ULX System Components

All systems include either a ULXS4
Standard Diversity Receiver or ULXP4
Professional Diversity Receiver.
Guitar systems include a 1/4" to mini 4-pin cable.
Antennas
ULXP4, ULXS4
2
Bodypack systems include a choice of lavalier,
headworn, or instrument microphones.
WH30, WCM16, WBH53/54
WB98H/C
WL93, WL183/184/185,
WL50/51
WA302
Active Antennas
The antenna connectors on the ULX receiver provide 12 Vdc for active circuit antennas.
Caution: Use only Shure antenna accessories to ensure the best operation. Do not use split-
ters, combiners, or antennas that provide a DC ground, as this can cause the receiver to func-
tion improperly.
Handheld systems include
a choice of interchangeable
microphone heads.
SM58, SM86, SM87A,
Beta 58, Beta 87C
ULXP4 receivers include rack-mounting hardware.
UA507
UA506
1/2 RACK MOUNT HARDWARE
FULL RACK MOUNT HARDWARE
