Appendix A – Internal Links and Fuses
Fuses (Mains Inlet)
The mains inlet contains a single 1 amp 1.25" time delay fuse (SSL Part No. 35FJJ310). To change it disconnect the
mains inlet, then using a small screwdriver prise open the mains selector cover. This contains the fuse. Test and
replace with the same type and value if necessary.
Internal Fuses
The internal power rails are also individually fused. These fuses should only be changed by suitably experienced
staff. They are listed below:
Fuses (629610X2 Power Regulator Card)
+48V FS1 - 500mA wire ended (SSL part No. 35F5E250)
Fuses (629601X1 Main Card)
–18V FS1 - 3 amp wire ended (SSL part No. 35F5E330)
–15V FS2 - 3 amp wire ended (SSL part No. 35F5E330)
+15V FS3 - 3 amp wire ended (SSL part No. 35F5E330)
+18V FS4 - 3 amp wire ended (SSL part No. 35F5E330)
+5V FS5 - 3 amp wire ended (SSL part No. 35F5E330)
Links
LK1 Solder link. Links digital and analogue 0V. Do not remove.
LK2 Links chassis and analogue 0V. Normally fitted. Remove to increase impedance to 10Ω.
