Triumph Adler LP 4230 Instruction Handbook Manual

Triumph Adler LP 4230 Instruction Handbook Manual

Laser printer b/w
Table of Contents

Advertisement

Instruction Handbook
LP 4230
Laser Printer b/w

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LP 4230 and is the answer not in the manual?

Questions and answers

Summary of Contents for Triumph Adler LP 4230

  • Page 1 Instruction Handbook LP 4230 Laser Printer b/w...
  • Page 2: Table Of Contents

    Contents Machine Parts ..............1-1 Components at the Front of the Printer ......1-2 Operation Panel ..............1-3 Paper Handling ..............2-1 General Guidelines ............2-2 Selecting the Right Paper ..........2-4 Paper Type ............... 2-11 Loading Paper ..............3-1 Preparing the Paper ............
  • Page 3 Network Interface .............. 9-3 10 Appendix ................10-1 Specifications ..............10-2 Glossary Index...
  • Page 4 Legal and Safety Information Please read this information before using your machine. This chapter provides information on the following topics: Legal Information License Agreements Safety Information Symbols Installation Precautions xvii Precautions for Use About the Operation Guide Conventions in This Guide xxii...
  • Page 5: Legal Information

    Legal Information CAUTION NO LIABILITY IS ASSUMED FOR ANY DAMAGE CAUSED BY IMPROPER INSTALLATION. Notice on Software SOFTWARE USED WITH THIS PRINTER MUST SUPPORT THE PRINTER'S EMULATION MODE. The printer is factory-set to emulate the PCL. The emulation mode can be changed. Notice The information in this guide is subject to change without notification.
  • Page 6: License Agreements

    License Agreements IBM Program License Agreement THE DEVICE YOU HAVE PURCHASED CONTAINS ONE OR MORE SOFTWARE PROGRAMS (“PROGRAMS”) WHICH BELONG TO INTERNATIONAL BUSINESS MACHINES CORPORATION (“IBM”). THIS DOCUMENT DEFINES THE TERMS AND CONDITIONS UNDER WHICH THE SOFTWARE IS BEING LICENSED TO YOU BY IBM. IF YOU DO NOT AGREE WITH THE TERMS AND CONDITIONS OF THIS LICENSE, THEN WITHIN 14 DAYS AFTER YOUR ACQUISITION OF THE DEVICE YOU MAY RETURN THE DEVICE FOR A FULL...
  • Page 7 1. the equivalent of U.S. $25,000 in your local currency; or 2. IBM's then generally available license fee for the Program This limitation will not apply to claims for bodily injury or damages to real or tangible personal property for which IBM is legally liable. IBM will not be liable for any lost profits, lost savings, or any incidental damages or other economic consequential damages, even if IBM, or its authorized supplier, has been advised of the possibility of such...
  • Page 8 3. To protect proprietary rights of Monotype Imaging, you agree to maintain the Software and other proprietary information concerning the Typefaces in strict confidence and to establish reasonable procedures regulating access to and use of the Software and Typefaces. 4. You agree not to duplicate or copy the Software or Typefaces, except that you may make one backup copy.
  • Page 9: Original Ssleay License

    Firmware of this machine is using in part the GPL applied codes (www.fsf.org/copyleft/gpl.html). Please access "http:// www.kyoceramita.com/gpl" for more information on how to make GPL applied codes available. Open SSLeay License Copyright © 1998-2006 The OpenSSL Project. All rights reserved. Redistribution and use in source and binary forms, with or without modification, are permitted provided that the following conditions are met: Redistributions of source code must retain the above copyright...
  • Page 10 This library is free for commercial and non-commercial use as long as the following conditions are aheared to. The following conditions apply to all code found in this distribution, be it the RC4, RSA, lhash, DES, etc., code; not just the SSL code. The SSL documentation included with this distribution is covered by the same copyright terms except that the holder is Tim Hudson (tjh@cryptsoft.com).
  • Page 11 Compliance and Conformity FCC Statement (for users in the United States and Canada) This device complies with Part 15 of FCC Rules and RSS-Gen of IC Rules. Operation is subject to the following two conditions; (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation of the device.
  • Page 12: Safety Information

    Radio Frequency Transmitter This machine contains a transmitter module. We, the manufacturer (UTAX GmbH) hereby declare that this equipment (page printer), model LP 4230 is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC. Radio Tag Technology...
  • Page 13: Caution Labels

    Caution Labels The printer bears any of the following labels. Laser inside the printer Laser inside the printer (Laser radiation warning) (Laser radiation warning) For U.S.A. and For Europe, Asia, and Canada other countries CDRH Regulations The Center for Devices and Radiological Health (CDRH) of the U.S. Food and Drug Administration implemented regulations for laser products on August 2, 1976.
  • Page 14 Manufacturer’s address: 2-28, 1-Chome, Tamatsukuri, Chuo-ku, Osaka 540-8585, Japan Declares that the product Product name: Page Printer Model number: LP 4230 (as tested with enhancement optional unit; Paper Feeder PF-100) Conforms to the following product specifications: EN 55 022:1998+A1:2000+A2:2003 Class B...
  • Page 15 The manufacturer and its merchandising companies retain the following technical documentation in anticipation of the inspection that may be conducted by the authorities concerned: User's instruction that conforms to the applicable specifications. Technical drawings. Descriptions of procedures that guarantee conformity. Other technical information.
  • Page 16: Duplex Printing

    EN ISO 7779 Maschinenlärminformations-Verordnung 3. GPSGV, 06.01.2004: Der höchste Schalldruckpegel beträgt 70 dB (A) oder weniger gemäß EN ISO 7779. Disclaimer TA Triumph-Adler will not be liable to customers or any other person or entity for any loss or damage caused or alleged to be caused directly or indirectly by equipment sold or furnished by us, including but not limited to, any interruption of service, loss of business or anticipatory profits, or consequential damages resulting from the use or operation of the...
  • Page 17: Symbols

    Symbols The sections of this guide and parts of the machine marked with symbols are safety warnings meant to protect the user, other individuals and surrounding objects, and ensure correct and safe usage of the machine. The symbols and their meanings are indicated below. DANGER: Indicates that serious injury or even death will very possibly result from insufficient attention to or incorrect compliance with the related points.
  • Page 18: Installation Precautions

    Installation Precautions Environment Caution Avoid placing the machine on or in locations which are unstable or not level. Such locations may cause the machine to fall down or fall over. This type of situation presents a danger of personal injury or damage to the machine. Avoid locations with humidity or dust and dirt.
  • Page 19 Power Supply/Grounding the Machine Warning Do not use a power supply with a voltage other than that specified. Avoid multiple connections in the same outlet. These types of situations present a danger of fire or electrical shock. Plug the power cord securely into the outlet. If metallic objects come in contact with the prongs on the plug, it may cause a fire or electric shock.
  • Page 20: Precautions For Use

