1 2
Touchpad gestures
1. One finger slide or tap—point, move, click
• Pointer movement: Touch and slide finger to move screen pointer.
• Left click: Tap finger once for left-button mouse click.
• Double click: Tap finger twice (rapidly) for left-button, double click.
• Drag and drop: Tap, and then tap, hold, and slide finger to drag a screen object. Lift finger
to release.
2. Two finger swipe—vertical and horizontal scrolling
• Vertical scrolling: Swipe two fingers up or down. Flick (quick swipe) for continuous scrolling.
1
• Horizontal scrolling : Swipe two fingers left or right.
3. Three finger swipe—page navigation
2
• Page up and down : Swipe three fingers up to go up one page. Swipe down to go down
one page.
• Web page forward and back: Swipe three fingers right to go forward one page. Swipe left to go
back one page.
4. Four finger swipe—switch, minimize/restore, and snap
• Application switch: Swipe four fingers up to display window of open applications (similar to
Alt-Tab).
• Minimize/restore windows: Swipe four fingers down to minimize all open windows and to
display the desktop. Swipe down again to restore all windows
• Windows® 7 Snap: Swipe four fingers left to move and snap a window to the left screen edge.
Swipe right to move and snap a window to the right screen edge.
1 Horizontal scrolling is widely supported, but if it doesn't work in your application, download the free Logitech
SetPoint® Software at www.logitech.com/downloads, and try again.
2 Three finger swipe (page up and down) functions like the Page up and Page down keys on a keyboard. In some
applications, these keys don't always display the next page up or down when pressed.
Touchpad features
5. Left button click 3
Press the left button for left-button mouse click.
6. Right button click 3
Press the right button for right-button mouse click.
7. Battery LED
When the battery LED is green, the touchpad is on. When the LED turns red, replace the batteries.
3 To change button assignments, download the free Logitech SetPoint® Software at www.logitech.com/downloads.
This software also allows you to disable/enable touchpad gestures.
www.logitech.com/support
United States
What do you think?
Please take a minute to tell us. Thank you for purchasing our product.
www.logitech.com/ithink
3
7
5 6
+1 646-454-3200
4
The Logitech® Unifying receiver
Plug it. Forget it. Add to it.
Your new Logitech product ships with a
Logitech® Unifying receiver. Did you know you
can add a compatible Logitech wireless device
that uses the same receiver as your current
Logitech Unifying product?
Are you Unifying-ready?
If you have a Logitech wireless device
that's Unifying-ready, you can pair it with
additional Unifying devices. Just look for the
orange Unifying logo on the new device or
its packaging. Build your ideal combo. Add
something. Replace something. It's easy,
and you'll use only one USB port for up to
six devices.
Help with setup
• Is the touchpad powered on? If not, move the On/Off slider to the On position.
• Is the Unifying receiver securely plugged into a computer USB port? Try changing USB ports.
• If the Unifying receiver is plugged into a USB hub, try plugging it directly into a USB port on
your computer.
• Did you pull the battery tab? Check the orientation of the batteries inside the touchpad, or replace
the batteries. The touchpad uses two AA alkaline batteries.
• Remove metallic objects between the touchpad and the Unifying receiver.
• Try moving the Unifying receiver to a USB port closer to the touchpad.
• Try reconnecting the touchpad and Unifying receiver using the Logitech Unifying software. (Refer
to the Unifying section in this guide. The Unifying software is not required for touchpad gestures.)
Getting started is easy
If you're ready to pair your device(s) via
Unifying, here's what you need to do:
1. Make sure your Unifying receiver is
plugged in.
2. If you haven't already, download the
Logitech® Unifying software from www.
logitech.com/unifying.
3. Start the Unifying software* and follow the
onscreen instructions to pair the new wireless
device with your existing Unifying receiver.
*Go to Start / All Programs / Logitech / Unifying /
Logitech Unifying Software
