Grizzly H8246 Instructions

For questions or help with this product contact Tech Support at (570) 546-9663 or techsupport@grizzly.com
to reduce risk of serious burns, electrocu-
tion or death when installing this switch:
• only use this switch to replace an exist-
ing component switch that has the same
physical configuration and equivalent
electrical specifications/ratings.
• Installation must only be performed by an
electrician or qualified service personnel,
and all applicable electrical codes must
be adhered to.
• Turn off and completely disconnect all
power sources to the component before
installing the switch.
• Only install this switch on the "hot" wires.
do not install it on the neutral or ground
wires. otherwise, the component could
still be receiving live current even when
the switch is turned OFF.
• Do not use this switch in wet or damp
locations, or near explosive fumes or
flammable liquids. it is not sealed or rated
for these environments.
• Make sure there is a verified compo-
nent ground on the circuit this switch is
installed.
Warning: no portion of this instrUCtion shEEt may bE rEprodUCEd in any shapE
or form WithoUt thE WrittEn approval of grizzly indUstrial, inC.
Copyright © ApriL, 2011 By grizzLy industriAL, inC.
#ts13926 printed in ChinA
modEl h8246
WidE singlE mini
on/off sWitCh
instrUCtions
figure 1. Model h8246.
introduction
the Model h8246 features a wide single on/oFF
toggle switch and fits into a
hole.
specifications
rated Voltage ..................................... 125V/250V
rated Current ..................................................6A
⁄ " x ⁄ " rectangular
3 7
4 8
