The iMcV-FiberLinX-II module is a single-slot chassis-mounted module.
Compatible chassis include the following:
•
iMediaChassis series
•
MediaChassis series
•
IE-MediaChassis series

Port Interfaces

Every iMcV-FiberLinX-II includes the following ports:
•
One 10/100 twisted pair (RJ-45) data port
•
One additional 10/100 twisted pair port (EXT MGMT) for management (can
also function as a serial port)
And one of the following uplink ports:
•
One 100 Mbps Fiber
•
One additional 10/100 twisted pair (RJ-45)
•
One SFP port (requires one SFP/155-ED Module)
You can easily configure the iMcV-FiberLinX-II by using either the serial craft port
connection, through SNMP management application such as iView² or a Telnet
session.
Craft Serial Port Connection
The iMcV-FiberLinX-II includes a serial port on the unused pins of the EXT MGMT
Ethernet port. Connect a local management PC using the included RJ-45 to DB-9
adapter. This RS-232 serial connection provides access to the iMcV-FiberLinX-II
module configuration screens. These configuration screens are also accessible from a
Telnet connection.
