  • Page 1 Instruction Handbook Basic LP 4335 Laser Printer b/w...
  • Page 2 This Operation Guide is for model LP 4335. Note This Operation Guide contains information that corresponds to using both the inch and metric versions of these machines. The inch versions of these machines are shown in the screens in this guide. If you are using the metric version, use the messages provided for the inch version as reference only.

  • Page 3: Table Of Contents

    Contents Machine Parts ................1-1 Components at the Front of the Printer ........1-2 Components at the Rear of the Printer ........1-2 Operation Panel ................1-3 Loading Paper ................2-1 Preparing the Paper ..............2-2 Loading Paper into Cassette ............. 2-2 Loading Paper into MP (Multi-Purpose) Tray ......
  • Page 5 1Legal and Safety Information Please read this information before using your machine. This chapter provides information on the following topics: Legal Information License Agreements Safety Information Symbols Installation Precautions Precautions for Use xviii About the Operation Guide Conventions in This Guide...

  • Page 6: Legal Information

    Legal Information CAUTION NO LIABILITY IS ASSUMED FOR ANY DAMAGE CAUSED BY IMPROPER INSTALLATION. Notice on Software SOFTWARE USED WITH THIS PRINTER MUST SUPPORT THE PRINTER'S EMULATION MODE. The printer is factory-set to emulate the PCL. The emulation mode can be changed. Notice The information in this guide is subject to change without notification.

  • Page 7: License Agreements

    License Agreements IBM Program License Agreement THE DEVICE YOU HAVE PURCHASED CONTAINS ONE OR MORE SOFTWARE PROGRAMS (“PROGRAMS”) WHICH BELONG TO INTERNATIONAL BUSINESS MACHINES CORPORATION (“IBM”). THIS DOCUMENT DEFINES THE TERMS AND CONDITIONS UNDER WHICH THE SOFTWARE IS BEING LICENSED TO YOU BY IBM. IF YOU DO NOT AGREE WITH THE TERMS AND CONDITIONS OF THIS LICENSE, THEN WITHIN 14 DAYS AFTER YOUR ACQUISITION OF THE DEVICE YOU MAY RETURN THE DEVICE FOR A FULL...
  • Page 8 1. the equivalent of U.S. $25,000 in your local currency; or 2. IBM's then generally available license fee for the Program This limitation will not apply to claims for bodily injury or damages to real or tangible personal property for which IBM is legally liable. IBM will not be liable for any lost profits, lost savings, or any incidental damages or other economic consequential damages, even if IBM, or its authorized supplier, has been advised of the possibility of such...
  • Page 9 3. To protect proprietary rights of Monotype Imaging, you agree to maintain the Software and other proprietary information concerning the Typefaces in strict confidence and to establish reasonable procedures regulating access to and use of the Software and Typefaces. 4. You agree not to duplicate or copy the Software or Typefaces, except that you may make one backup copy.
  • Page 10 Firmware of this machine is using in part the GPL applied codes (www.fsf.org/copyleft/gpl.html). Please access "http:// www.kyoceramita.com/gpl" for more information on how to make GPL applied codes available. Open SSLeay License Copyright © 1998-2006 The OpenSSL Project. All rights reserved. Redistribution and use in source and binary forms, with or without modification, are permitted provided that the following conditions are met: Redistributions of source code must retain the above copyright...
  • Page 11 This library is free for commercial and non-commercial use as long as the following conditions are aheared to. The following conditions apply to all code found in this distribution, be it the RC4, RSA, lhash, DES, etc., code; not just the SSL code. The SSL documentation included with this distribution is covered by the same copyright terms except that the holder is Tim Hudson (tjh@cryptsoft.com).
  • Page 12 Compliance and Conformity This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.

