XLogic Channel Owner's Manual
Appendix E – Physical Specification *
Depth:
Height:
Width:
Weight:
Power:
Boxed size:
Boxed weight:
* All weights and dimensions are approximate
Appendix F – Environmental Specification
Temperature
Relative Humidity
Vibration
Shock
Altitude
Page 24
325mm/12.8 inches not including heatsink
365mm/14.3 inches including heatsink
400mm/15.75 inches including connectors
44.5mm/1.75 inches (1 RU)
480mm/19 inches
4.1kg/9 pounds
22 Watts/30 VA
520mm x 520mm x 182mm (20.5" x 20.5" x 7.2")
6.4kg (14 pounds)
Operating:
Non-operating:
Max. Gradient:
Operating:
Non-operating:
Max. wet bulb:
Operating:
Non-operating, power off:
Operating:
Non-operating:
Operating:
Non-operating:
5 to 30 Deg. C
–20 to 50 Deg. C
15 Deg. C/Hour
20 to 80 %
5 to 90 %
29 Deg. C (non-condensing)
< 0.2 G (3 - 100Hz.)
< 0.4 G (3 - 100Hz.)
< 2 G (10mSec. Max.)
< 10 G (10mSec. Max.)
0 to 3000m (above sea level)
0 to 12000m