    Precautions for Use Cautions when using the machine Warning Do not place metallic objects or containers with water (flower vases, flower pots, cups, etc.) on or near the machine. This situation presents a danger of fire or electrical shock should they fall inside.
  • Page 21 If dust accumulates within the machine, there is a danger of fire or other trouble. It is therefore recommended that you consult with your service representative in regard to cleaning of internal parts. This is particularly effective if accomplished prior to seasons of high humidity.
  • Page 22: Machine Parts

    About the Operation Guide This Operation Guide contains the following chapters: 1 Machine Parts This chapter explains the names of parts. 2 Paper Handling This chapter explains how choose, handle and load paper. 3 Loading Paper This chapter explains paper specifications for this printer and how to load paper into the cassette or MP tray.
  • Page 23: Conventions In This Guide

    Conventions in This Guide This manual uses the following conventions. Convention Description Example Used to emphasize a key word, Refer to Print Quality Problems on page Italic phrase or reference to additional 5-3. Typeface information. Used to denote buttons on the To start printing, click OK.
  • Page 24 Machine Parts This chapter identifies machine parts and operation panel keys. Components at the Front of the Printer Components at the Rear of the Printer Operation Panel Machine Parts...
  • Page 25: Components At The Front Of The Printer

    Components at the Front of the Printer Top Cover Paper Stopper Top Tray Operation Panel USB Memory Slot Right Cover Paper Cassette Front Cover MP Tray 10 Subtray Components at the Rear of the Printer 11 Network Interface Connector 12 USB Interface Connector 13 Rear Cover 14 Power Cord Connector 15 Power Switch...
  • Page 26: Operation Panel

    Operation Panel Indicators Message Display Cursor Keys [GO] Key [Cancel] Key [OK] Key [MENU] Key Machine Parts...
  • Page 27 Machine Parts...
  • Page 28: Paper Handling

    Paper Handling This chapter explains paper specifications for this printer General Guidelines Selecting the Right Paper Paper Type 2-11 Paper Handling...
  • Page 29: General Guidelines

    General Guidelines The machine is designed to print on standard copier paper, but it can also accept a variety of other types of paper within the limits specified below. Note The manufacturer assumes no liability for problems that occur when paper not satisfying these requirements is used. Selection of the right paper is important.
  • Page 30: Minimum And Maximum Paper Sizes

    Minimum and Maximum Paper Sizes The minimum and maximum paper sizes are as follows. For the paper smaller than JIS B6, postcards, and envelopes, the MP tray must be used. Paper cassette MP tray Minimum Minimum Paper Size Paper Size 105mm 70mm (4-1/8 inches)
  • Page 31: Selecting The Right Paper

    Selecting the Right Paper This section describes the guidelines for selecting paper. Condition Avoid using paper that is bent at the edges, curled, dirty, torn, embossed, or contaminated with lint, clay, or paper shreds. Use of paper in these conditions can lead to illegible printing and paper jams, and can shorten the life of the machine.
  • Page 32: Basis Weight

    Basis Weight Basis weight is the weight of paper expressed in grams per square meter (g/m²). Paper that is too heavy or too light may cause feed errors or paper jams as well as premature wear of the product. Uneven weight of paper, namely uneven paper thickness may cause multiple-sheet feeding or print quality problems such as blurring because of poor toner fusing.
  • Page 33: Paper Grain

    The moisture content of the paper varies with the relative humidity in the room. When the relative humidity is high and the paper absorbs moisture, the paper edges expand, becoming wavy in appearance. When the relative humidity is low and the paper loses moisture, the edges shrink and tighten, and print contrast may suffer.
  • Page 34: Special Paper

    Special Paper The following types of special paper can be used: Paper type to be used Paper type to be selected Thin paper (60 to 64 g/m²) Vellum Thick paper (90 to 220 g/m²) Thick Colored paper Color Recycled paper Recycled Overhead projector transparencies Transparency...
  • Page 35 The basic rule for printing on adhesive labels is that the adhesive must never come into contact with any part of the machine. Adhesive paper sticking to the drum or rollers will damage the machine. Label paper has a structure comprising of three layers, as shown in the diagram.
  • Page 36 Some postcards have rough edges on the back (those are created when the paper is cut). In this case, put the postcards on a flat place and rub the edges with, for example, a ruler to smooth them. Envelopes Up to 5 envelopes can be loaded at a time. Envelopes should be fed in the face-up position, right edge first.
  • Page 37 Recycled Paper Select recycled paper that meets the same specifications as the white bond paper except for whiteness. Refer to Paper Specifications on page 2-2. Note Before purchasing recycled paper, test a sample on the machine and check that the printing quality is satisfactory. 2-10 Paper Handling...
  • Page 38: Paper Type

    Paper Type The printer is capable of printing under the optimum setting for the type of paper being used. Setting the paper type for the paper source from the printer’s operation panel will cause the printer to automatically select the paper source and print in the mode best suited to that type of paper.
  • Page 39 2-12 Paper Handling...
  • Page 40: Loading Paper

    Loading Paper This chapter explains how to load paper into the cassette or MP tray Preparing the Paper Loading Paper into Cassette Loading Paper into MP (Multi-Purpose) Tray Loading Paper...
  • Page 41: Preparing The Paper

    Preparing the Paper After removing paper from the packaging, fan through the sheets to separate them prior to loading. If using paper that has been folded or is curled, straighten it prior to loading. Failure to do so may result in a paper jam. IMPORTANT Ensure paper is not stapled and clips are removed.
  • Page 42 Adjust the paper length guide to the paper size required. If you are going to use paper that is longer than A4, pull out the extension paper cassette by pushing the release lever one by one and adjust it to the desired paper size. Load the paper in the cassette.
  • Page 43 Insert the paper cassette into the slot in the printer. Push it straight in as far as it will go. There is a paper gauge on the left side of the front of the paper cassette to indicate the remaining paper supply. When paper is exhausted, the pointer will go down to the level of (empty).
  • Page 44: Loading Paper Into Mp (Multi-Purpose) Tray

    Loading Paper into MP (Multi-Purpose) Tray The LP 4230 can load up to 50 sheets of 11 × 8 1/2" or A4 paper (80 g/m²) into the MP tray. Pull the MP tray towards you until it stops. Adjust the position of the paper guides on the MP tray. Standard paper sizes are marked on the MP tray.
  • Page 45: Paper Stopper

    Note If the paper is considerably curled in one direction, for example, if the paper is already printed on one side, try to roll the paper in the opposite direction to counteract the curl. Printed sheets will then come out flat. Correct Incorrect When loading envelope, place with the envelope flap closed and...
  • Page 46: Connecting And Printing

