Unit configuration

This page provides access to a selection of both basic and advanced settings
for the AdderView CATxIP 1000. Many of the settings displayed here are also
accessible through the on-screen menu.
Hardware Version
Indicates the version of the electronic circuitry within the AdderView CATxIP
1000 unit.
Firmware Version
Indicates the version of the internal software within the AdderView CATxIP 1000
flash memory. This may be updated using the
Host Keyboard Layout
Use the arrow buttons to match the keyboard layout expected by the host
system.
Admin Password
Enter the password that will be used to gain administrator access to the
AdderView CATxIP 1000. There can only be one admin user and only that user is
given access to the configuration menus.
flash upgrade procedure.
To get here
1 Using VNC viewer or a browser, log on as the 'admin' user.
2 Click the 'Configure' button in the top right corner.
3 Click the 'Unit Configuration' option.
Unit Name
The name entered here will be displayed on the local menus and the remote
VNC viewer/browser windows.
Menu Bar Toggle Hot Key
Determines the function key that can be used to display/hide the menu bar
within the VNC screen.
Encryption
Three options are available: Always on, prefer off, prefer on. The one to choose
depends on the specific details of your installation - see
details. The use of encryption imposes a slight performance overhead of roughly 10%
but is highly secure against third party intrusion.
Advanced Unit Configuration
Encryption settings
for