  • Page 13: Safety Information

    Radio Frequency Transmitter This machine contains a transmitter module. We, the manufacturer (TA Triumph-Adler AG) hereby declare that this equipment (page printer), model LP 4335 is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC. Radio Tag Technology...
  • Page 14 Caution Labels The printer bears any of the following labels. Laser inside the printer Laser inside the printer (Laser radiation warning) (Laser radiation warning) For U.S.A. and For Europe, Asia, and Canada other countries CDRH Regulations The Center for Devices and Radiological Health (CDRH) of the U.S. Food and Drug Administration implemented regulations for laser products on August 2, 1976.
  • Page 15 DECLARATION OF CONFORMITY 2004/108/EC, 2006/95/EEC, 93/68/EEC, 1999/5/EC and 2009/125/EC We declare under our sole responsibility that the product to which this declaration relates is in conformity with the following specifications. EN55024 EN55022 Class B EN61000-3-2 EN61000-3-3 EN60950-1 EN60825-1 EN300 330-1 EN300 330-2 EN62301 Canadian Department of Communications...
  • Page 16 Safety Instructions Regarding the Disconnection of Power Caution: The power plug is the main isolation device! Other switches on the equipment are only functional switches and are not suitable for isolating the equipment from the power source. VORSICHT: Der Netzstecker ist die Hauptisoliervorrichtung! Die anderen Schalter auf dem Gerät sind nur Funktionsschalter und können nicht verwendet werden, um den Stromfluß...

  • Page 17: Symbols

    Symbols The sections of this guide and parts of the machine marked with symbols are safety warnings meant to protect the user, other individuals and surrounding objects, and ensure correct and safe usage of the machine. The symbols and their meanings are indicated below. DANGER: Indicates that serious injury or even death will very possibly result from insufficient attention to or incorrect compliance with the related points.

  • Page 18: Installation Precautions

    Installation Precautions Environment Caution Avoid placing the machine on or in locations which are unstable or not level. Such locations may cause the machine to fall down or fall over. This type of situation presents a danger of personal injury or damage to the machine. Avoid locations with humidity or dust and dirt.
  • Page 19 Power Supply/Grounding the Machine Warning Do not use a power supply with a voltage other than that specified. Avoid multiple connections in the same outlet. These types of situations present a danger of fire or electrical shock. Plug the power cord securely into the outlet. If metallic objects come in contact with the prongs on the plug, it may cause a fire or electric shock.

  • Page 20: Precautions For Use

    Precautions for Use Cautions when using the machine Warning Do not place metallic objects or containers with water (flower vases, flower pots, cups, etc.) on or near the machine. This situation presents a danger of fire or electrical shock should they fall inside.
  • Page 21 If dust accumulates within the machine, there is a danger of fire or other trouble. It is therefore recommended that you consult with your service representative in regard to cleaning of internal parts. This is particularly effective if accomplished prior to seasons of high humidity.

  • Page 22: About The Operation Guide

    About the Operation Guide This Operation Guide contains the following chapters: Parts Machine This chapter explains the names of parts. 2 Loading Paper This chapter explains paper specifications for this printer and how to load paper into the cassette or MP tray. 3 Printing This chapter explains how to install the printer driver, print from your PC, and use the application software included in the CD-ROM.

  • Page 23: Conventions In This Guide

    Conventions in This Guide This manual uses the following conventions. Convention Description Example Italic Used to emphasize a key word, Refer to Print Quality Problems on page Typeface phrase or reference to additional 5-3. information. Bold Used to denote buttons on the To start printing, click OK.
  • Page 24 Introduction-xxii...

  • Page 25: Machine Parts

    Machine Parts This chapter identifies machine parts and operation panel keys. Components at the Front of the Printer Components at the Rear of the Printer Operation Panel Machine Parts...

  • Page 26: Components At The Front Of The Printer

    Components at the Front of the Printer Top Cover Paper Stopper Top Tray Operation Panel USB Memory Slot Right Cover Paper Cassette Front Cover MP Tray 10 Subtray Components at the Rear of the Printer 11 Network Interface Connector 12 USB Interface Connector 13 Rear Cover 14 Power Cord Connector 15 Power Switch...

  • Page 27: Operation Panel

    Operation Panel Indicators Message Display Cursor Keys [GO] Key [Cancel] Key [OK] Key [MENU] Key Machine Parts...
  • Page 28 Machine Parts...

  • Page 29: Loading Paper

    Loading Paper This chapter explains how to load paper into the cassette or MP tray Preparing the Paper Loading Paper into Cassette Loading Paper into MP (Multi-Purpose) Tray Loading Paper...

