Global user access via web browser

You can use a standard Web browser
the AdderView CATxIP 1000 and its host computer(s). As soon as you make
contact with the AdderView CATxIP 1000 it will begin downloading a small Java
application to your browser, which will be used only for the duration of your
connection.
To access via your web browser
1 Launch your standard Web browser as usual.
2 In the Address section, type the address of the AdderView CATxIP 1000 as
follows:
http://v.w.x.y
where v.w.x.y is the IP network address, for example 192.168.0.3
If you have been asked to also enter a port
•
3 Press . A connection attempt will be made.
4 In the browser window, select the 'Connect using built-in Java VNC viewer'
option to download a small application that will temporarily empower your
browser (on slow connections the application download can take several
tens of seconds to complete). Once complete, a connection details dialog
will be displayed:
Options button
Provides a range of viewer and connection settings -
5 Make any necessary option/encryption changes and click the OK button
to proceed. Depending on the options selected, you may need to confirm
certain items.
6 A second connection attempt will be made and if successful, an
authentication dialog will be displayed:
7 Enter your username and password. The
and show the current host computer. Note: If the Username entry is blanked
out then only admin user account is currently defined and only a password is
required.
(supported versions) to gain access to
number.
The previously entered
AdderView CATxIP 000 address
will be shown here
If required, select the
encryption mode - MORE [+]
MORE [+]
viewer window
should now open
IMPORTANT: During login, if you see a warning message similar to the
one shown here, then stop and do not proceed.
This message is displayed if an AdderView CATxIP 1000 unit, that your
viewer has previously visited, has had a change of security keys. This
is not uncommon if a unit is reset for some reason. However, it could
also mean that your trusted unit is being spoofed and you may not be
connecting to the system that you think you are.
Do not click the Yes button until you have checked with your
administrator that the trusted AdderView CATxIP 1000 unit has been
recently reset for some reason.
