5.0 Signal Routing

Channel Processing Order
There are two switches that control the order of the signal processing elements. These are Filters to INPUT and
Dynamics PRE EQ. The table below shows the effect of these:
Switch 1 Switch 2
Filters to
'INPUT'
Dynamics
'PRE EQ'
Filters to Dynamics
'INPUT' 'PRE EQ'
Side Chain Processing Order (KEY switch released)
The EQ and filter sections can be assigned to the dynamics side chain using the DYN S/CH switches in the
respective sections. The table below shows the sidechain source and processing for the various combinations of
these:
Switch 1 Switch 2
EQ to
'DYN S/C '
Filters to
'DYN S/C '
EQ to Filters to
'DYN S/C ' 'DYN S/C '
Side Chain Processing Order (KEY switch in)
Finally the side chain can be fed from the KEY input on the rear of the unit by selecting KEY. The table below
shows the sidechain source and processing for the various combinations of DYN S/CH switches:
Switch 1 Switch 2
EQ to
'DYN S/C '
Filters to
'DYN S/C '
EQ to Filters to
'DYN S/C ' 'DYN S/C '
Processing Order
Equaliser Filters
Filters Equaliser
Dynamics Equaliser
Filters Dynamics
Side chain
Side chain processing order
source
Dynamics
Input
Dynamics
Equaliser
Input
Dynamics
Filters
Input
Dynamics
Equaliser
Input
Side chain processing order
KEY Input
KEY Input Equaliser
KEY Input Filters
KEY Input Equaliser
Dynamics
Dynamics
Filters
Equaliser
Filters
Filters
Signal Routing
Page 13
