K
Settings on [Weekly schedule] setting window
1)
Select either [Every week] or [Every other week].
2)
Set the schedule start and end dates.
*
The monthly calendar is displayed by clicking
Refer calendar and you can select the start and
end dates.
If necessary, you can change the month by clicking
*
or
.
3)
Set one of the registered daily transfer schedules or no
schedule to each day of the week. (Select one from the
pull-down menu.)
L
Settings on [Individual schedule] setting window
Set an individual schedule to the target date.
[Individual schedule] setting window will not open if you
*
have not selected the target date on the calendar in the
[Transfer schedule setting] window.
1)
If necessary, you can change the date by clicking
repeatedly.
2)
[Daily transfer schedule]:
Select either of the registered daily schedules (DT1 or
DT2) or no schedule from the pull-down menu.
3)
[Call transfer time]:
When "DT1" or "DT2" is selected:
The call transfer time is automatically entered.
If necessary, change the [Start time (hour and
minute)] and [End time (hour and minute)] of
transferring manually.
When no schedule is selected:
Enter the call transfer time manually.
When the time is entered or changed manually, [Daily
*
transfer schedule] changes to "Individual schedule".

Setting the timer [Timer setting]

Set the time for each operation.
1
Click
Timer setting in the table of contents.
2
Set the time for the following operations respectively.
The setting range is displayed on the right side of each
*
input box.
[Call]:
Set the duration of call from door stations and room sub
stations to [Normal], [Priority] or [Urgent].
[Communication In Local]:
Set the duration of communication between stations.
or
[Paging]:
Set the duration of paging.
[Monitor]:
Set the duration of monitoring only one station.
[Scan monitor: Switching]:
Set the duration of monitoring each station while scan-
monitoring.
[Contact output]:
Set the duration of chime from the external sound source
1 and 2, triggered by contact output of the central control
unit (IS-CCU).
[Door release]:
Set the duration of door release.
If you set the time to "0", the door is released while
*
the door release button on the master station is held
down.
3
Click
Temporarily stored
results temporarily.
If you wish to cancel the setting results you have made,
*
click a title in the table of contents or "Refresh" in the
web browser menu.
to save the current setting
21
