Summary of Contents for Scytek electronic 600
- Page 1 6 6 0 0 0 0 S S E E R R I I E E S S VEHICLE SECURITY SYSTEM PRODUCT MANUAL...
- Page 2 Limited L L ifetime W W arranty This vehicle security system is warranted to the original purchaser, to be free from defects in material and workmanship. The manufacturer will repair or replace at its option, and free of charge for the first twelve (12) months, any part that proves defective in material or workmanship under normal installation, use, and service, provided the product is returned to the manufacturer freight prepaid.
-
Page 3: Table Of Contents
About Your System ........... .Page 1 Remote Transmitters . -
Page 5: About Your System
· Power Trunk / Hatch Release · Glass Breakage Sensor · Radar Sensor · Auxiliary Lighting Control · Stereo System Valet · Remote Head Lamp Control · Back-up Battery Siren PLEASE NOTE: Additionally, many features of this security system have Astra 600 - Page 1... -
Page 6: Remote Transmitters
Remote Transmitter Description Button 1 Button 3 The Astra 600 is supplied with two 5-button Remote Transmitters used to control system operations. Button 1 Arms the system and when held for 2 seconds, activates the system’s Panic feature. Button 1 also locks the doors when the system is in Valet Mode. -
Page 7: Adding/Replacing Transmitters
6. Turn off the ignition key. Two Car Operation If two vehicles are equipped with Astra 600 systems, for convenience both can be operated using the same remote transmitter. If all four transmitters are to be used with both cars, program transmitters A and B into the first vehicle in the manner described above. -
Page 8: System Operation
* During Disarming, if the system was triggered while away from the vehicle, the siren will chirp 3 times, the parking lights will flash 3 times, and the LED will flash to indicate triggered zone. See Tamper Alert for zone listing. Page 4 - Astra 600 System O O peration... -
Page 9: Tamper Alert
Note: If the Passive Arming feature is enabled, the Automatic Rearming feature will also be enabled even if it was not already programmed. optional sensor shock sensor not used door trunk main power interrupt or system was reset Astra 600 - Page 5... -
Page 10: Panic Mode
3. Press the valet switch 3 times. · The siren will chirp each time the valet switch is pressed. 4. Within 5 seconds, press Button 3 on the transmitter. · The siren will chirp 3 times. Page 6 - Astra 600... -
Page 11: Automatic Rearming
· The siren will chirp twice to confirm the Valet Mode is off. 3. Turn off the ignition. While in Valet Mode the remote transmitters will continue to lock and unlock the doors, and operate the optional auxiliary functions. Astra 600 - Page 7... -
Page 12: Extended Features
Auxiliary Function Outputs The Astra 600 system is equipped with 3 Auxiliary Outputs allowing the convenience features of the system to be further expanded. These outputs can be used to add a number of optional features such as: power trunk release, remote engine start, power window activation, power sunroof control, and more. -
Page 13: System Installation
3. Verify with the owner, the mounting locations for all visible components, including the LED and Override switch. 4. Verify with the owner, the optional features of the Astra 600 and the features that must be programmed during installation. 5. Inspect and perform a function test of all vehicle systems before and after the installation. -
Page 14: Mounting The Control Unit
During proper operation, the shock sensor will detect impacts to the vehicle only and will not usually be triggered by slow rocking movements of the vehicle like those caused by wind. Page 10 - Astra 600 Do not mount the... -
Page 15: System Wiring
Pin 3 BLUE WIRE: Unlock Relay Pin 30 (Common). Pin 4 BROWN WIRE: Unlock Relay Pin 87a (Normally Closed). Pin 5 VIOLET WIRE: Lock/Unlock Relays Pin 87 (Normally Open) [10A Fuse]. System W W iring Astra 600 - Page 11... -
Page 16: Starter Defeat Conncectors
2-Pin Blue Connector: Plug-in connector port for valet switch. Mount the valet switch in an area that is easily accessible from the driver’s position. 4-Pin White Connector 1: Plug-in connector port for dual stage shock sensor. 4-Pin White Connector 2: Plug-in connector port for dual stage radar sensor. Page 12 - Astra 600... -
Page 17: Jumper Settings
Auxiliary 1 Output. Selects the polarity (+/-) for the output of the on-board Aux 1 relay. Left Pin + Center Pin = positive Right Pin + Center Pin = negative Dome Light Auxiliary 1 Relay Jumper S S ettings Relay default settings shown Parking Light Relay Lock Relay Astra 600 - Page 13... -
Page 18: System Programming
The following is a description of the programming options. Some program branches control more than one option, and may require accessing a particular branch number twice in order to program all desired features. Page 14 - Astra 600 System P P rogramming... - Page 19 Full-Time. When selected, the Anti-Carjacking feature will automatically activate each time the ignition is turned on. 13. Anti-Carjack Mode. Enables Anti-Carjacking protection. 14. Ignition Armed Mode. When enabled, the security system may also be manually armed and disarmed using the transmitter, while the ignition is on. Astra 600 - Page 15...
-
Page 20: Door Lock Diagrams
Brown wire Violet wire Reverse Polarity White wire Green wire Blue wire Brown wire Violet wire +12V Page 16 - Astra 600 Door L L ock D D iagrams FACTORY DOOR LOCK MODULE DOOR LOCK SWITCH NOT USED NOT USED... -
Page 21: Two Stage Door Lock Diagrams
Two S S tage D D oor L L ock D D iagrams The Astra 600 is equipped with a dedicated Passenger Unlock output allowing Two Stage Door Lock operation. When connected as shown below, disarming the system will unlock only the driver’s door. - Page 22 Violet wire Blue/white wire (-) PASSENGER UNLOCK White wire Green wire Blue wire Brown wire Violet wire Page 18 - Astra 600 Two Stage Reverse Polarity 15A FUSE +12V DRIVER DOOR MOTOR FACTORY +12V DOOR LOCK Two Stage Adding Actuators...
-
Page 23: Technical Information
Operation is subject to the following two conditions: 1) This device may not cause harmful interference. 2) This device must accept any interference received, including interference that may cause undesired operation Technical I I nformation Astra 600 - Page 19... -
Page 24: Wiring Diagram
Armed output (-) Auxiliary 2 outout (-) Hood/Trunk input (-) Unlock relay 87a (Normally Closed) Lock relay 30 (Common) Unlock relay 30 (Common) Lock relay 87a (Normally Closed) Lock/Unlock relays 87 (Normally Open) Starter Defeat Starter Defeat Astra 600 r1 11/02...
