Generac Power Systems Stationary emergency generator Owner's Manual page 38

EXPLODED VIEW: EV CONBOX C2 CPL
DRAWING #: 0J8319
APPLICABLE TO:
ITEM PART#
A 0G5250
B 0H7356
C 0F4186AGS0R
D 0F8432A
E 0H7311
F 045771
G 036261
H 0C2454
J 053640
K 038150
L 022264
M 022471
N 049897
P 022129
R 022145
S 058306
T 0F8843
U 0F8451
V 0G3259
(6)W 0J78740ST0R
X 0J7872
Y 0E3257
A 0F4153
B 0H6735
C 0A7822
D 0H6734
E 042419
F 022097
G 052647
H 0C2454
J 046526
K 023897
L 022152
M 022158
N 023334
P 022473
Q 0G3259
(6)R 0J7874AST0R
S 0J7872
T 0E3257
(1) ITEMS INCLUDED WITH HARNESS P/N 0H6692.
(2) ITEMS INCLUDED WITH NEUTRAL BLOCK P/N 0D5464B.
(3) ITEMS INCLUDED WITH 4.2L MODELS ONLY.
(4) SEE "C2 DPE BREAKER SELECTION" TABLE.
(5) QTY. REQ. FOR 2 POLE BREAKER / QTY. REQ. FOR 3 POLE BREAKER.
(6) SHEET METAL PARTS LISTED IN THE BOM TABLE ARE REPRESENTING GENERIC PARTS (NO COLOR)
MANUFACTURING: FOR CORRECT MATERIAL AND COLOR REFER TO AS400 BOM.
•
CUSTOMER: WHEN ORDERING REPLACEMENT PARTS ENTER BASE NUMBER (FIRST 6 DIGITS ONLY) IN THE
•
SYSTEM FOR CORRECT MATERIAL AND COLOR (FOR REFERENCE SEE GUIDELINE 0H7169).
(7) ITEMS INCLUDED WITH 5.4L MODELS ONLY.
REVISION: -A-
DATE: 1/25/12
QTY. DESCRIPTION
UL CIRCUIT BREAKER (225AF)
1 CB 175A 2 POLE 240V 225AF
1 COVER CB C2 CPL
1 COVER CB DISH 2P G 225AF
1 INSULATOR CB 2P 225AF
1 STANDOFF CB BOX CONBOX
2 NUT HEX M8-1.25 G8 CLEAR ZINC
4 RIVET POP .125 X .275 SS
12 SCREW HWHT M6-1 X 16 N WA Z/JS
2 SCREW RHM #8-32 X 3-1/4
2 WASHER FLAT #8 ZINC
2 WASHER LOCK #8-M4
2 NUT HEX #8-32 STEEL
4 SCREW SHC M8-1.25 X 20 G8
6 WASHER LOCK M8-5/16
4 WASHER FLAT 5/16-M8 ZINC
2 SCREW SHC M8-1.25 X 25 C12.9
2 BUS BAR 200A LUG ADAPTOR
2 LUG SLDLSS 300 MCM-6 AL/CU
1 DECAL TERMINAL SHOCK HZD BI
1 SHIELD-SM CIRCUIT BREAKER
1 GASKET-CB SHIELD C2
2 SCREW HWHTF M6-1.0 X 16
UL CIRCUIT BREAKER (400AF)
1 CB 0250A 3P 480V G 400AF
1 COVER CB 400AF C2 CONBOX
3 LUG SLDLSS 600/250-1/0X1/4-28
1 STANDOFF CB MOUNT CONBOX
4 SCREW RHM 10-32 X 4
6 WASHER LOCK M6-1/4
6 SCREW SHC M10-1.5 X 25 C12.9
12 SCREW HWHT M6-1 X 16 N WA Z/JS
6 WASHER LOCK M10
4 WASHER FLAT #10 ZINC
4 WASHER LOCK #10
4 NUT HEX #10-32 STEEL
6 SCREW HHC 1/4-28 X 1/2 G5
6 WASHER FLAT 1/4-M6 ZINC
1 DECAL TERMINAL SHOCK HZD BI
1 SHIELD-LGE CIRCUIT BREAKER
1 GASKET-CB SHIELD C2
2 SCREW HWHTF M6-1.0 X 16
GROUP A
Page 5 of 8
