Korg Kaossilator Pro Owner's Manual page 19

4. To view the contents of the KAOSSILATOR
PRO's card, open the drive that was added to
your computer in step 2.
Copy the desired data onto your computer.
You can also copy data from your computer
onto the card.
5. Exit USB mode.
In Explorer or My Computer, right-click the
"Removable Disk" icon and choose "Remove."
Then press the KAOSSILATOR PRO's SHIFT
button to exit USB mode.
When you're ready to disconnect the KAOSSILATOR
PRO from your computer, you must first exit USB mode and
then disconnect the USB cable.
MacOSX users (OSX 10.4 or later)
1. Use a USB cable to connect the KAOSSI-
LATOR PRO to your computer.
Plug the USB connector into the KAOSSILA-
TOR PRO's USB connector. Make sure that
the connector is oriented correctly, and insert
it as far as it will go.
2. Hold down the SHIFT button and press the
PROGRAM MEMORY 7 (USB) button.
The display will indicate "buSy."
3. The drive name of the card in the card slot
will appear on your computer.
While this screen is shown, you must not disconnect
the USB cable, remove the card from the slot, or switch the
power of your computer on or off. Doing so may damage
the data.
4. To view the contents of the KAOSSILATOR
PRO's card, open the drive that was added to
your computer in step 2.
Copy the desired data onto your computer.
You can also copy data from your computer
onto the card.
5. When you're ready to disconnect the KA-
OSSILATOR PRO, drag the drive from the
desktop into the Trash.
Then press the KAOSSILATOR PRO's SHIFT
button to exit USB mode.
When you're ready to disconnect the KAOSSILATOR
PRO from your computer, you must first exit USB mode and
then disconnect the USB cable.
About the contents of the card
The following files and folders will be created
in the root directory of the card.
Files you can save
LOOP REC Data
GLOBAL
PROGRAM MEMORY Set
All Data
Files you can load
LOOP REC Data
GLOBAL
PROGRAM MEMORY Set
All Data
TIP: If an All data file named "0.KOA" exists on the
card, this file will automatically be loaded when you
start up the KAOSSILATOR PRO.
TIP: The WAVE or AIFF files that can be loaded must
be 8/16-bit linear PCM mono or stereo files. Data that
is other than 16-bit will be handled by discarding the
bits below 16 bits or by filling the lacking bits with
zeros. You must place the files in the root folder of
the SD card.
TIP: Since WAVE and AIFF files do not contain the
tempo or length settings needed for playback on the
KAOSSILATOR PRO's loop recorder, the tempo and
length will automatically be set to appropriate values
when the file is loaded. If the data is longer than can
be recorded in one bank, it will be truncated. If the
data is shorter than can be recorded in one bank, the
remaining length will be handled as silence.
00–99.KOS
0–9.KOG
0–9.KOP
0–9.KOA
00– 99.KOS
00– 99.WAV
00–99.AIF
0–9.KOG
0–9.KOP
0–9.KOA
19