  • Page 30: Preparing The Paper

    Preparing the Paper After removing paper from the packaging, fan through the sheets to separate them prior to loading. If using paper that has been folded or is curled, straighten it prior to loading. Failure to do so may result in a paper jam. IMPORTANT Ensure paper is not stapled and clips are removed.
  • Page 31 Adjust the paper length guide to the paper size required. If you are going to use paper that is longer than A4, pull out the extension paper cassette by pushing the release lever one by one and adjust it to the desired paper size. Load the paper in the cassette.
  • Page 32 Insert the paper cassette into the slot in the printer. Push it straight in as far as it will go. There is a paper gauge on the left side of the front of the paper cassette to indicate the remaining paper supply. When paper is exhausted, the pointer will go down to the level of (empty).

  • Page 33: Loading Paper Into Mp (Multi-Purpose) Tray

    Loading Paper into MP (Multi-Purpose) Tray This machine can load up to 50 sheets of 11 × 8 1/2" or A4 paper (80 g/m²) into the MP tray. Pull the MP tray towards you until it stops. Adjust the position of the paper guides on the MP tray. Standard paper sizes are marked on the MP tray.

  • Page 34: Paper Stopper

    Note If the paper is considerably curled in one direction, for example, if the paper is already printed on one side, try to roll the paper in the opposite direction to counteract the curl. Printed sheets will then come out flat. Correct Incorrect When loading envelope, place with the envelope flap closed and...

  • Page 35: Connecting And Printing

    Connecting and Printing This chapter explains how to start up the printer, print from your PC, and use the application software included in the CD-ROM. Connections Changing Network Interface Parameters Printing a Network Interface Status Page 3-12 Installing the Printer Driver 3-13 Printing 3-19...

  • Page 36: Connections

    Connections This section explains how to start up the printer. Connecting the USB Cable Follow the steps as below for connecting the USB cable. Connect the USB cable to the USB Interface Connector. Note Use a USB cable with a rectangular Type A plug and a square Type B plug.
  • Page 37 Connecting the Power Cord Install the printer close to an AC wall outlet. If an extension cord is used, the total length of the power cord plus extension should be 5 meters (16 feet) or less. Note Ensure the printer's power switch is off. Only use the power cord supplied with the printer.

  • Page 38: Changing Network Interface Parameters

    Changing Network Interface Parameters This printer supports TCP/IP, TCP/IP (IPv6), NetWare, AppleTalk, IPP, SSL Server, IPSec protocols, and Security Level. For more information, refer to the Advanced Operation Guide. Note After all network related settings have been done, turn the machine OFF and ON again.
  • Page 39 TCP/IP This section describes how to enable the TCP/IP protocol. If TCP/IP is set to Off, use to select On and press [OK]. >TCP/IP Press . Each time you press , the selection changes. >>DHCP >>IP Address 000.000.000.000 >>Subnet Mask 000.000.000.000 >>Gateway 000.000.000.000...
  • Page 40 TCP/IP (IPv6) This section describes how to enable the TCP/IP (IPv6) protocol. If TCP/IP (IPv6) is set to Off, use to select On and press >TCP/IP (IPv6) [OK]. Press . Each time you press , the selection changes. >>RA(Stateless) >>DHCPv6 Display the item you want to set and press [OK].
  • Page 41 Press . Each time you press , the selection changes. Refer to the explanations below when specifying the settings. If you are using NetWare, AppleTalk, IPP, SSL Server or IPSec to connect to a network, you must enter an administrator ID and press [OK].
  • Page 42 Set the Security Level to High. >Security Level High NetWare This section explains the procedure for enabling NetWare. Enter the administrator ID and password. Then, if NetWare is set to >NetWare > Off, use to select On and press [OK]. Press >>Frame Type Auto...
  • Page 43 AppleTalk This section explains the procedure for enabling AppleTalk. Enter the administrator ID and password. Then, if AppleTalk is set >AppleTalk to Off, use to select On. Press [OK]. A blinking question mark (?) appears. >AppleTalk ? On Press [OK] again. Press [MENU].
  • Page 44 SSL Server This section explains the procedure for enabling SSL Server. Enter the administrator ID and password. Then, if SSL Server is >SSL Server > set to Off, use to select On and press [OK]. Press . Each time you press , the selection changes.
  • Page 45 Security Level Security Level is primarily a menu used by service representative >Security Level for maintenance work. There is no need for customers to use this menu. High Connecting and Printing 3-11...

  • Page 46: Printing A Network Interface Status Page

    Printing a Network Interface Status Page You can print out a status page for the network interface. The network status page shows the network addresses, and other information under various network protocols about the network interface. Adjust/Maintenance Adjust/Maintenance is used to adjust the print quality and to carry out printer maintenance.

