- Page 1 DC 2045 DC 2055 INSTRUCTION HANDBOOK...
- Page 2 Swiss Energy 2000 program. <IMPORTANT> The instructions contained herein are based on the 45 cpm (copies-per-minute) DC 2045 copier and the 55 cpm DC 2055 copier. NOTE: This Operation Guide contains information that corresponds to using both the inch and metric versions of this copier.
-
Page 3: Cautions
Please read this Operation Guide before using the copier. Keep it close to the copier for easy reference. The sections of this guide and parts of the copier marked with symbols are safety warnings meant to protect the user, other individuals and surrounding objects, and ensure correct and safe usage of the copier. -
Page 4: Table Of Contents
CONTENTS Section 1 Section 5 IMPORTANT! PLEASE READ FIRST..1 OTHER CONVENIENT FUNCTIONS ..5-1 CAUTION LABELS ............. 1-1 1. Making 2-sided copies from various types of originals INSTALLATION PRECAUTIONS ........1-2 [2-sided copy modes] ............5-1 (1) Making 2-sided copies from a 2-sided original ..5-1 PRECAUTIONS FOR USE .......... - Page 5 CONTENTS 23. Saving on toner use [Eco print mode] ......5-49 4. Multi-bypass tray paper settings ........7-60 (1) Paper size and type ..........7-60 24. Original set direction ............5-50 (2) Selecting other standard sizes ........ 7-61 25. Memorizing frequently used settings 5.
-
Page 6: Enlarging/Reducing The Copy Image
MAKING FULL USE OF THE COPIER'S ADVANCED FUNCTIONS Having the copier automatically select Making clear reproductions of Various functions for making enlarged copy paper of the same size as the photographs and reduced copies original <Image quality selection> Enlarging/reducing the copy image to fit the <Auto paper selection mode>... -
Page 7: Auto Rotation Function
Making booklets from sheet originals Making booklets from books Automatic sorting of copy sets without the <Booklet/Stitching mode> <Book to Booklet mode> Document Finisher (Page 5-22) (Page 5-25) <Sort/Finished mode> (Page 5-28) Automatic rotation of the copy image Copying different sized originals at the Adding a front and/or back cover to your <Auto rotation function>... -
Page 8: Copy Management Mode
Registering images to be used for form Managing shared forms Printing out different stored originals in overlay <Shared data box> one operation <Form registration> (Page 6-4) <Synergy print boxes> (Page 6-1) (Page 6-9) Using department ID-codes to manage Turning the power to the copier ON/OFF Changing the language used in the touch the number of copies made by each automatically on a set schedule... -
Page 9: Caution Labels
Section 1 IMPORTANT! PLEASE READ FIRST. CAUTION LABELS Caution labels have been attached to the copier at the following locations for safety purposes. BE SUFFICIENTLY CAREFUL to avoid fire or electric shock when removing a paper jam or when replacing toner. Label 1 High temperature inside. -
Page 10: Installation Precautions
INSTALLATION PRECAUTIONS Environmment • During copying, some ozone is released, but the amount does not cause any ill effect to one's health. If, however, the copier is used over a long period of time in a poorly CAUTION ventilated room or when making an extremely large number of copies, the smell may become unpleasant. -
Page 11: Precautions For Use
PRECAUTIONS FOR USE Cautions when using the copier CAUTION WARNING • DO NOT pull the power cord when removing it from the outlet. If the power cord is pulled, the • DO NOT place metallic objects or containers with wires may become broken and there is a danger water (flower vases, flower pots, cups, etc.) on or of fire or electrical shock. -
Page 12: Cautions When Handling Consumables
PRECAUTIONS FOR USE Cautions when handling Other precautions • DO NOT place heavy objects on the copier or cause consumables other damage to the copier. CAUTION • DO NOT open the front cover, turn off the main switch, or pull out the power plug during copying. •... -
Page 13: Section 2 Names Of Parts
Section 2 NAMES OF PARTS 1. Main body 1 Operation panel 8 Multi-bypass tray (Perform copy operations here.) (Set copy paper on this tray when you want to copy onto small 2 Cover on the right side of the operation panel paper sizes or onto special types of paper.) (Open this cover when you need to add toner.) 9 Insert guides... - Page 14 Section 2 NAMES OF PARTS & ⁄ # Original table (Set originals to be copied on this table.) $ Original insert guides (Align these guides to fit the width of the originals to be copied.) % Document Processor cover (Open this cover if an original misfeed occurs.) ^ Original set indicator (This indicator lights when originals are set in the Document Processor.)
