EXPLODED VIEW: ENGINE COMMON PRT 2.4L G2 TURBO 36K
DRAWING #: 0H7321
APPLICABLE TO:
ITEM PART#
73 052265
74 0H07280ST03
75 0H0723BST03
76 084750
77 045772
78 0F3217
(1) SUPPLIED WITH ENGINE.
(2) APPLY MEDIUM STRENGTH BLUE THREAD LOCKING FLUID TO THE THREADS.
REVISION: H-8507-E
DATE: 3/17/11
QTY. DESCRIPTION
1(REF) SCREW HHC M8-1.25 X 65 C8.8
1 BRKT-EXH MANF 2.4L 36KW
1 LWR BRKT ASM HT SHIELD G2 36KW
4 PLUG SPARK
1 NUT HEX M10-1.5 G8 YEL CHR
1 SPACER DC ALTERNATOR PULLEY
GROUP D
Page 4 of 4
