Network Settings Page - NEC SuperScript 4200 Network Manual

N S
ETWORK ETTINGS
Each time you turn on the networked printer, it prints a
Network Settings page. The Network Settings page provides
information about the network printer settings and network
connections. You should review this page immediately after
NIC installation and any time you change the configuration
to verify that the procedure was done properly.
In the illustration at the right, important features are circled.
The Print Server Name. (which is also on the back of the
NIC), is used for printer identification in peer-to-peer and
NetWare protocols. The Network Address is the hardware
address or MAC address. The Protocol Address is the IP
address you assign the printer. You can set a new AppleTalk
Printer Name using the Apple Printer Utility.
Another way to print the Network Settings page is:
1. Go to the URL Configuration Page, the URL is
http://<IP address>/configure.html.
2. Click on the Network Administration link. This displays
the Network Administration Page.
3. Click Configure Status Page, then click Generate Now.
(The Network Administration Page is described in
Chapter 4.)
P
AGE
The Network Settings Page
- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
Unit Serial No: 992048
Network Address: 00:40:af:79:19:80
Network Topology: Ethernet
Network Speed: 10 Megabits
Novell Network Information
Print Server Name: NEC_992048
Password Defined: No
Preferred Server Name not defined
Directory Services Context not defined
Frame Type: Novell 802.3
Peer-to-Peer Information
Frame Type: 802.3
Network ID: 32803
TCP/IP Network Information
Frame Type: Ethernet II
Subnet Mask: 255.255.255.0
DNS Address: 0.0.0.0
AppleTalk Network Information
Frame Type: 802.2 SNAP On 802.3
Preferred Appletalk Zone:*
- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
Novell Connection Information
Printer Name: NEC_992048_P
File Server: LABNW312
Queue: NEC_992048_Q
No Notify Defined
Peer-to-Peer Connection Information
Printer Name: NEC_992048
AppleTalk Connection Information
AppleTalk Printer Name: Peggy's SS4600 4
TCP/IP Connection Information
Port Number: 10001
- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
Version: 05.20
Connector:RJ45
enabled
enabled
enabled
Protocol Address: 131.241.45.84
Default Gateway: 131.241.45.254
enabled
San Jose EtherNet
Priority: 1 Attached: Yes
