Channel Instrument Input
Signal applied to Channel Instrument Input and measured at Output. Pad switched out and Input Gain control
set to +6dB.
Gain
Input Impedance
Output Headroom
THD + Noise
(-10dBu applied, +30dB gain)
Frequency Response
Equivalent Input Noise
(Input terminated with 150Ω)
Channel Output
Output is fully balanced and floating, and incorporates SSL's cable compensating output design, allowing it to
drive long cable runs without degrading the frequency response.
Gain
Output Impedance:
Variable from +6dB to +72dB in 6dB steps
Independently switchable 18dB Pad
1MΩ
> +26dBu at onset of clipping
< 0.003% at 1kHz
< 0.005% at 10kHz
+0.05dB/-0.1dB from 20Hz to 20kHz
–3dB at 200kHz
< –70dBu at +40dB gain
< –89dBu at +20dB gain
Continuously variable from -20dB to +20dB with indent at 0dB position
< 40Ω
