Rolodex RF-3A User Manual

Personal organizer
Hide thumbs
Table of Contents

Advertisement

Quick Links

RF-3a/RF-48a
Personal Organizer
Organizador Personal
User's Guide
Manual del usuario

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RF-3A and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Rolodex RF-3A

Summary of Contents for Rolodex RF-3A

  • Page 1 RF-3a/RF-48a Personal Organizer Organizador Personal User’s Guide Manual del usuario...

  • Page 2: Table Of Contents

    Table of Contents License Agreement ........2 Notice ............3 Getting Started ..........4 Using the Clocks ......... 7 Setting the Alarms ........10 Using the Telephone Directories ..... 12 Using the Scheduler ......... 14 Using the Memo Directory ....... 16 Searching and Editing Records ....

  • Page 3: License Agreement

    License Agreement READ THIS LICENSE AGREEMENT BEFORE USING THE ELECTRONIC REFERENCE. YOUR USE OF THE ELECTRONIC REFERENCE DEEMS THAT YOU ACCEPT THE TERMS OF THIS LICENSE. IF YOU DO NOT AGREE WITH THESE TERMS, YOU MAY RETURN THIS PACKAGE WITH PURCHASE RECEIPT TO THE DEALER FROM WHICH YOU PURCHASED THE ELECTRONIC REFERENCE AND YOUR PURCHASE PRICE WILL BE REFUNDED.

  • Page 4: Notice

    Notice Recommendations • The manufacturer strongly recommends that separate permanent written records be kept of all important data. Data may be lost or altered in virtually any electronic memory product under certain circumstances. Therefore, the manufacturer assumes no responsibility for data lost or otherwise rendered unusable whether as a result of improper use, repairs, defects, battery replacement, use after the specified battery life has expired, or any other...

  • Page 5: Getting Started

    Getting Started Using the Organizer for the First Time The first time you use this organizer, you should perform a system reset. Warning! A system reset erases any user-entered information and clears all settings. 1. Turn the organizer over and carefully pull the battery insulation sheet to remove it.
  • Page 6 Getting Started 1. Press 2000-09-20 A 12-00 Indicates Home Time mode. 2. Press ALT + L. ENGLISH 3. Press (Search up) or (Search down) to cycle through English, Nederlands (Dutch), Português (Portuguese), Italiano (Italian), Deutsch (German), Français (French), and Español (Spanish).
  • Page 7 Key Guide Combination Keys Press and release ALT before pressing the next key. is displayed. To lock ALT, press it twice. indicates that the keys are now shifted. Toggles times between 12- and 24-hour time (12/24) displays. Selects the alarm clock and then cycles through the daily, hourly, and reminder alarms to activate/deactivate them.

  • Page 8: Using The Clocks

    Using the Clocks The clock lets you set a Home time and view local times around the world. You should set the Home time before viewing the World times or using the Schedule, because World times are based on Home time. Setting Home Time 1.
  • Page 9 Using the Clocks 5. Press and enter the date and Home time. For example, to enter 2000-09-25, 10:15 p.m., type 200009251015 . M O N 2000-09-25 A 10-05-00 6. Press ENTER to confirm your settings.

  • Page 10: Setting World Time

    Using the Clocks Setting World Time 1. Press ) until the World time screen TIME appears. The absence of a indicates the World time screen. There are 40 built-in cities of different zones. 2. Use to cycle (Search up) or (Search down) through the list of cities and view their corresponding times.

  • Page 11: Setting The Alarms

    Setting the Alarms There are three kinds of alarms: the daily alarm, indicated by , the hourly chime, indicated by , and the Schedule alarm, indicated by Setting the Daily Alarm 1. Press and then SET. ALARM SET A 12-00 2.
  • Page 12 Setting the Alarms Setting the Hourly Chime 1. Press 2. Press C ( ) until is displayed. ALARM SET P 10-15 Press C ( ) to cycle through four alarm selections: Alarm Icon No alarm No icon Hourly chime Daily alarm Schedule alarm Hourly chime, daily alarm and Schedule alarm...

  • Page 13: Using The Telephone Directories

    Using the Telephone Directories There are two telephone directories, a Business phone directory and a Personal phone directory. There are five fields in each telephone directory: Name, Address, E- mail, URL and Number. Entering a Phone Record 1. Press to enter a personal telephone record. Press to enter a business telephone record.
  • Page 14 Using the Telephone Directories Note: If the display exceeds 12 characters, it begins to scroll to the left and the cursor ( ) appears. 3. Press to enter the Address. 4. Press to go to the next field. 5. Type an E-mail and URL address. You can type up to 36 characters in each field.

