JUKI MB-1373 Instruction Manual
Hide thumbs Also See for MB-1373:

Advertisement

ENGLISH
INStructIoN MaNuaL


Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MB-1373 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for JUKI MB-1373

  • Page 1 ENGLISH INStructIoN MaNuaL...
  • Page 2: Table Of Contents

    coNtENtS 1. SPEcIFIcatIoNS ......................1 2. PrEParatIoN oF tHE SEWING MacHINE ..............1 2-1. Installation ............................1 2-2. Lubrication ............................2 2-3. attaching the needle .......................... 2 2-4. attaching the needle bar cover ......................3 2-5. attaching the button tray assembly ....................3 2-6.
  • Page 3: Specifications

    0 to 28 mm Needle used TQx #6 (#4 to #20) TQx7 #6 (#4 to #20) Lubricating oil JUKI New Defrix Oil No.  Noise - Equivalent continuous emission sound pressure level (L ) at the workstation : A-weighted value of 84 dB; (Includes K = 2.5 dB);...
  • Page 4: Lubrication

    1) Open the sde cover, and apply JUKI New Defrx Ol No. 1 to the portons shown by the red marks 1 to !2 ( 7 : MB-1377 only).
  • Page 5: Attaching The Needle Bar Cover

    2-4. attaching the needle bar cover WarNING : to protect against possible personal injury due to abrupt start of the machine, be sure to start the following work after turning the power off and ascertaining that the motor is at rest. 1) Loosen screw 2 and remove thread gude 3 .
  • Page 6: Adjustment Of The Sawing Machine

    3. aDJuStMENt oF tHE SaWING MacHINE 3-1. thread tension adjustment Tenson post No. 1 1 s used to adjust the thread tenson to sew on the button and a relatvely low tenson wll be enough. Tenson post No. 2 2 s used to adjust the thread tenson appled to the root of the button sewng sttches.
  • Page 7: Adjusting The Nipper

    3-4. adjusting the nipper WarNING : to protect against possible personal injury due to abrupt start of the machine, be sure to start the following work after turning the power off and ascertaining that the motor is at rest. 1) Provde a 0.4 to 0.6 mm clearance between npper block 2 and npper 1 to prevent the npper 1 from hold- ng the thread whle the machne s n...
  • Page 8: Position Of The Needle Guide

    3-7. Position of the needle guide WarNING : to protect against possible personal injury due to abrupt start of the machine, be sure to start the following work after turning the power off and ascertaining that the motor is at rest. Loosen screw 2 and provde a 0.05 to 0.1 mm clear- ance between the needle gude 1 and the needle by movng the needle gude 1 to the left or the rght...
  • Page 9: Timing Of Thread Tension Release

    n a button and set equally cross- wse and lengthwse feed regulators for 4-hole buttons. [In case of MB-1377] [In case of MB-1373] ★ Lengthwise feed ★ Lengthwise feed Push down lengthwse feed adjustng lever 1 and set t to "0" for -2-hole...
  • Page 10: Setting A Number Of Stitches

    3-13. Setting a number of stitches WarNING : to protect against possible personal injury due to abrupt start of the machine, be sure to start the following work after turning the power off and ascertaining that the motor is at rest. To change the number of sttches, open the left-hand sde cover and change the number of sttches usng sttch number adjustng screw 1 and sttch number adjustng lever 4 (optonal).
  • Page 11: Automatic Thread Trimmer

    3-15. automatic thread trimmer (1) adjusting the position of the moving knife WarNING : to protect against possible personal injury due to abrupt start of the machine, be sure to start the following work after turning the power off and ascertaining that the motor is at rest. When the presser has completely lfted at the stop- "3-14.
  • Page 12: Knot-Tying Mechanisms

    3-18. Knot-tying mechanisms WarNING : to protect against possible personal injury due to abrupt start of the machine, be sure to start the following work after turning the power off and ascertaining that the motor is at rest. (1) adjusting the knot-tying connecting plate Loosen screws 1 and adjust so that a clearance of 1 to 1.5 mm s provded between the needle 2 and the knot tyng plate 3 when the roller of the knot-...
  • Page 13: Changeover Of WTh/WThout Knot-TyNg

    2. take care not to allow the belt to be clogged with oil when assembling it. 4-2. Subclass models MB-1373 MB-1373-11 8, 16, 32 sttches 8, 16, 32 sttches – 11 –...
  • Page 14: Attachments

    MB-373NS and that of MB-377NS is button clamp lifting hook 5 . Flat buttons Shank buttons Snaps Large-sze Medum-sze General MB-1373 Z201 Z202 Z033 Z037 MB-1377 Schematc drawng Remarks Button sze :...
  • Page 15: Attachments For Shank Buttons (Pearl Buttons) (Z033)

    (1) attachments for shank buttons (Pearl buttons) (Z033) WarNING : to protect against possible personal injury due to abrupt start of the machine, be sure to start the following work after turning the power off and ascertaining that the motor is at rest. (INStaLLatIoN) Remove both the button clamp mechansm assem- bly and the feed plate from the machne and nstall...
  • Page 16: Attachment For The Second Process Of Wrapped-Around Buttons (Z035)

    (3) attachment for the second process of wrapped-around buttons (Z035) WarNING : to protect against possible personal injury due to abrupt start of the machine, be sure to start the following work after turning the power off and ascertaining that the motor is at rest. (INStaLLatIoN) (Z035) Remove the button clamp mechansm assembly, but-...
  • Page 17: Attachment For Metal Buttons (Z038)

    (5) attachment for metal buttons (Z038) WarNING : to protect against possible personal injury due to abrupt start of the machine, be sure to start the following work after turning the power off and ascertaining that the motor is at rest. (INStaLLatIoN) Remove both the button clamp mechansm assem- bly and the feed plate from the machne and nstall...
  • Page 18: Troubles And Corrective Measures

    5. trouBLES aND corrEctIVE MEaSurES TROUBLES CAUSES CORRECTIVE MEASURES 1. Thread breakage 1 The yoke slde does not move n the correct ™ Adjust the tmng of forward, backward and way. sdeways of the yoke slde. 2 The tenson lever has been mproperly ™...

This manual is also suitable for:

Mb-1377
