Intergraph Zx10 System Board Manual page 16

8
Each processor socket accepts an Intel Pentium III processor (100 MHz or 133 MHz front-side
bus). The processor is secured to the socket by retention clips on both sides. The retention clips
are secured by nuts to screws attached to the system board.
The system can function with one or two processors installed. For a single-processor system, a
processor bus terminator card must be installed in the unused processor socket. For a dual-
processor system, both processors must be the same speed.
Processor
Retention Clip
(One each side)
Processor
Processor Bus Terminator Card
