Appendix B – Connector Details
All XLR Inputs and Outputs
Location: Front and Rear Panels
Conn' Type: XLR Female
Pin Description
1 Chassis
2 Audio +ve
3 Audio -ve
Instrument Input
Location: Front Panel
Conn' Type:
Mono 1/4" Jack Socket
Pin Description
Tip
Guitar Input
Sleeve Chassis
Dynamics Link
Location: Rear Panel
Conn' Type: Stereo 1/4" Jack Socket
Pin Description
Tip
Link Bus*
Ring
Link Bus*
Sleeve 0V
*Note that tip and ring are linked to allow use of
mono jacks
