Self-Cleaning Oven
Stainle,ss Sled I;ange
BefoTe a
clean cycle
The range must be completely cool in order to
set the self-clean cycle.
We recommend venting with an open window
or using a ventilation f_m or 11oo(t during the
first self:clean cycle.
Remove all cookware and any aluminum foil
from tile oven.
Remove tile oven shelves and shelf slide
assembly.
Make sure the oven light bulb cover is in place
and the oven light is off.
Do not use commercial oven cleaners or oven
protectors in or near the self-cleaning oven.
O_en
shelf slide
assembly
An interlock system has been designed so that
the self:clean cycle will not start until the shelf
slide assemblies hm_e been removed.
Tile roller-assisted shelf supports are designed
to withstand standard baking temperatures.
They will not withstand tile extreme
temperatures of self:cleaning.
To remove the slide assemblies:
1 Loosen tile retaining screws on both sides of
tile oven.
2 Lift up slightly and pull tile entire assembly
out. Set aside.
To replace the slide assemblies:
When self:cleaning is finished, and tile oven has
cooled, replace the assemblies and retaining
screws.
1 Guide tile rear of tile shelf slide assembly into
the bottom rear bracket.
Guide tile top rear of tile shelf slide assembly
into the top "U"-shaped bracket.
Lift up tile push rod so that it rests on tile
ledge of the side support of the assembly.
Reattach tile assembly securely to tile oven
with the retaining screw. Repeat for the other
side of the oven.
Lift up and off
I
I
Bottom
bracket
Pull the entire
assembly out.
Push
rod