    Connecting and Printing This chapter explains how to start up the printer, print from your PC, and use the application software included in the CD-ROM. Connections Changing Network Interface Parameters Printing a Network Interface Status Page 4-12 Installing the Printer Driver 4-13 Printing 4-19...
  • Page 47: Connections

    Connections This section explains how to start up the printer. Connecting the USB Cable Follow the steps as below for connecting the USB cable. Connect the USB cable to the USB Interface Connector. Note Use a USB cable with a rectangular Type A plug and a square Type B plug.
  • Page 48: Connecting The Power Cord

    Connecting the Power Cord Install the printer close to an AC wall outlet. If an extension cord is used, the total length of the power cord plus extension should be 5 meters (16 feet) or less. Note Ensure the printer's power switch is off. Only use the power cord supplied with the printer.
  • Page 49: Changing Network Interface Parameters

    Changing Network Interface Parameters This printer supports TCP/IP, TCP/IP (IPv6), NetWare, AppleTalk, IPP, SSL Server, IPSec protocols, and Security Level. For more information, refer to the Advanced Operation Guide. Note After all network related settings have been done, turn the machine OFF and ON again.
  • Page 50: Subnet Mask

    TCP/IP This section describes how to enable the TCP/IP protocol. If TCP/IP is set to Off, use to select On and press [OK]. >TCP/IP > Press . Each time you press , the selection changes. >>DHCP >>IP Address 000.000.000.000 >>Subnet Mask 000.000.000.000 >>Gateway 000.000.000.000...
  • Page 51 TCP/IP (IPv6) This section describes how to enable the TCP/IP (IPv6) protocol. If TCP/IP (IPv6) is set to Off, use to select On and press >TCP/IP (IPv6) > [OK]. Press . Each time you press , the selection changes. >>RA(Stateless) >>DHCPv6 Display the item you want to set and press [OK].
  • Page 52 Press . Each time you press , the selection changes. Refer to the explanations below when specifying the settings. If you are using NetWare, AppleTalk, IPP, SSL Server or IPSec to connect to a network, you must enter an administrator ID and press [OK].
  • Page 53: Security Level

    Set the Security Level to High. >Security Level High NetWare This section explains the procedure for enabling NetWare. Enter the administrator ID and password. Then, if NetWare is set to >NetWare > Off, use to select On and press [OK]. Press >>Frame Type Auto...
  • Page 54 AppleTalk This section explains the procedure for enabling AppleTalk. Enter the administrator ID and password. Then, if AppleTalk is set >AppleTalk to Off, use to select On. Press [OK]. A blinking question mark (?) appears. >AppleTalk Press [OK] again. Press [MENU]. The display returns to Ready. This section explains the procedure for enabling IPP.
  • Page 55 SSL Server This section explains the procedure for enabling SSL Server. Enter the administrator ID and password. Then, if SSL Server is >SSL Server > set to Off, use to select On and press [OK]. Press . Each time you press , the selection changes.
  • Page 56 Security Level Security Level is primarily a menu used by service representative >Security Level for maintenance work. There is no need for customers to use this menu. High Connecting and Printing 4-11...
  • Page 57: Printing A Network Interface Status Page

    Printing a Network Interface Status Page You can print out a status page for the network interface. The network status page shows the network addresses, and other information under various network protocols about the network interface. Adjust/Maintenance Adjust/Maintenance is used to adjust the print quality and to carry out printer maintenance.
  • Page 58: Installing The Printer Driver

    Installing the Printer Driver According to the instructions of the Installation Guide, connect the PC to the printer and turn on them to install the printer driver. For more information on printer driver, refer to the KX Driver User Guide in the CD- ROM.
  • Page 59 Custom Mode: This option allows you to select items to be installed • as required and to specify the port. Proceed the section below according to the installation method. Express Mode When selecting Express Mode, printer driver and fonts are installed. After installing with this mode, the other utilities can be added using Custom Mode.
  • Page 60 Custom Mode When selecting Custom Mode, printer port and utilities are changed as necessary. On Installation Method screen, click Custom Mode. On Driver tab and Utility tab of the Custom Installation screen, select the printer driver and utilities you want to install, and click Next. Select the printer you want to install, and click Next.
  • Page 61 Installing the Printer Driver on Mac OS This section explains how to install the printer driver in Mac OS. Turn on the printer and the Macintosh. Insert the included CD-ROM (Product Library) into the CD-ROM drive. Double-click the CD-ROM icon. Double-click either OS X 10.2 and 10.3 Only or OS X 10.4 or higher depending on your Mac OS version.
  • Page 62 Open System Preferences and click Print & Fax. Click the plus symbol (+) to add the installed printer driver. Click the IP icon for an IP connection or the AppleTalk icon for an AppleTalk connection and then enter the IP address and printer name.
  • Page 63 The selected printer is added. This completes the printer setup procedure. 4-18 Connecting and Printing...
  • Page 64: Printing

    Printing This section explains the printing procedure from an application software. You can specify the printing settings from each tab on KX Driver. KX Driver is stored in the CD-ROM (Product Library). For more information, refer to the KX Driver User Guide in the CD-ROM. About KX Driver KX Driver consists of the following tabs.
  • Page 65: Status Monitor

    Status Monitor The Status Monitor monitors the printer status and provides an ongoing reporting function. It also allows you to specify and modify settings for printers not included in the KX Driver. The Status Monitor is installed automatically during KX Driver installation.
  • Page 66 If an information notification event occurs, the 3D view and an alert sound are used to notify you. For information on the sound notification settings, refer to Status Monitor Settings on page 4-22. Status Monitor icon The Status Monitor icon is displayed in the taskbar notification area when the Status Monitor is running.
  • Page 67: Status Monitor Settings

    Status Monitor Settings The Status Monitor has two tabs to configure its settings. Use the Preference option to set up the Status Monitor. Sound Notification Tab The Event Notification tab contains the following items. IMPORTANT To confirm the settings on Sound Notification tab, the computer requires the sound capabilities such as sound card and speaker.
  • Page 68 Appearance Tab The Appearance tab is contains the following items. Enlarge window Doubles the size of the Status Monitor window. Always on top Positions the Status Monitor in front of other active windows. Transparency Displays the Status Monitor as a transparent window. Connecting and Printing 4-23...
  • Page 69: Uninstalling Software (Windows Pc)

    Uninstalling Software (Windows PC) The software can be uninstalled (removed) using the CD-ROM (Product Library) supplied with the printer. IMPORTANT On Macintosh computers, because the printer settings are specified using a PPD (PostScript Printer Description) file, the software cannot be uninstalled using the CD-ROM (Product Library). Exit all active software applications.
  • Page 70: Maintenance