- Page 15 Section 2 NAMES OF PARTS ‹ ‚ · — ¤ › fi fl ‡ ⁄ Œ ´ „ ¤ Original size indicator lines · Transfer unit release lever B (Be sure to align the original with these lines whenever setting an (Operate this lever when you need to pull out the transfer unit.) original on the platen.) ‚...
-
Page 16: Operation Panel
Section 2 NAMES OF PARTS 2. Operation panel & 1 [Start] key & indicator lamp ! [Copier] key & indicator lamp (Press this key when the lamp in that key is lit green and you want (Press this key to light the lamp in that key when you want to use to start copying.) the copier functions of this machine.) 2 [Stop/Clear] key... -
Page 17: Copy Default Settings
Section 2 NAMES OF PARTS Initial mode (at the end of warm-up or when the [Reset] key is pressed) In the default settings prepared at the factory, paper of the same size as the original is selected automatically and the copy magnification ratio is set to “100%”... -
Page 18: Specifications
Section 2 NAMES OF PARTS 3. Touch panel Inch specifications Paper Size Ready to copy. 11x8 " Combine 11x8 " Plain Orig.image quality x11" 1 sided Color R1 sided Reduc Auto 1 sided /Enlarge Bypass 11x8 " Exposure Plain R2 sided 11x8 "... -
Page 19: Registration Keys
Section 2 NAMES OF PARTS 1 This area displays messages on the machine's status and on * “User choice” tab operational procedures. (Touch this tab when you want to display the contents of the “User 2 This area displays information on the size of paper in the choice”... - Page 20 Section 2 NAMES OF PARTS ) “Program” tab NOTE (Touch this tab when you want to register the currently selected You can change or add new keys to those displayed in the “Basic” settings as a program, or to delete a previously registered and the “User choice”...
-
Page 21: Section 3 Preparations
Section 3 PREPARATIONS 1. Loading paper Paper can be loading into 5 locations in this copier: the 4 Pull the drawer[cassette] out toward you as far as it will go. drawers[cassettes] and the multi-bypass tray. (1) Note when adding paper After taking new paper out of its packaging, be sure to fan through them a few times to separate the sheets before loading the paper into a drawer[cassette] or setting the paper on the multi-bypass tray. -
Page 22: No.3 And No.4
Section 3 PREPARATIONS Align the paper flush against the right side of the Gently push the drawer[cassette] back in. drawer[cassette], and then set the paper in the drawer[cassette]. NOTE If you will not be using the copier for a prolonged period of time, remove all paper from the drawers[cassettes] and seal it in its original packaging in order to protect it against moisture. -
Page 23: Setting Paper On The Multi-Bypass Tray
Section 3 PREPARATIONS (4) Setting paper on the multi-bypass tray IMPORTANT! • Make sure there are no folds, etc., in the paper you load into the Standard copy paper as well as special paper can be set on the multi- drawers[cassettes]. - Page 24 Section 3 PREPARATIONS Adjust the insert guides to fit the width of the paper that is to be set on the multi-bypass tray. Slide the paper all the way in, along the insert guides, as far as it will go. IMPORTANT! •...
- Page 25 Section 3 PREPARATIONS Align the paper flush against the left side of the paper plate, (5) Loading paper into the Side Feeder (an optional and then set the paper in the Side Feeder. drawer[cassette] only available for 55 cpm copiers) Up to 4000 sheets of 11"...
-
Page 26: Setting Originals
Section 3 PREPARATIONS 2. Setting originals 3 How to set originals in the Document Processor (1) Setting originals in the Document Processor The Document Processor automatically feeds and scans each original, one by one, for copying. You can also have two-sided Adjust the original insert guides to fit the size of the originals. -
Page 27: Setting Originals On The Platen
Section 3 PREPARATIONS Hold the Document Processor handle and close the IMPORTANT! Document Processor. DO NOT set more originals than indicated on the sticker that is * Leave the Document Processor open whenever you are attached to the rear original insert guide. If more than the acceptable using an original that is over 4 cm thick. -
Page 28: Adding Toner
Section 3 PREPARATIONS 3. Adding toner Add toner when “Add toner” is displayed. Although a few copies can Turn the new toner bottle upside down and tap the bottom still be made once this message is displayed, you should add toner as portion about 10 times or so.