  • Page 47: Installing The Printer Driver

    Installing the Printer Driver Ensure the printer is plugged in and connected to the PC before installing the printer driver from the CD-ROM. Installing the Software in Windows If you are connecting this printer to a Windows PC, follow the next steps to install the printer driver.
  • Page 48 Express Mode In Express Mode, the installer automatically detects the printer when it is turned on. Use Express Mode for standard connection methods. In the installation method selection window, select Express Mode. The print system detection window appears and the installer detects the connected printers.
  • Page 49 Custom Mode Use Custom Mode if you want to specify the printer port and select the software to be installed. For example, if you do not want fonts installed on your computer to be replaced, select Custom Mode and deselect the Fonts checkbox in the utility tab.
  • Page 50 Double-click OS X x.x. The printer driver installation program starts up. Choose Select Destination, Installation Type and then install the printer driver as directed by the instructions in the installation software. Note In addition to Easy Install, the Installation Type options include Custom Install, which allows you to specify the components to be installed.
  • Page 51 Click the plus symbol (+) to add the installed printer driver. Click the IP icon for an IP connection or the AppleTalk icon for an AppleTalk connection and then enter the IP address and printer name. When you click the AppleTalk icon for an AppleTalk connection, enter the printer name.
  • Page 52 The selected printer is added. This completes the printer setup procedure. 3-18 Connecting and Printing...

  • Page 53: Printing

    Printing This section explains the printing procedure from an application software. You can specify the printing settings from each tab on KX Driver. KX Driver is stored in the CD-ROM (Product Library). For more information, refer to the Printer Driver User Guide in the CD-ROM. About KX Driver KX Driver consists of the following tabs.

  • Page 54: Status Monitor

    Use Number of copies to enter the number of copies required. Up to 999 copies can be printed. For Microsoft Word, we recommend that you click Options and specify Use printer settings for the Default tray. To start printing, click OK. Status Monitor The Status Monitor monitors the printer status and provides an ongoing reporting function.
  • Page 55 Pop-up window If an information notification event occurs, a pop-up window appears. This window only appears when the 3D View is open on the desktop. 3D View This shows the status of the monitored printer as a 3D image. You can choose whether to show or hide the 3D view from the menu displayed when you right-click the Status Monitor icon.
  • Page 56 Status Monitor Settings The Status Monitor has two tabs to configure its settings. Use the Preference option to set up the Status Monitor. Sound Notification Tab The Event Notification tab contains the following items. IMPORTANT To confirm the settings on Sound Notification tab, the computer requires the sound capabilities such as sound card and speaker.
  • Page 57 Appearance Tab The Appearance tab is contains the following items. Enlarge window Doubles the size of the Status Monitor window. Always on top Positions the Status Monitor in front of other active windows. Transparency Displays the Status Monitor as a transparent window. Connecting and Printing 3-23...

  • Page 58: Uninstalling Software (Windows Pc)

    Uninstalling Software (Windows PC) The software can be uninstalled (removed) using the CD-ROM (Product Library) supplied with the printer. IMPORTANT On Macintosh computers, because the printer settings are specified using a PPD (PostScript Printer Description) file, the software cannot be uninstalled using the CD-ROM (Product Library). Exit all active software applications.

  • Page 59: Maintenance

    Maintenance This chapter explains how to replace the toner container and clean the printer General Information Toner Container Replacement Cleaning the Printer Prolonged Non-Use and Moving of the Printer Maintenance...

  • Page 60: General Information

    General Information This chapter describes basic maintenance tasks you can perform for the printer. You can replace the toner container according to the printer's display. Also, the internal parts need periodic cleaning. Note Information Collection on Memory Chips - The memory chip attached to the toner container is designed to improve convenience for the end user;...
  • Page 61 Replacing the Toner Container This section explains how to replace the toner container. CAUTION Do not attempt to incinerate the Toner Container. Dangerous sparks may cause burns. IMPORTANT During toner container replacement, temporarily move storage media and computer supplies (such as floppy disks) away from the toner container.
  • Page 62 Take the new toner container out of the toner kit. Shake the new toner container at least 5 times as shown in the figure in order to distribute the toner evenly inside the container. Remove the label from the toner container. Install the new toner container in the printer.