    Maintenance This chapter explains how to replace the toner container and clean the printer General Information Toner Container Replacement Cleaning the Printer Prolonged Non-Use and Moving of the Printer Maintenance...
  • Page 71: General Information

    General Information This chapter describes basic maintenance tasks you can perform for the printer. You can replace the toner container according to the printer's display. Also, the internal parts need periodic cleaning. Note Information Collection on Memory Chips - The memory chip attached to the toner container is designed to improve convenience for the end user;...
  • Page 72: Replacing The Toner Container

    Replacing the Toner Container This section explains how to replace the toner container. CAUTION Do not attempt to incinerate the Toner Container. Dangerous sparks may cause burns. IMPORTANT During toner container replacement, temporarily move storage media and computer supplies (such as floppy disks) away from the toner container.
  • Page 73 Take the new toner container out of the toner kit. Shake the new toner container at least 5 times as shown in the figure in order to distribute the toner evenly inside the container. Remove the label from the toner container. Install the new toner container in the printer.
  • Page 74 Turn the lock lever to the lock position. Close the top cover. Maintenance...
  • Page 75: Cleaning The Printer

    Cleaning the Printer To avoid print quality problems, the interior of the printer must be cleaned with every toner container replacement. Open the top cover and front cover. Lift the developer unit together with the toner container out of the printer.
  • Page 76 Place the drum unit flat on a clean, level surface. IMPORTANT Do not place the drum unit on end. Use a clean, lint free cloth to clean dust and dirt away from the metal registration roller. IMPORTANT Take care not to touch the transfer roller (black) during cleaning.
  • Page 77 Return the developer unit to its position, aligning the guides at both ends with the slots in the printer. Then, close the front cover and top cover. Use a lint free cloth to clean dust and dirt away from the vent on the left and the right side of the machine.
  • Page 78: Prolonged Non-Use And Moving Of The Printer

    Prolonged Non-Use and Moving of the Printer Prolonged Non-use If you ever leave the printer unused for a long period of time, remove the power cord from the wall outlet. We recommend you consult with your dealer about the additional actions you should take to avoid possible damage that may occur when the printer is used next time.
  • Page 79 5-10 Maintenance...
  • Page 80: Troubleshooting

    Troubleshooting This chapter explains how to handle printer problems, understand error messages, and clear paper jams General Guidelines Print Quality Problems Error Messages Ready, Data, and Attention Indicators Clearing Paper Jams 6-10 Troubleshooting...
  • Page 81: General Guidelines

    General Guidelines The table below provides basic solutions for problems you may encounter with the printer. We suggest you consult this table to troubleshoot the problems before calling for service repairs. Symptom Check Items Corrective Actions Print quality is poor. –...
  • Page 82: Print Quality Problems

    Print Quality Problems The tables and diagrams in the following sections define print quality problems and the corrective action you can conduct to solve the problems. Some solutions may require cleaning or replacing parts of the printer. If the suggested corrective action will not solve the problem, call for service representative.
  • Page 83 Printed Results Corrective Action Check the toner container and if necessary replace. Refer to Toner Faint or blurred printing Container Replacement on page 5-2. Clean the charger wire. Refer to Cleaning the Printer on page 5-6. Check the toner container and if necessary replace. Refer to Toner Gray background Container Replacement on page 5-2.
  • Page 84: Error Messages

    Error Messages The following table lists errors and maintenance messages that you can be dealt with by yourself. If Call service or Error.Power off. is displayed, turn off the printer then turn it back on to see if the printer has recovered. If the printer has not recovered, turn off the printer, disconnect the power cord, and contact your service representative or authorized service center.
  • Page 85 Message Corrective Action The CF card inserted in the printer is not formatted, and therefore cannot be read or written. To format a CF card, follow the procedure in Memory Card (Using the memory card) section Format error in the Advanced Operation Guide. Memory card Current print processing cannot continue because of occurrence of KPDL error which is categorized by ##.
  • Page 86 Message Corrective Action When one or more optional feeders are installed, this message will appear if any of the paper feeders or the printer cassette upper than the selected one is not properly closed. Paper path error The print job transferred to the printer was too complex to print on a page. Press [GO] to resume printing.
  • Page 87: Storage Error Codes

    Storage Error Codes CompactFlash (CF) Card and USB Flash Memory Errors Code Meaning The printer does not support the CF card inserted, or the CF card is broken. Insert the correct CF card. For more information, refer to Memory Card (Using the memory card) section in the Advanced Operation Guide.
  • Page 88: Ready, Data, And Attention Indicators

    Ready, Data, and Attention Indicators The following indicators light during normal operation and whenever the printer needs attention. Depending on the status of lighting, each indicator has the following meaning: Indicator Description Flashing. Indicates an error that you can resolve. On.
  • Page 89: Clearing Paper Jams

    Clearing Paper Jams If paper jams in the paper transport system, or no paper sheets are fed at all, the Paper jam message appears and the location of the paper jam (the component where the paper jam has occurred) is also indicated.
  • Page 90: General Considerations For Clearing Jams

    Paper jam message Paper jam location Description Reference page Paper jam inside the printer. page 6-15 Paper jam Printer Paper jam at the rear cover. page 6-17 Paper jam Rear Cover General Considerations for Clearing Jams Bear in mind the following considerations when attempting paper jam removal: CAUTION When pulling the paper, pull it gently so as not to tear it.
  • Page 91 MP Tray Remove the paper jammed at the MP tray. IMPORTANT Do not try to remove paper that has already been partially fed. Proceed to Inside the Printer on page 6-15. Reload the MP tray. Open and close the top cover to clear the error and the printer warms up and resumes printing.
  • Page 92 Paper Cassette/Paper Feeder Pull out the cassette or optional paper feeder. Remove any partially fed paper. IMPORTANT Do not try to remove paper that has already been partially fed. Proceed to Inside the Printer on page 6-15. Note Check to see if paper is loaded correctly. If not, reload the paper.
  • Page 93 Duplexer Paper is jammed in the duplexer. Remove the jammed paper using the procedure given below. Pull the paper cassette all the way out of the printer. Open the duplexer's cover in front of the printer and remove any jammed paper. Open the duplexer's cover at the rear of the printer and remove any jammed paper.
  • Page 94: Inside The Printer

    Inside the Printer Pull the paper cassette all the way out of the printer. Remove any partially fed paper. IMPORTANT Do not try to remove paper that has already been partially fed. Proceed to step 2. Open the top cover and front cover, and lift the developer unit together with the toner container out of the printer.
  • Page 95 Return the drum unit to its position, aligning the guides at both ends with the slots in the printer. Insert the developer unit together with the toner container, back into the machine. Close the top cover and the front cover. The printer warms up and resumes printing.
  • Page 96: Rear Cover

