The drive is not terminated and requires external termination only if installed as the last
device on the SCSI chain.
Use jumpers as defined in the following table to set the SCSI ID. The factory default address
is SCSI ID 5.
SCSI ID
0
1
2
3
4
5
6
40 GB 8MM Tape Drive (CMTP169)
The following figure shows the back of the tape drive.
SCSI connector
Device Connector
Power
SCSI
SCSI termination is permanently disabled.
Use jumpers as defined in the following table to set the SCSI ID.
SCSI ID
0
1
2
3
ID1
ID2
ID4
OFF
OFF
OFF
ON
OFF
OFF
OFF
ON
OFF
ON
ON
OFF
OFF
OFF
ON
ON
OFF
ON
OFF
ON
ON
Power connector
Cable
P3; P5-P9
MCBL254A
ID0
ID1
ID2
OFF
OFF
OFF
ON
OFF
OFF
OFF
ON
OFF
ON
ON
OFF
ID2
ID1
Connects to
Power supply
J40, system board
ID0
83
