Block Diagram - Intergraph Zx10 System Board Manual

4
Wahoo 133MHz FSB
Mouse /
Keyboard
USB
x2
AC97
Codec
Super I/O
Ctrl.
BIOS
Flash
PROM

Block Diagram

CPU 2 (SC242)
133MHz, 128-bit
ServerWorks
Host bus ServerSet III WS
North Bridge
CPU 1 (SC242)
AGP Pro (Slot 0)
PCI (Slot 1)
PCI (Slot 2)
PCI (Slot 3)
PCI (Slot 4)
66MHz, 64-bit
PCI (Slot 5)
33MHz, 64-bit
PCI (Slot 6)
ISA (Slot 6)
MEM_DATA
MEM_DATA
16-bit
16-bit
ServerWorks
ServerSet III
WS
MADP
Intel
82559
Ethernet
Ctrl.
Ensoniq
ES1373
Audio Ctrl.
16-bit
ServerWorks
ServerSet III
WS
I/O Bridge
33MHz, 64-bit
Battery
ATX Power
ATX Power
Floppy
Secondary
IDE
Primary
IDE
Ultra3 SCSI
Channel B
Ultra3 SCSI
Channel A
LSI
53C1010
Ultra3
SCSI Ctrl.
ServerWorks
ServerSet III
WS
South Bridge