    Rear Cover Open the rear cover and remove the jammed paper by pulling it out. CAUTION The fuser unit inside the printer is hot. Do not touch it, as it may result in burn injury. If the paper is jammed inside the fuser unit, open the fuser cover and remove the paper by pulling it out.
  • Page 97 6-18 Troubleshooting...
  • Page 98: Using The Operation Panel

    Using the Operation Panel This chapter contains explanations on the following topics: General Information Understanding the Operation Panel Using the Menu Selection System Report Print 7-11 USB Memory (USB flash memory selection) 7-16 Counter (Viewing the counter value) 7-18 Paper Settings 7-19 Print Settings 7-27...
  • Page 99: General Information

    General Information This chapter provides the information you need to configure the printer. In general you need to use the operation panel only to make default settings. You can make most changes to the printer settings using the printer driver through the application software. Note Changes to printer settings made using a software application override changes made using the operation panel.
  • Page 100: Understanding The Operation Panel

    Understanding the Operation Panel The operation panel on the top of the printer has a 2-line by 16-character liquid crystal display (LCD), eight keys, and three indicators (LED). Messages that appear on the display and functions of indicators and keys are explained in this chapter. Using the Operation Panel...
  • Page 101: Message Display

    Message Display The message display on the operation panel shows: Status information, the ten messages listed below which are • displayed during normal operation. Error codes, when the printer requires the operator’s attention; as • explained in the Operation Guide. Status Information Message Meaning...
  • Page 102: Indicators In Message Display

    Indicators in Message Display Ready Ready, Data, and Attention Indicators The following indicators light during normal operation and whenever the printer needs attention. Depending on the status of lighting, each indicator has the following meaning: Indicator Description Flashing. Indicates an error that you can resolve. For details, refer to the Troubleshooting section in the Operation Guide.
  • Page 103: Cancel Key

    Keys The operation panel keys are used to configure the printer operation. Note that certain keys have a secondary function. GO Key Use this key to: Recover from certain errors. • Recover from Auto Sleep mode. • Cancel Key This key is used to: Cancel a printing job.
  • Page 104: Cursor Keys

    Cursor Keys The four cursor keys are used in the menu system to access an item or enter numeric values. Use to change menus, and move to the sub menu. The cursor key with the question mark ( ) may be pressed when the paper jam message has appeared on the message display.
  • Page 105: Using The Menu Selection System

    Using the Menu Selection System Menu Selection System This section explains how to use the menu selection system. [MENU] on the operation panel allows you to use the menu to configure the printer settings to your specific needs. Settings can be made when Ready is indicated on the printer message display.
  • Page 106: Selecting A Menu

    Selecting a Menu The mode selection menu is hierarchical. Press to display the desired menu. If the selected menu has a sub-menu, > is displayed after the menu. Paper Settings > Press to move to the sub-menu or to go back. Indicates that there is a sub-menu >...
  • Page 107: Report Print

    Setting a Mode Selection Menu This section explains the setting procedures used for each menu item in the mode selection menu. While the printer displays Ready, Please wait, Sleeping and Report Print > Processing, press [MENU]. The mode selection menu is displayed.
  • Page 108 Report Print The printer prints the report. Report Print includes the following items: Print Menu Map • Print Status Page • Print Fonts List • Print RAM Disk File List • Print Mem. Card File List • Press [MENU]. Press repeatedly until Report Print >...
  • Page 109 Menu Map Sample 7-12 Using the Operation Panel...
  • Page 110: Status Page

    Print Status Page You can check the printer's current status, including available memory space and option settings by printing a status page. Press while Report Print > is displayed. Press repeatedly until >Print Status Page appears. Press [OK]. A question mark (?) appears. >Print Press [OK] again.
  • Page 111 Firmware Version This item shows the version and release date of the printer firmware. Printer Settings Information This item shows various printer settings for hardware-related items: MP tray paper size and type • Paper cassette size and type • Sleep time •...
  • Page 112: File List

    Print Fonts List To help you decide in selecting a font, you can printout lists of the internal fonts or the optional fonts. Press while Report Print > is displayed. Press repeatedly until >Print Fonts List appears. Press [OK]. A question mark (?) appears. >Print Fonts List ? Press [OK] again.
  • Page 113: Usb Memory (Usb Flash Memory Selection)

    USB Memory (USB flash memory selection) This specifies the settings for removing the USB flash memory and printing USB flash memory content. IMPORTANT This message is displayed only when the USB host block is set to Unblock . For more information, refer to Interface Block (Interface (external device) block setting) on page 7-56.
  • Page 114 Copies (Number of copies) Sets the number of copies printed of the specified file in USB flash memory. While Copies in step 5 above is displayed, press Copies to display the number of copies. (E.g.: 10) Press [OK]. Paper Source and a question mark (?) appears. Paper Source ? Cassette 1 Paper Source (Selecting the paper feed source)
  • Page 115: Counter (Viewing The Counter Value)

    Counter (Viewing the counter value) This only displays the total number of pages printed. You cannot change the displayed number. Press [MENU]. Press repeatedly until Counter > appears. Counter > Press . >Printed Pages appears as he total number of pages >Printed Pages printed.
  • Page 116: Paper Settings

    Paper Settings This sets the paper size and type for the MP tray and cassettes from which paper is supplied. The options available in Paper Settings are as follows: MP Tray Size (Setting MP tray paper size) • MP Tray Type (Setting the MP tray paper type) •...
  • Page 117 MP Tray Size (Setting MP tray paper size) When you use the MP tray, you should set the MP tray size to the paper size that is used to format the job to print. If the sizes do not match, printing will not be performed on the correct size paper.
  • Page 118 Press [OK]. A blinking question mark (?) appears. >MP Tray Type ? PLAIN Press to display the desired paper type. The message display toggles through the following paper types: PLAIN TRANSPARENCY PREPRINTED LABELS BOND RECYCLED VELLUM ROUGH LETTERHEAD COLOR PREPUNCHED ENVELOPE CARDSTOCK THICK...
  • Page 119 Setting the Paper Size from the Operation Panel Use the operation panel to set the size of paper loaded in the cassette on the printer. Press while Paper Settings > is displayed. Press repeatedly until >Cassette Size > appears. If optional paper feeders are added, Cassette1 Size will appear for the standard paper cassette and Cassette2 Size, and Cassette3 Size will appear for the optional paper feeders.
  • Page 120 Unit (Selecting the unit of measurement) Press Press repeatedly until >>Unit appears. The unit of measurement can be selected between millimeters and inches. The current unit of measurement is displayed (the default setting is mm). Press [OK]. A blinking question mark (?) appears. >>Unit ? mm Select mm or inch using...
  • Page 121 Cassette (1 to 3) Type (Setting the cassette paper type) By setting a paper type (plain, recycled, etc.) for the paper cassette, you can automatically select the paper in the paper cassette according to the paper type you command on the printer driver. The default setting is plain paper for all paper cassettes.
  • Page 122: Type Adjust

