P2R Receiver; Psm200 Channel Frequencies - Shure PSM200 User Manual

P2T Audio Input
Connector Type:
Configuration:
Actual Impedance:
Nominal Input Level:
Maximum Input Level:
Pin Assignments:
Phantom Power Protection?

P2R Receiver

RF Sensitivity
–109dBm typical
Squelch Threshold
–102dBm typical
Antenna
Attached Whip
Audio Input Connector
Connector Type:
Impedance:
Maximum Input Level:
Frequency Response:

PSM200 Channel Frequencies

The PSM200 is available in four frequency groups,each coordinated to work in a specific geographic region.You can find the fre-
quency group for your system printed on the rear panel of the P2T TransMixer. For more information on which frequencies can be
used in your area, call our Applications Group at 847-866-2525, Shure Europe at 49-1731-72140, Shure Asia at 852-2893-4290, or
visit theTechnical Support section at www.shure.com.
CHANNEL
1
2
3
4
5
6
7
8
Channel A (P2R Only)
XLR/1/4-inch combo
electronically balanced
1 kΩ
–25 dBu @ 1/2 volume
(12 o'clock)
–5 dBu @ 1/2 volume
(12 o'clock)
XLR:2=hot; 3=cold, 1=ground
1/4:Tip = hot, Ring = cold,
Sleeve=ground
Yes:Up to 52 Vdc
1/4-inch Mono
1 MΩ
LO=+0 dBu
HI = –10 dBu
30 Hz to 20k Hz (+/–3dB);
earphone dependent
H2
(518-554) MHz
North America, Europe
518.750
524.875
525.625
534.375
536.875
538.500
551.000
553.250
ENGLISH
P2T Audio Outputs
Passive connection parallel with input.
Connector Type:
Configuration:
Pin Assignments:
Phantom Power Protection?
Power Requirements
Operating voltage 12-18 Vdc
Supplied with one of the following external power supplies:
• Model PS21: 120 VAC, 60Hz input.
• Model PS21E, Model PS21UK: 230 VAC, 50/60Hz input.
• Model PS21AR: 220 VAC, 50Hz input.
Power Requirements
9 V alkaline battery, recommended
Battery Life
Volume Dependent
Wired (RF Off):
Wireless (RF On):
Audio Output Connector
1/8 inch (3.5mm)
Minimum Load Impedance
8Ω
Net Weight
100 g (3.52oz.), less battery
Overall Dimensions
122 mm x 73 mm x 32 mm
(4.809 in.x2.875 in.x1.251in.)
R8
(800-814) MHz (748-784) MHz
Europe France, Australia
801.100
802.325
805.050
808.600
810.550
811.600
813.300
813.800
Wired Mode (RF Disabled)
13
XLR
electronically balanced
2= hot ; 3 = cold, 1 = ground
Yes: Up to 52 Vdc
6 Hours
4 hours
Q3
(842-865) MHz
England
749.100 855.275
754.025 856.175
756.000 857.625
765.900 858.200
765.900 863.075
775.000 863.625
778.775 864.425
781.900 864.850
S5
