Wiring Diagram - SECO-LARM E-941SA-600 Manual

Wiring Diagram:

Bond Status Sensor:
The Bond Status Sensor checks
to make sure the door is closed,
and the electromagnet is locked.
LED Indicators:
Green Door is closed and locked
Red Door not closed and/or locked
Door in use / No power
Off
600PQ and 1K2P models ONLY
*NOTE: Connect switching devices like
push-to-exit switches between the
power source and the positive terminal
on the lock. Connecting switching
devices to the negative terminal may
cause a delay in unlocking.
Maximum Distance from Power Source to Electromagnetic Lock:
For a complete chart, please visit www.seco-larm.com
12VDC Minimum Wire Gauge:
Wire Length
Wire Gauge @ 500mA 20
24VDC Minimum Wire Gauge:
Wire Length
Wire Gauge @ 250mA 24
Note: E-941SA-300 is pre-wired.
Optional SECO-LARM Electromagnetic Lock Accessories:
Does not include armature plate
"Z" Brackets
Description
(includes 1 "L" Bracket)
600-lb.
E-941S-600/ZQ
Models
1200-lb.
E-941S-1K2/ZQ
Models
E-941S-1K2/ZRQ
Additional
(Right-side "Z" Bracket
Models
for E-941DA-1K2P)
Note: Brackets and spacers are not available for E-941SA-300.
SECO-LARM U.S.A., Inc.
(600PQ and 1K2P
models ONLY)
Voltage Selection Jumpers
Position two jumpers
on all four pins for
12VDC operation
25ft. 50ft. 75ft. 100ft. 150ft. 200ft. 250ft. 300ft. 400ft. 500ft. 1000ft.
18 18 18
25ft. 50ft. 75ft. 100ft. 150ft. 200ft. 250ft. 300ft. 400ft. 500ft. 1000ft.
24 22 20
"L" Brackets
E-941S-600/LQ
E-941S-1K2/PQ
E-941S-1K2/LQ
(for E-941DA-1K2P)
SECO-LARM
ELECTROMAGNETIC LOCK
Position a jumper over
the two middle pins for
24VDC operation
16 14 14
18 18 16
Glass Door
Plate Spacers
"U" Brackets
E-941S-600/PQ E-941S-600/UQ
E-941S-1K2/UQ
E-941D-1K2/P
Control
Device*
Power Supply
12 10 --
16 14 14 14
Armature
Plate Holders
E-941S-600/HQ
E-941S-1K2/HQ
--
7