    Type Adjust (Creating custom paper type) The following describes the procedure used to set a user-defined paper type for the printer. Eight custom user settings may be registered. After having been set, any of these may be called up when setting the paper type for a paper source.
  • Page 123 Press to display the desired paper thickness. The display changes as shown below. For details of the default setting for each paper type, refer to Paper Specifications on page 2-2. Light Normal 1 Normal 2 Normal 3 Heavy 1 Heavy 2 Heavy 3 Extra Heavy Press [OK].
  • Page 124: Print Settings

    Print Settings These settings specify printing parameters such as the print quality used for printing (Normal or Fine), the gloss mode (Low or High), the number of copies, reduced printing and the page orientation. The options available in Print Quality are as follows: Paper Source (Selecting the paper feed source) •...
  • Page 125 Paper Feed Mode (Setting the paper feed source) This mode specifies how the paper should be fed, after the paper feed source and paper type has been chosen. If Auto is selected, the printer searches for a paper feed source that matches the paper size and type, and paper is delivered from that source.
  • Page 126 Duplex (Duplex printing) Using the duplexer, you can automatically print on both sides of the paper. The duplexer is mounted underneath the printer. Duplex printing is available for the following paper types: PLAIN PREPRINTED BOND RECYCLED ROUGH COLOR PREPUNCHED HIGH QUALITY CUSTOM 1 (to 8) Activating the duplexer is done by selecting either short edge or long edge binding mode.
  • Page 127 Press to display the desired binding mode. The message display toggles through the following: Off (default) Short edge bind Long edge bind Press [OK]. Press [MENU]. The display returns to Ready. Override A4/LT (Overriding difference between A4 and Letter) When the Override A4/LT is turned On using the operation panel, the printer ignores the difference between A4 and Letter paper sizes.
  • Page 128 Alternative Emulation for KPDL Emulation KPDL is Kyocera’s implementation of the PostScript language. The KPDL (AUTO) emulation enables the printer to automatically change the emulation mode according to the data received when printing. In addition to KPDL (AUTO) emulation, you can use the operation panel to set another emulation mode that is used very often.
  • Page 129 Font Select (Selecting the default font) You can select the default font for the current interface. The default font can be one of the internal fonts or a font that is downloaded to the printer memory or stored on CompactFlash (CF) card. In this menu, you can also set the type and pitch for Courier and Letter Gothic;...
  • Page 130 Press [OK]. A blinking question mark (?) appears. >>Courier ?Regular Select Regular or Dark using Press [OK]. Press [MENU]. The display returns to Ready. Changing the Default Font Size You can change the size of the default font. If you selected a proportional font, the character size can also be changed.
  • Page 131 When the desired size is displayed, press [OK]. Press [MENU]. The display returns to Ready. Code Set (Setting the code set) You can change the character code set. Available character code sets vary depending on the current font. (The default is IBM PC-8.) Press while Print Settings >...
  • Page 132 Press [OK]. A blinking question mark (?) appears. >>KIR Mode ? On Select On or Off using Press [OK]. Press [MENU]. The display returns to Ready. EcoPrint Mode (Selecting the EcoPrint mode) By enabling EcoPrint mode, you can minimize the amount of toner used during printing.
  • Page 133 Page Set (Setting pagination) In Page Set menus, you can set the number of copies, page orientation, and other settings regarding pagination. The options available in Page Set are as follows: Copies (Number of copies) • Orientation (Print orientation) • LF Action (Linefeed) •...
  • Page 134 Press [OK]. A blinking question mark (?) appears. >>Orientation ? Portrait Select Portrait or Landscape using Press [OK]. Press [MENU]. The display returns to Ready. LF Action (Linefeed) This procedure instructs the printer what to do when it receives a linefeed code (0AH).
  • Page 135 Press [OK]. A blinking question mark (?) appears. >>Wide A4 ? Off Select On or Off using Press [OK]. Press [MENU]. The display returns to Ready. 7-38 Using the Operation Panel...
  • Page 136: Network (Network Settings)

    Network (Network settings) This printer supports TCP/IP and TCP/IP (IPv6) protocols. IP is an abbreviation for Internet Protocol. This printer routinely uses the TCP/IP (IPv4) protocol, but provides a separate setting for the next- generation IP, IPv6. TCP/IP (IPv4) uses 32-bit IP addresses, but the rapid growth in the number of Internet users has resulted in a shortage of IP addresses.
  • Page 137 Select On or Off using Select On and press [OK]. The display changes to the settings shown below. DHCP (DHCP setting) DHCP (Dynamic Host Configuration Protocol) is the protocol that assigns the information required to establish a network connection when a host attempts to connect to the network (Internet).
  • Page 138 Subnet Mask (Subnet mask setting) The subnet mask is a way of augmenting the network address section of an IP address. A subnet mask represents all network address sections as 1 and all host address sections as 0. The number of bits in the prefix indicates the length of the network address.
  • Page 139 Press [MENU]. The display returns to Ready. Bonjour (Bonjour setting) Bonjour, also known as zero-configuration networking, is a service that automatically detects computers, devices and services on an IP network. Bonjour, because an industry-standard IP protocol is used, allows devices to automatically recognize each other without an IP address being specified or DNS server being set.
  • Page 140 RA(Stateless) (RA (Stateless) setting) The IPv6 router communicates (transmits) information such as the global address prefix using ICMPv6. This information is the Router Advertisement (RA). ICMPv6 stands for Internet Control Message Protocol, and is a IPv6 standard defined in the RFC 2463 "Internet Control Message Protocol (ICMPv6) for the Internet Protocol Version 6 (IPv6) Specification".
  • Page 141: Device Common (Selecting/Setting The Common Device)

