Appendix 7 – Cable and connector specifications

AdderView CATxIP 1000 to power switch cable

pin D-type female

Power switch to power switch daisy chain cable

pin RJ

Multi-head synchronisation cable

pin RJ
pin RJ
MASTER end
pin D-type female pin D-type female
MASTER end
pin D-type female pin D-type female
pin D-type male
SLAVE end
Use this cable when two
AdderView CATxIP 000
devices are being synchronised.
SLAVE end
Use this cable when three
AdderView CATxIP 000
devices are being synchronised.
SLAVE end
