Aiphone IS SERIES Local System Setting Manual page 5

Title Sub title
System setting Advanced station
settings
Item
Video door
station/Audio
door station/
Room sub
station
Master station Stations to be scan monitored
Central
control unit
Sub item
Call priority Normal/Priority/Urgent
Called stations (Set up to 20 master stations from the
registered ones.)
Contact type Normally open (NO)
/Normally closed (NC)
Call priority/Answering Answering the page
the page /Call (Normal/Priority/Urgent)
Transmit volume boost ON/OFF
at PTT (ON: approx. +6dB up)
Camera zoom image 0 (wide)/1/2/3/4/5/6/7/8/9 (zoom)
preset (video door
stations only)
Call acknowledge tone ON/OFF
on/off
Backlight adjustment Exposure +/Exposure -
(video door stations
only)
Speaker Built-in speaker
(room sub stations only) /External speaker
(Select up to 20 sub stations from the
registered ones.)
Master station function: ON/OFF
paging, chime, monitor,
door release, and
remote site call
(Contact input) S1 to S4
Contact type Normally open (NO)
/Normally closed (NC)
Trigger condition None/Broadcast chime/Stop chime
Sound source Internal sound source (Select a
(Only when "Broadcast sound fi le or sequence name from the
chime" is selected at registered ones in the list.)
"Trigger condition") /External sound source (Select either
External sound source 1 or 2.)
Chime priority Normal/Priority/Urgent
(Only when "Broadcast
chime" is selected for
"Trigger condition")
Zone name (Select from the registered ones.)
(Only when "Broadcast
chime" is selected at
"Trigger condition")
(Contact output terminal) L1 to L8
Contact type Normally open (NO)
/Normally closed (NC)
Trigger condition None/Calling notice/Door release
/External sound source/PA output
Calling notice Normal: OFF/ON
(Only when "Calling Priority: OFF/ON
notice" is selected at Urgent: OFF/ON
"Trigger condition")
Door release (Select from the sub stations registered
(Only when "Door and set for the central control unit.)
release" is selected at
"Trigger condition")
External sound source External sound source 1
(Only when "External /External sound source 2
sound source" is
selected at "Trigger
condition")
PA output PA output 1 to 4
(Only when "PA output"
is selected at "Trigger
condition")
Setting range
Normal
-
Normally open
(NO)
Normal
OFF
5 (Center)
ON
Exposure +
Built-in
speaker
-
ON
S1
Normally open
(NO)
None
-
Normal
-
L1
Normally open
(NO)
None
Normal: OFF
Priority: OFF
Urgent: OFF
-
-
-
Default
5
