Positive Dome Light
Black/White
(-) DOME LIGHT
OUTPUT
Positive Horn Honk
Brown/White
(-) HORN OUTPUT
Negative Glow Plug
+12V
(-) GLOW PLUG
WIRE FROM
VEHICLE
Blue/Yellow Wire
Page 24 - VisionGuard 6000

Wiring Diagrams

TO POSITIVE
DOME LIGHT
+12V
TO POSITIVE
HORN WIRE
+12V
Yellow Wire
(+) IGNITION
(+) GLOW PLUG
INPUT
Negative Dome Light
TO NEGATIVE
DOME LIGHT
Black/White
(-) DOME LIGHT
OUTPUT
Negative Horn Honk
TO NEGATIVE
HORN WIRE
Brown/White
(-) HORN OUTPUT
Starter Defeat/Anti-Grind
Orange wire
(-) ANTIGRIND/
STARTER DEFEAT
IGNITION SWITCH
+12V
+12V
Yellow Wire
(+) IGNITION
Violet Wire
(+) STARTER
TO STARTER
