Summary of Contents for HAMPTON BAY Farmington

  • Page 1 ELEMENTALS by Hampton Bay ® Farmington 52" Ceiling Fan Owner’s Manual Farmington Ventilador de Techo de 1.32 m Manual del Propietario...
  • Page 2 Farmington by Hampton Bay...
  • Page 3 15-Year Motor Warranty The retailer warrants the fan motor to be free from defects in workmanship and material present Date Purchased at time of shipment from the factory for a period of fifteen years after the date of purchase by the original purchaser.
  • Page 4: Table Of Contents

    Safety Rules............................Unpacking Your Fan .......................... Installing Your Fan ..........................Operating Your Fan..........................Care of Your Fan ..........................Troubleshooting ..........................Specifications ..........................Table of Contents...
  • Page 5: Safety Rules

    8. Avoid placing objects in the path of the blades. 1. To reduce the risk of electric shock, insure electricity has been turned off at the circuit breaker or fuse box before beginning. 9. To avoid personal injury or damage to the fan and other items, be cautious when working around or cleaning the fan.
  • Page 6: Unpacking Your Fan 2

    Unpack your fan and check the contents. You should have the following items: 8. Loose parts bag containing: a. Electrical hardware 1. Set of blades (5) 5. Blade arms assembly (5) ( 3 plastic wire connectors) 2. Canopy assembly 6. Pull chain and fob b.
  • Page 7: Installing Your Fan

    Figure 4 Figure 2 To hang your fan where there is an existing fixture but no ceiling joist, you may need an installation hanger bar as shown in Figure 4 (available at your Hampton Bay Retailer). 3. Installing Your Fan...
  • Page 8: Hanging The Fan

    Hanging the Fan 3. Pass the 120-volt supply wires through the center hole in the ceiling hanger bracket as shown in Fig. 6. Ceiling REMEMBER to turn off the power. Follow the mounting steps below to hang your fan properly. NOTE: bracket 4.
  • Page 9 8. Hang the fan on the hook of the hanger FLUSHMOUNT INSTALLATION bracket. Be certain that the canopy is fully Motor wires locked into hook as shown in Fig. 11. This 1. Remove the decorative canopy cover from Ball/downrod will allow you to make the electrical the canopy.
  • Page 10 Step 1 Connect the fan supply (black) wire SUPPLY CIRCUIT and light supply (blue) wire to the black Hook household supply wire as shown in Figure 12. Ground Conductor Step 2. Connect the neutral fan (white) wire to the white neutral household wire. Outlet Box Step 3 Connect the two green fan ground Green...
  • Page 11 Finishing the Outlet Outlet Installation Hanger Hanger STANDARD CEILING INSTALLATION bracket Screws bracket Screws Canopy Slide canopy up to the ceiling as shown in Canopy Figure 13. Make sure you place the wires Ceiling ring safely into the outlet box. Secure the canopy to canopy the hanger bracket with the four screws with Canopy...
  • Page 12 Attaching the Fan WARNING Blades TO REDUCE THE RISK OF PERSONAL INJURY, DO NOT BEND THE BLADE HOLDERS WHILE INSTALLING, BALANCING THE BLADES, OR CLEANING THE FAN. DO CAUTION NOT INSERT FOREIGN OBJECTS BETWEEN Remove 5 rubber packing mounts from ROTATING FAN BLADES.
  • Page 13: Operating Your Fan

    The slide switch controls directions: forward NOTE (switch down ) or reverse (switch up ). WAIT FOR FAN TO STOP BEFORE CHANGING THE SETTING OF THE SLIDE Warm weather - (Forward) A downward air SWITCH. flow creates a cooling effect as shown in Turn on the power and check the operation of Figure 18.
  • Page 14: Care Of Your Fan 10

    Here are some suggestions to help you maintain 3. You can apply a light coat of furniture your fan polish to the wood blades for additional protection and enhanced beauty. Cover Touching 1.Because of the fan's natural movement, some small scratches with a light application of ceiling connections may become loose.
  • Page 15: Troubleshooting

    Problem Solution Fan will not start. 1. Check circuit fuses or breakers. 2. Check line wire connections to the fan and switch wire connections in the switch housing. CAUTION: Make sure main power is off. Fan sounds noisy. 1. Make sure all motor housing screws are snug. 2.
  • Page 16: Specifications 12

    Volts Fan Size Speed Amps Watts N.W. G.W. C.F. 0.19 1822 6.85 kgs 7.66 kgs 1.57' 52" (15.08 lbs) (16.87 lbs) Medium 0.34 3534 (1.32 m) High 0.48 5311 These are approximate measures. Distributed by Home Depot U.S.A., Inc. 2455 Paces Ferry Rd. N.W. Atlanta, Georgia 30339 Specifications 12.