  • Page 63: Maintenance Kit Replacement

    Turn the lock lever to the lock position. Close the top cover. Maintenance Kit Replacement When the machine prints 100,000 pages, a message is displayed indicating that the maintenance kit should be replaced. The maintenance kit must then be replaced immediately. To replace the maintenance kit, contact your service technician.

  • Page 64: Cleaning The Printer

    Cleaning the Printer To avoid print quality problems, the interior of the printer must be cleaned with every toner container replacement. Open the top cover and front cover. Lift the developer unit together with the toner container out of the printer.
  • Page 65 Place the drum unit flat on a clean, level surface. IMPORTANT Do not place the drum unit on end. Use a clean, lint free cloth to clean dust and dirt away from the metal registration roller. IMPORTANT Take care not to touch the transfer roller (black) during cleaning.
  • Page 66 Return the developer unit to its position, aligning the guides at both ends with the slots in the printer. Then, close the front cover and top cover. Use a lint free cloth to clean dust and dirt away from the vent on the left and the right side of the machine.

  • Page 67: Prolonged Non-Use And Moving Of The Printer

    Prolonged Non-Use and Moving of the Printer Prolonged Non-use If you ever leave the printer unused for a long period of time, remove the power cord from the wall outlet. We recommend you consult with your dealer about the additional actions you should take to avoid possible damage that may occur when the printer is used next time.
  • Page 68 4-10 Maintenance...

  • Page 69: Troubleshooting

    Troubleshooting This chapter explains how to handle printer problems, understand error messages, and clear paper jams General Guidelines Print Quality Problems Error Messages Ready, Data, and Attention Indicators Clearing Paper Jams 5-10 Troubleshooting...

  • Page 70: General Guidelines

    General Guidelines The table below provides basic solutions for problems you may encounter with the printer. We suggest you consult this table to troubleshoot the problems before calling for service repairs. Symptom Check Items Corrective Actions Print quality is poor. –...

  • Page 71: Print Quality Problems

    Print Quality Problems The tables and diagrams in the following sections define print quality problems and the corrective action you can conduct to solve the problems. Some solutions may require cleaning or replacing parts of the printer. If the suggested corrective action will not solve the problem, call for service representative.
  • Page 72 Printed Results Corrective Action Faint or blurred printing Check the toner container and if necessary replace. Refer to Toner Container Replacement on page 4-2. Clean the charger wire. Refer to Cleaning the Printer on page 4-6. Gray background Check the toner container and if necessary replace. Refer to Toner Container Replacement on page 4-2.

  • Page 73: Error Messages

    Error Messages The following table lists errors and maintenance messages that you can be dealt with by yourself. If Call service or Error.Power off. is displayed, turn off the printer then turn it back on to see if the printer has recovered. If the printer has not recovered, turn off the printer, disconnect the power cord, and contact your service representative or authorized service center.
  • Page 74 Message Corrective Action The CF card inserted in the printer is not formatted, and therefore cannot be read or written. To format a CF card, follow the procedure in Memory Card (Using the memory Format error card) section in the Advanced Operation Guide. Memory card Replace Maintenance Kit which is displayed on the message display.
  • Page 75 Message Corrective Action Displayed when the installed toner is the original TA Triumph-Adler product. Original toner installed A paper jam has occurred. The location of the paper jam is indicated in place of the #’s. For details, refer to Clearing Paper Jams on page 5-10. Paper jam ##################### When one or more optional feeders are installed, this message will appear if any of the...
  • Page 76 Storage Error Codes CompactFlash (CF) Card and USB Flash Memory Errors Code Meaning The printer does not support the CF card inserted, or the CF card is broken. Insert the correct CF card. For more information, refer to Memory Card (Using the memory card) section in the Advanced Operation Guide.

  • Page 77: Ready, Data, And Attention Indicators

    Ready, Data, and Attention Indicators The following indicators light during normal operation and whenever the printer needs attention. Depending on the status of lighting, each indicator has the following meaning: Indicator Description Flashing. Indicates an error that you can resolve. Refer to Error Messages on page 5-5.

