Grizzly H8242 Instructions

For questions or help with this product contact Tech Support at (570) 546-9663 or techsupport@grizzly.com
To reduce risk of serious burns, electrocu-
tion or death when installing this switch:
• Only use this switch to replace an existing
machine switch that has the same physi-
cal configuration and equivalent electrical
specifications/ratings.
• Installation must only be performed by an
electrician or qualified service personnel,
and all applicable electrical codes must
be adhered to.
• Turn off and completely disconnect all
power sources to the machine before
installing the switch.
• Do not use this switch in wet or damp
locations, or near explosive fumes or
flammable liquids. It is not sealed or rated
for these environments.
• Make sure there is a verified machine
ground on the circuit this switch is
installed.
Copyright © FEBrUAry, 2011 By grizzly indUstriAl, inC., rEVisEd April, 2011 (ts)
WARNINg: NO PORTION OF THIS INSTRUCTION SHEET MAy bE REPRODUCED IN ANy SHAPE
OR FORM WITHOUT THE WRITTEN APPROVAL OF gRIzzLy INDUSTRIAL, INC.
Figure 1. h8242 on/oFF paddle switch.
Introduction
the Model h8242 features a recessed on ( | )
button that can be disabled with a padlock and a
large oFF paddle that ensures fast shut off. the
switch assembly will mount on a standard electri-
cal box, or over a 1" x 2" opening.

Specifications

rated hp ..................................................... 2 hp
rated Voltage ..................................... 220V/240V
rated Current ................................................ 16A
padlock shaft size .........................................
#ts13814 printEd in ChinA
MODEL H8242
220V/240V ON/OFF
PADDLE SWITCH
INSTRUCTIONS
⁄ "
3
16
