Resetting

Resetting the keyboard and mouse

If it becomes necessary to reset the keyboard and mouse connected to
your AdderView Omega, use the following procedure:
To reset the keyboard and mouse
1 Press and hold the Omega button for roughly five seconds until
both of the AdderView Omega indicators light as well as all three
of the keyboard indicators.
2 Release the Omega button and then press (and release it) once
again.
The connected keyboard and mouse will both be reset.

Resetting your AdderView Omega

If your AdderView Omega ceases to operate correctly, reset it using
the following procedure:
To reset the AdderView Omega
1 Remove the two connectors linking your AdderView Omega to the
keyboard ports of the two computers (alternatively, switch off the
two computers). The connectors are purple and have the
logo.
2 After a short pause, reconnect the two connectors (or switch on
the computers), whereupon the AdderView Omega will reinitialize
itself.

Switching more than two computers

In common with our professional switching products, you can expand
its use and switch more than two computers. This is called 'cascading'
and is achieved by connecting the keyboard, video and mouse ports of
the AdderView Omega to one of the channels of another switching
product.
When you use our switches in this way, channel selection is performed
by an extended keyboard sequence.
For instance, to select channel two of your AdderView Omega when it
is connected to the fourth port of an AdderView GEM (a four port
switch), you would use the keyboard sequence:
1 then, while still holding
2 Release and press , then release all keys.
Note: Because the AdderView Omega does not use a power supply, it
must always be the last switching device in a cascade. For the same
reason, you cannot cascade two AdderView Omegas.
4 3 2 1
14
