Generac Power Systems GP17500E GP SERIES Specification

GP17500E
A/C Rated Output Watts 17,500
A/C Maximum Output Watts 26,250
Model 5735
UPC Number: 696471057355
Emissions Certification: 49-State
features
• GENERAC OHVI ENGINE, FULL PRESSURE
LUBRICATION
• HIGH PERFORMANCE ALTERNATOR
• LARGE CAPACITY FUEL TANK FOR EXTENDED
RUN TIME
• IDLE CONTROL
• CIRCUIT BREAKER PROTECTED OUTLETS
• BUILT-IN LIFTING EYE
• HEAVY DUTY, FIXED HANDLES
• 12.3" PNEUMATIC WHEELS
• 1.25" HARDENED STEEL TUBE CRADLE
• LOW TONE MUFFLER
Commercial/Residential
Portable Generators
customer connections
Outlets
A (1) Duplex 5-20R GFCI
B (1) Duplex 5-20R 120V
C (2) L5-30R
D (1) L14-30R
E (1) 12VDC
F (1) 14-50R
O
H
E
12Vdc
CONTROL
ON
10A
CIRCUIT BREAKERS - PUSH TO RESET
120V/240V
30A
F UNDERNEATH PANEL
®
GP SERIES
Circuit Breakers
M (2) 20A
N (4) 30A
O (1) 50A
Other Features
H Hour Meter
I Idle Control Switch
I M
B A
20A
GFCI
TEST RESET
IDLE
TEST RESET
20A
OFF
120V 120V
20A 20A
GFCI
120V
30A
30A 30A
120V
30A
30A 30A
D N C
1 of 2
