T A L L A T I O N 22 • Initialization...

  • Page 23: Index

    Cleaning 9 Connecting the phone 11 Keypad 13 DHCP 17 Language 17 DNS Server 19 LEDs 15 LED for MWI 13 ENTER key 13 Manual 21 Mute microphone 15 Forwarding. Transfer Netmask 18 Numeric block 14 snom technology AG • 23...
  • Page 24 Copyright © 2006 snom technology AG. All rights reserved. snom is a registered trademark of snom technology AG and affi liates in Germany, U.S.A. and certain other countries. Other trademarks or registered trademarks mentioned in this document are the property of their respective manufacturers or owners.