    Device Common (Selecting/Setting the common device) Selects/sets all the functions in this printer. The options available in Device Common are as follows: MSG Language (Selecting the message language) • Buzzer (Alarm (Buzzer) setting) • RAM Disk Mode (Using the RAM disk) •...
  • Page 142 Buzzer (Alarm (Buzzer) setting) This function uses tones to notify the user of printer operations and the printer status. This setting is useful, for example, when the printer is located some distance from the user. The options available in Buzzer are as follows: Key Confirm.
  • Page 143 Ready (Preparation completed tone setting) When On is selected in this setting, a tone sounds when print preparation has been completed. The default setting is Off. Press while >Buzzer > is displayed. Press repeatedly until >>Ready appears. Press [OK]. A blinking question mark (?) appears. >>Ready ? Off Select On or Off using...
  • Page 144 RAM Disk Mode (Using the RAM disk) The RAM disk is a memory space shared within the printer memory that can temporarily store print jobs. The stored print job can then be used to print multiple copies of the job reducing the total amount of time required to print the whole job.
  • Page 145 RAM Disk Size (Setting the RAM disk size) Use this procedure to set the amount of memory used for the RAM disk. IMPORTANT The RAM Disk Size menu option only appears when is set to On . RAM Disk Mode Press while >RAM Disk Mode On >...
  • Page 146 Format (Formatting CF card) A new CF card must be formatted before it can be used in the printer. Formatting allows data to be written to the CF card.. IMPORTANT Format is only displayed when a CF card is installed in the printer and protection is disabled.
  • Page 147 Duplex (Duplex printing error detection setting) If the error detection setting for duplex printing has been turned On, and you attempt to print onto a paper size and paper type that cannot be used for duplex printing, the Duplex disabled Press GO error message will be displayed and printing will stop.
  • Page 148 Timer (Timer setting) This specifies timer-related settings such as the automatic form-feed timeout and the timeout settings for Auto Sleep. The options available in Timer are as follows: Form Feed Time Out (Automatic form feed timeout setting) • Sleep Timer (Sleep timer timeout time) •...
  • Page 149 Sleep Timer (Sleep timer timeout time) You can adjust the length of time the printer waits before entering Auto Sleep in the absence of data. The printer reverts to normal operation mode when the printer receives a print job, the operation panel is operated, or one of the exterior covers is opened.
  • Page 150 Auto Error Clear (Auto error clear setting) If an error that still allows you to continue printing occurs, the next received data is automatically printed after a set period of time elapses. For example, if the printer is shared over a network as a network printer and one person causes one of the above errors, after the set period of time elapses, the data sent from the next person is printed.
  • Page 151 For setting the time until the panel is reset, refer to the next section Panel Reset Timer (Setting the panel reset timer). Press while >Timer > is displayed. Press repeatedly until >>Auto Panel Reset appears. Press [OK]. A blinking question mark (?) appears. >>Auto Panel Reset ? On Select On or Off using...
  • Page 152: Security

    Security The security functions can be set up to protect printer operation and the print data. The options available in Security are as follows: ID (Administrator ID input) • Password (Administrator password input) • I/F Block (Interface (external device) block setting) •...
  • Page 153 Password (Administrator Password input) To set up the Security functions, you must enter an administrator ID and administrator password. For information on how to set the administrator password, refer to Admin (Administrator settings) on page 7-63. When you entered the ID in the previous step (ID (Administrator ID Password input)), the message display shows Password (Administrator password input) and a blinking cursor (_).
  • Page 154 USB Device (USB interface setting) This locks and protects the USB interface. The default setting is Unblock. Press while >I/F Block > is displayed. >>USB Device appears. Press [OK]. A blinking question mark (?) appears. >>USB Device ? Unblock Select Block or Unblock using Press [OK].
  • Page 155 NetWare (NetWare setting) NetWare is a PC-based network operating system specifically for servers. NetWare is a client-server system that operates by installing the NetWare OS on the server and dedicated client modules (NetWare clients) on the client machines (running MS-DOS, OS/2, Windows, etc.). The basic network layer protocol used is NetWare's own IPX (Internetwork Packet eXchange)/SPX (Sequenced Packet eXchange), but the system also supports TCP/IP.
  • Page 156 AppleTalk (AppleTalk setting) AppleTalk is a communications protocol used primarily on Macintosh computers and also refers to the Mac OS network functions. AppleTalk assigns 24-bit network addresses (a 16-bit network section and an 8-bit node address) that are used to identify devices (computers, printers, etc.) on the network.
  • Page 157 SSL Server (SSL Server setting) SSL (Secure Sockets Layer) refers to a protocol used to encrypt information sent and received over a network. SSL can currently be used to encrypt data such as the WWW or FTP files widely used on the Internet so that privacy-related information, credit card numbers, corporate secrets and other confidential information can be sent and received safely.
  • Page 158 3DES (SSL Server 3DES setting) 3DES (Triple Data Encryption Standard) is a high level of encryption in which DES encryption is repeated threefold. The default setting is Off. Press while >SSL Server On > is displayed. >>3DES appears. Press [OK]. A blinking question mark (?) appears. >>3DES ? Off Select On or Off using...
  • Page 159 HTTPS (SSL Server HTTPS setting) HTTPS (HyperText Transfer Protocol Secure) is a protocol that adds SSL data encryption, message authentication and a digital signature function to the HTTP protocol used for data transfer between WWW servers and clients. S-HTTP is a similar protocol, but HTTPS differs in that it uses SSL. The default setting is Off.
  • Page 160: Admin (Administrator Settings)

    Admin (Administrator settings) The administrator setting is a function that identifies the user who can use the printer and can be used to manage users. The administrator is authenticated by the entered administrator ID and password and can then use the printer's security functions. The options available in Admin are as follows: ID (Administrator ID input) •...
  • Page 161 Each time you press , the following settings to be changed appear in succession. Change ID • Change Password • Note If a change is required, refer to the procedures in Change ID (Administrator ID change) and Change Password (Administrator Password change) below. Press [OK] again.
  • Page 162: Adjust/Maintenance (Adjust/Maintenance Selection/Setting)

    Adjust/Maintenance (Adjust/Maintenance selection/setting) Adjust/Maintenance is used to adjust the print quality and to carry out printer maintenance. The options available in Adjust/Maintenance are as follows: Restart Printer • Service (for maintenance) • IMPORTANT Service is primarily a menu used by service representative for maintenance work.
  • Page 163 Service (for maintenance) The options available in Service are as follows: Print Status Page (Printing the service status page) • Print Network Status Page (Printing the network status page) • Print Test Page • Developer (Initializing the developer unit) • IMPORTANT Service is primarily a menu used by service representative for maintenance work.
  • Page 164: Test Page

    Press repeatedly until >>Print Test Page appears. Press [OK]. A question mark (?) appears. >>Print Test Page ? Press [OK] again. Processing appears and a test page is printed out. When printing ends, the display returns to Ready. Developer (Initializing the developer unit) The replaced developer can be automatically fill up the toner using this menu when a toner container is installed and the printer is turned on.
  • Page 165 7-68 Using the Operation Panel...
  • Page 166: Option

    Option This chapter explains the options for this printer General Information Expansion Memory Modules Paper Feeder (PF-100) CompactFlash (CF) Card USB Flash Memory Option...
  • Page 167: General Information

