To adjust the centre frequency
response and tilt offset
If your system includes a DSP centre speaker you
should set Centre Y on the master speaker. An
additional frequency response option is then provided to
allow you to adjust the centre speaker, with the options:
C.Free, C.Boun., C.Sub 1, C.Sub 2, and
C.Corner.
Press Function > or Function < until the display
•
shows the current centre frequency response.
For example:
Press Function A or Function V to select the
•
appropriate option for the centre speaker.
An additional centre tilt offset option is also provided.
The centre tilt offset is added to the treble value for
the selected source. The recommended setting is -1dB
when the speaker is positioned above a television.
Press Function > or Function < until the display
•
shows the current centre tilt offset.
For example:
Press Function A or Function V to adjust the
•
centre tilt offset.
To store the settings
Once you have adjusted the frequency response for the
speakers in your system you should store the settings
using the following procedure:
• Press Function Store.
The display shows:
C.Free
C.Tilt+1
Store
• Turn off the DSP loudspeaker using the power switch
on the back panel.
When you turn on the power again the speaker will
operate normally with the frequency response settings
you have stored.
