Summary of Contents for Maytag MAV9504EWW
-
Page 1: Model Number
WASHER Repair Parts List MODEL NUMBER MAV9504EWW When requesting service or ordering parts, always provide the following information: - Product Type - Part Number - Model Number - Part Description ©2005 Maytag Services... - Page 2 Section: CABINET Model: MAV9504EWW LW12-109...
- Page 3 Section: CABINET Part No. Description Series Qty 22003086 CLIP, AIR DOME HOSE 22003461 PAD, PRESSURE SWITCH 22003298 RETAINER, WIRE 22004095 HINGE, PLASTIC 22001995 SCREW 22004053 LOWER INJECTOR, FLUME 22004361 UPPR INJECTOR/THERMOSTAT ASSY 22004251 WATER VALVE SHIELD 22003376 BRACKET, WATER VALVE Note: SCREW, VALVE TO BRACKET 22002960 STRAINER, WASHER INLET Y013783...
- Page 4 Section: TUB Model: MAV9504EWW LW13-78...
- Page 5 Section: Part No. Description Series Qty 22004043 AGITATOR/AUGER ASSY (AS PK) 21001510 SCREW Note: SCREW, TUB 22002933 SCREW 25-7948 SCREW, AGITATOR RETENTION 22003434 GASKET, HUB/BOTTOM ISOLATOR 35-3686 GASKET, TUB TO HOUSING 22003647 BOLT, SHOULDER,THREAD CUTTING 35-2328 SEAL, TUB TOP 22003285 HOSE, TUB TO PUMP 22003368 SPINNER TOP...
- Page 6 Section: TRANSMISSION Model: MAV9504EWW LW15-41...
- Page 7 Section: TRANSMISSION Part No. Description Series Qty 25-7941 "O" RING 21001065 SCREW,#10-24X.50 HXNIBHD Note: SCREW, STATOR 12001797 KIT, PULLEY & DUST CAP LA-2007 CAM REPLACEMENT KIT 21001533 SEAL NUT ASSEMBLY 35-2082 WASHER,1.25ODX.530IDX.062 Note: WASHER, FLAT 35-2132 WASHER,1.25ODX.530IDX.032 Note: WASHER, FLAT 21001515 BASKET HUB ASSEMBLY 25-7854...
- Page 8 Section: BASE Model: MAV9504EWW LW10-40...
- Page 9 Section: BASE Part No. Description Series Qty 22004376 SPRING, MOTOR PIVOT 21001506 PULLEY, MOTOR-60 HZ Note: FOR MOTORS BUILT BEFORE 8-18-03 21001950 MOTOR, 2SP 1/2HP 120/60 HI-TOR 22004297 PULLEY Note: FOR MOTORS BUILT AFTER 8-18-03 22002721 SHIELD, MOTOR 22002019 SCREW 22003438 SLEEVE, PUMP (ATL) 21001873...
-
Page 10: Supplemental Information
Section: SUPPLEMENTAL INFORMATION Part No. Description Series Qty 62620660 MANUAL, USE & CARE 22004369 GUIDE, ENERGY HANG TAG 22004362 HARNESS, WIRE - LOWER 22004403 WIRE HARNESS 22004366 HARNESS,WIRE - UPPER 22003061 CORD, POWER (AS WRAPPED) 211881 GROMMET, CORD 22003817 SCREW, SERRATED WASHER HEAD HX 22003512 INSULATION, CABINET 22003218... - Page 11 Section: CONTROL PANEL & TOP Model: MAV9504EWW LW11-169...
-
Page 12: Control Panel & Top
Section: CONTROL PANEL & TOP Part No. Description Series Qty 22003955 SWITCH SUPPORT 22003960 CONSOLE HOUSING (WHT) 22003938 SCREW, OVAL CTSK HD #8 22002754 PLUNGER 22002757 GUIDE TUBE 22003941 LID CAM (WHITE) 22004073 TIMER 22002751 HINGE PIN (WHT) 22004063 LID AS PACK PHASE III (WHT) 2016090 SCREW, LID SWITCH TO BRACKET 22003804... - Page 13 Section: WIRING INFORMATION Model: MAV9504EWW 15003495...
- Page 14 Section: WIRING INFORMATION Model: MAV9504EWW 15003609...