    General Information The printers have the following options available to satisfy your printing requirements. Note Install the memory module before installing the optional paper feeder (PF-100). For instructions on installing individual options, refer to the documentation included with the option. Some options are explained in the following sections.
  • Page 168: Expansion Memory Modules

    Expansion Memory Modules To expand the printer memory for more complex print jobs and faster print speed, you can plug in optional memory module (dual in line memory module) in the memory slot provided on the printer main controller board. You can select additional memory module from 128, 256, 512, or 1024 MB.
  • Page 169: Removing A Memory Module

    Remove the fixing tape in case of the first installation. Then, remove the memory slot cover as shown in the figure. Remove the memory module from its package. Aligning the cutouts of the memory module with the matching keys of the socket, carefully plug the memory module into the memory socket until it clicks in place.
  • Page 170: Paper Feeder (Pf-100)

    Paper Feeder (PF-100) The PF-100 allows you to add two more paper cassette to the bottom of the printer for continuous feeding of a large volume of paper. Each paper cassette can hold up to approximately 250 sheets of ISO A4, ISO A5, JIS B5, Letter, or Legal size (80g/m ) paper.
  • Page 171: Compactflash (Cf) Card

    CompactFlash (CF) Card The printer is equipped with a slot for a CF card with the maximum size of 256MB. A CF card is useful for storing fonts, macros, and overlays. Turn off the printer and disconnect the power cord and printer cable. CAUTION Before inserting a CF card in the printer, make sure that the printer is switched off.
  • Page 172: Computer Interface

    Computer Interface This chapter contains explanations on the following topics: General Information USB Interface Network Interface Computer Interface...
  • Page 173: General Information

    General Information This chapter explains the connector specifications of USB and network interfaces. USB Interface This printer supports the Hi-Speed USB. USB (Universal Serial Bus) interface specifications are as follows. Specifications Basic specification Complies with the Universal Serial Bus Specification Revision 2.0. Connectors Printer: B-type receptacle (female) with upstream port Cable: B-type plug (male)
  • Page 174: Network Interface

    Network Interface Features Automatic IP address resolution This feature is compatible with the DHCP/DHCPv6 protocol and allows the printer to automatically receive IP addresses from the DHCP/DHCPv6 server. Management using Web browsers HTTP pages are incorporated in to the interface, so that a web browser can be used to monitor and change a range of settings.
  • Page 175 EMI Countermeasures VCCI Class B, FCC Class B (U.S.), CE (Europe) IMPORTANT When IPv6 functions are used, the devices used on the network (routers, PCs, etc) must support IPv6. Computer Interface...
  • Page 176: Appendix

    10 Appendix This section lists the following information of this printer. Specifications 10-2 Environmental Standard Requirements 10-4 Appendix 10-1...
  • Page 177: Specifications

    Specifications Note These specifications are subject to change without notice. Item Description Type Desktop Printing Method Electrophotography, laser scan Paper Weight Cassette 60 to 120 g/m² (Duplex: 60 to 105 g/m²) MP Tray 60 to 220 g/m² Paper Type Cassette Plain, Preprinted, Bond, Recycled, Rough, Letterhead, Color (Colour), Prepunched, High Quality, Custom 1 to 8 MP Tray...
  • Page 178 Item Description Supported OS Windows 2000 Service Pack 2 or later, Windows Server 2003, Windows XP, Windows Vista, Mac OS X 10.x Interface Hi-Speed USB: 1 Network: 1 (10BASE-T/100BASE-TX) KUIO-W slot: 1 PRESCRIBE Emulation PCL 6, KPDL, KPDL (AUTO), Line Printer, IBM Proprinter, DIABLO 630, EPSON LQ-850 Standard Memory...
  • Page 179: Environmental Standard Requirements

    Environmental Standard Requirements This machine conforms to the following environmental standard requirements. Time for switching to Sleep mode (default): 15 minutes • Duplex Printing: Standard Equipment • Durable paper for feeding: Paper made of 100 % recycled paper • Note Contact your dealer or service representative for recommended paper types.
  • Page 180 Glossary Additional memory An additional memory (optional) is used for increasing the memory capacity of this machine. For DIMM that can be used in this machine, contact your service technician. AppleTalk AppleTalk offers file sharing and printer sharing and it also enables you to utilize application software that is on another computer on the same AppleTalk network.
  • Page 181 IP Address (Internet Protocol Address) The Internet Protocol address is a unique number that represents a specific computer in a network. The format of an IP Address is four numbers separated by dots, e.g. 192.168.110.171. Each number should be a decimal between 0 and 255. KPDL KPDL is Kyocera's implementation of the PostScript page description language Level3.
  • Page 182 Subnet Mask This is a 32-bit numerical value that defines which bits of the IP address specify the network address and which specify the host address. TCP/IP (Transmission Control Protocol/Internet Protocol) TCP/IP is a suite of protocols designed to define the way computers and other devices communicate with each other over a network.
  • Page 183 Glossary-4...
  • Page 184 Index Colored paper ..............2-9 Numerics Common device selecting or setting ..........7-44 3DES setting SSL server ..............7-61 CompactFlash card ...........8-2, 8-6 Components at the front of the printer ...........1-2 at the rear of the printer ..........1-2 Adhesive label ..............2-8 Computer interface ............9-1 Administrator ID ............7-55, 7-63 Connection Change ..............
  • Page 185 Expansion memory module OK ................7-7 option ................8-2 KPDL Errors ..............7-31 Express mode installation method ..........4-14 Label ................2-7 Left cover 1 ..............1-2 Features linefeed code ..............7-37 Network interface ............9-3 Loading paper Font select Cassette ..............3-2 Selecting default font ..........7-32 MP tray ..............
  • Page 186 USB flash memory ..........7-17 Possible paper jam locations .........6-10 Postcard ................2-8 Power cord connection ............4-3, 4-4 Operation Panel Power cord connector diagram ..............7-3 components ..............1-2 Operation panel Power switch components .............. 1-2 components ..............1-2 indicators, keys, overview ......... 1-3 Preparing paper ...............3-2 Option Preprinted paper ..............2-9...
  • Page 187 USB interface Interface block ............7-57 USB interface connector Security level ..............7-62 components ............. 1-2 Selecting paper feed source USB Memory ..............7-16 USB falsh memory ..........7-17 USB memory slot Selecting regular or dark ..........7-32 Interface block ............7-56 Service (for maintenance) ..........7-66 Special paper ..............2-7 Specifications ..............10-2 Environmental specifications ........10-4...
  • Page 188 We recommend the use of our own brand supplies. We will not be liable for any damage caused by the use of third party supplies in this machine.
  • Page 189 UTAX GmbH, Ohechaussee 235, 22848 Norderstedt, Germany...

Table of Contents