  • Page 15: Using The Scheduler

    Using the Scheduler In each schedule record, you can enter the name and type of event and the date and time when the event is going to occur. Entering a Schedule Record 1. Press SCHEDULE? 2. Type the name of the event. For example, type STAFF MEETING.

  • Page 16: Gauging The Memory

    Using the Scheduler 4. Press ENTER to store the data. When the schedule alarm is set, the alarm will sound at the time of the appointment. The organizer will turn on (if it was off), displaying the relevant schedule record. To turn the alarm off, press ALT and then .

  • Page 17: Using The Memo Directory

    Using the Memo Directory You can enter three lines of data in a memo record. You can type a maximum of 36 characters including letters, numbers and symbols on line one, and 36 numbers each on lines 2 and 3. Entering a Memo Record 1.

  • Page 18: Searching And Editing Records

    Searching and Editing Records Telephone and Memo records are listed alphabetically. Schedule records are listed in chronological order. You can search for them either directly or sequentially. You can review your records, edit them or delete them. Searching for a Record 1.

  • Page 19: Editing A Record

    Searching and Editing Records 3. Press to view other fields in a record. Editing a Record 1. Find the record you want to edit. To learn how, read "Searching for a Record". 2. Press ALT and then (Edit/Ins). 3. Move the cursor to the character you want to edit. 4.

  • Page 20: Using A Password

    Using a Password You can have a secret area in your organizer by setting a password in the Telephone, Memo and Schedule mode. Warning: Please keep written records of your data. If you forget your password, you will not be able to recover any of the data stored in your organizer.
  • Page 21 Using a Password Entering Confidential Data Make sure that the key icon is not displayed on the screen before you begin to type your confidential data. 1. Select the directory you want and type your data. 2. Press SET ( 3.

  • Page 22: Using The Calculator

    Using the Calculator Making a Calculation 1. Press until the Calculator screen appears. 2. Type a number. You can type up to 10 digits. To type a decimal, press O (.). To clear a number, press C/Ce. 3. Press I (+), U (-), Y (x) or T ( ) to add, subtract, multiply, or divide, respectively.

  • Page 23: Using The Calculator Memory

    Using the Calculator Using the Calculator Memory 1. In the Calculator, make a calculation or type a number. 2. To add the number on the screen to the number stored in memory, press R ( +). To subtract the number on the screen from the number stored in memory, press E ( M indicates the number is stored in memory.

  • Page 24: Using The Converter

    Using the Converter Doing Metric Conversions Use your organizer to do the following built-in conversions: Inches Centimeters Yards Meters Miles Kilometers Feet Meters Ounces Grams Pounds Kilograms US gallons Liters UK gallons Liters 1. Press until the Converter screen appears. INCH 2.54 2.
  • Page 25 Using the Converter Creating Custom Conversion Rates You can enter your own units and conversion rates, to do currency conversions. For example: 1. Press until the Converter screen appears. 2. Press (Search up) or (Search down) till you see the following screen: EURO 3.
  • Page 26 Using the Converter Doing Euro Currency Conversions Once you have set the conversion rates, you can do currency conversions. 1. Press until the Converter screen appears. EURO 13.7603 2. Press (Search up) or (Search down) to select a conversion category. 3.

  • Page 27: Replacing The Battery

    Replacing the Battery This organizer uses one CR2032, 3-volt lithium battery. Before you follow these steps you should have a small Phillips screwdriver and the new battery at hand. Warning! When no battery is installed, this organizer will save your information for only about 30 seconds. So quickly install the new battery when you remove the old one.

  • Page 28: Specifications

    Specifications Model RF-3a (Mfg#00EX) Size: 11.5 x 9.0x1.0 cm • Weight: 3 oz. Battery: 0ne CR2032 lithium • Storage capacity: 3 KB ISBN 1-56712-526-3 Model RF-48a (Mfg#00EX) Size: 11.5 x 9.0x1.0 cm • Weight: 3 oz. Battery: 0ne CR2032 lithium • Storage capacity: 48 KB...

  • Page 29: Limited Warranty (U.s. Only)

    Limited Warranty (U.S. only) LIMITED WARRANTY, DISCLAIMER OF WARRANTIES AND LIMITED REMEDY (A) LIMITED WARRANTY. FRANKLIN WARRANTS TO THE ORIGINAL END USER THAT FOR A PERIOD OF ONE (1) YEAR FROM THE ORIGINAL DATE OF PURCHASE AS EVIDENCED BY A COPY OF YOUR RECEIPT, YOUR FRANKLIN PRODUCT SHALL BE FREE FROM DEFECTS IN MATERIALS AND WORKMANSHIP.

  • Page 30: Fcc Notice

    FCC Notice NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.

This manual is also suitable for:

Rf-48a
