Generac Power Systems Stationary emergency generator Owner's Manual page 31

EXPLODED VIEW: EV ALTCOMPRT DIRECT B-CAN
DRAWING #: 0J5599A
ITEM PART#
1 0G1931
0G2101
0G6568
0G6570
2 0G1932
0G2098
0G2099
0G2100
0G6365
0G6569
0G6571
0G6572
0H1299
0H1300
0H1301
0J5243
0J5427
0J6268
0J6269
3 0C9708
4 SEE ENGINE EV
5 SEE ENGINE EV
6 0F5767B
7 0E5706
8 0F7874
0F7874A
(6) 0J7347
(6) 0J7347A
9 077043A
10 038150
11 023454
12 077043J
13 04576100BU
(5) 04576100BF
14 052646
15 043123
16 051779
(2) 17 0A2601
18 072879
(2) 19 059980
20 046526
21 0C3993
22 022264
(1) 23 047248
(1) 24 070892
(3)25 0J7077
(6)(7) 0J7348
(3)26 0J7077A
(3)27 0J7007
(3)28 0J7086
(3)29 0C2454
(3)30 052250
REVISION: J-1544-B
DATE: 2/3/12
QTY. DESCRIPTION
1 ROTOR 25KW 3PH DIRECT 390 1800
1 ROTOR 25KW 1PH DIRECT 390 1800
1 RTR 390 45AD1 CPL
1 RTR 390 45KD1 CPL
1 ASSY STR 390 25 GD1 CPL
1 ASSY STR 390 25AD1 CPL
1 ASSY STR 390 25KD1 CPL
1 ASSY STR 390 25JD1 CPL
1 STR 390 45JD1 CPL
1 STR 390 45AD1 CPL
1 STR 390 45GD1 CPL
1 STR 390 45KD1 CPL
1 ASSY STR 390 36AD1 CPL
1 ASSY STR 390 36JD1 CPL
1 ASSY STR 390 36 GD1 CPL
1 STR 390 48GD1 CPL
1 STR 390 48AD1 CPL
1 STR 390 48JD1 CPL
1 STR 390 48KD1 CPL
REF INSTR HYPOT TEST (NOT SHOWN)
REF ENGINE ADAPTER
REF FLEXPLATE
1 ASSY FLYWHEEL CPL W/40MM FAN B
1 REAR BEARING CARRIER 390/DRCT
1 ASSY BRUSH HOLDER 390/HSB
1 ASSY BRUSH HOLDER 390/HSB
1 ASSY BRUSH HOLDER 390/HSB
1 ASSY BRUSH HOLDER 390/HSB
1 CONDUIT FLEX .38" ID (60")
4 WASHER FLAT #8 ZINC
1 KEY WOODRUFF #E
1 CONDUIT FLEX 2.0"ID (35" LG)
4 STUD M14-2.0 570 G5 ZINC
4 STUD M14-2.0 X 540 G5 ZINC
4 WASHER FLAT M14
4 WASHER LOCK M14
4 NUT HEX M14-2.0 G8 YEL CHR
1 SCREW HHC M16-2.0 X 45 G8.8
1 SPACER .69 X 2.75 X .37 ST/ZNC
4 SCREW HHC M10-1.5 X 25 C10.9
4 WASHER LOCK M10
4 SCREW HHTT M4-0.7 X 25 BP
4 WASHER LOCK #8-M4
1 BALL BEARING-45 MM
1 SLIP RING MACHINED
1 BLOCK OFF, ALTERNATOR AIR
1 BLOCK OFF, ALTERNATOR AIR QTA
2 BLOCK OFF, ALT AIR LH/RH
1 BAFFLE-ALT INLET
1 PLATE LEAD CLAMP
19 SCREW HWHT M6-1 X 16 N WA Z/JS
1 TAPE FOAM 1X1 (166" LG)
GROUP A