  • Page 78: Clearing Paper Jams

    Clearing Paper Jams If paper jams in the paper transport system, or no paper sheets are fed at all, the Paper jam message appears and the location of the paper jam (the component where the paper jam has occurred) is also indicated.
  • Page 79 Paper jam message Paper jam location Description Reference page Paper jam inside the printer. page 5-15 Paper jam Printer Paper jam at the rear cover. page 5-17 Paper jam Rear Cover General Considerations for Clearing Jams Bear in mind the following considerations when attempting paper jam removal: CAUTION When pulling the paper, pull it gently so as not to tear it.
  • Page 80 MP Tray Remove the paper jammed at the MP tray. IMPORTANT Do not try to remove paper that has already been partially fed. Proceed to Inside the Printer on page 5-15. Reload the MP tray. Open and close the top cover to clear the error and the printer warms up and resumes printing.
  • Page 81 Paper Cassette/Paper Feeder Pull out the cassette or optional paper feeder. Remove any partially fed paper. IMPORTANT Do not try to remove paper that has already been partially fed. Proceed to Inside the Printer on page 5-15. Note Check to see if paper is loaded correctly. If not, reload the paper.
  • Page 82 Duplexer Paper is jammed in the duplexer. Remove the jammed paper using the procedure given below. Pull the paper cassette all the way out of the printer. Open the duplexer’s cover in front of the printer and remove any jammed paper. Open the duplexer’s cover at the rear of the printer and remove any jammed paper.
  • Page 83 Inside the Printer Pull the paper cassette all the way out of the printer. Remove any partially fed paper. IMPORTANT Do not try to remove paper that has already been partially fed. Proceed to step 2. Open the top cover and front cover, and lift the developer unit together with the toner container out of the printer.
  • Page 84 Return the drum unit to its position, aligning the guides at both ends with the slots in the printer. Insert the developer unit together with the toner container, back into the machine. Close the top cover and the front cover. The printer warms up and resumes printing.
  • Page 85 Rear Cover Open the rear cover and remove the jammed paper by pulling it out. CAUTION The fuser unit inside the printer is hot. Do not touch it, as it may result in burn injury. If the paper is jammed inside the fuser unit, open the fuser cover and remove the paper by pulling it out.
  • Page 86 5-18 Troubleshooting...

  • Page 87: Appendix

    Appendix This section lists the following information of this printer. Specifications Environmental Standard Requirements Appendix...

  • Page 88: Specifications

    Specifications Note These specifications are subject to change without notice. Item Description Type Desktop Printing Method Electrophotography, laser scan Paper Weight Cassette 60 to 120 g/m² (Duplex: 60 to 105 g/m²) MP Tray 60 to 220 g/m² Paper Type Cassette Plain, Preprinted, Bond, Recycled, Rough, Letterhead, Color (Colour), Prepunched, High Quality, Custom 1 to 8 MP Tray...
  • Page 89 Item Description Controller PowerPC 440F5/500 MHz Supported OS Microsoft Windows 2000/XP/Vista/7, Windows Server 2003/2008 Mac OS X 10.x Interface Hi-Speed USB: 1 Network: 1 (10BASE-T/100BASE-TX) KUIO-LV(W) slot: 1 PRESCRIBE Emulation PCL 6, KPDL, KPDL (AUTO), Line Printer, IBM Proprinter, DIABLO 630, EPSON LQ-850 Memory Standard...

  • Page 90: Environmental Standard Requirements

    Environmental Standard Requirements This machine conforms to the following environmental standard requirements. • Time for switching to Sleep mode (default): 15 minutes • Duplex Printing: Standard Equipment • Durable paper for feeding: Paper made of 100 % recycled paper Note Contact your dealer or service representative for recommended paper types Appendix...

  • Page 91: Index

    Index troubleshooting ............5-2 Cassette loading paper ............2-2 Charger cleaner ............... 4-7 Inside the printer Cleaning clearing paper jams ..........5-15 charger wire .............. 4-7 Installation method printer ............... 4-6 custom mode ............3-15 registration roller ............4-7 express mode ............3-14 Clearing paper jams Installation precautions ............
  • Page 92 clearing paper jams ..........5-13 connection ..............3-2 Paper gauge ..............2-4 USB interface connector Paper guides ..............2-5 components .............. 1-2 Paper length guide ............2-3 Paper stopper components ..............1-2 Possible paper jam locations .........5-10 Power cord connection ............3-3, 3-4 Power cord connector components ..............1-2 Power switch components ..............1-2...
  • Page 94 UTAX GmbH, Ohechaussee 235, 22848 Norderstedt, Germany...
