Grizzly H8243 Instructions

For questions or help with this product contact Tech Support at (570) 546-9663 or techsupport@grizzly.com
to reduce risk of serious burns, electrocu-
tion or death when installing this switch:
• only use this switch to replace an existing
machine switch that has the same physi-
cal configuration and equivalent electrical
specifications/ratings.
• Installation must only be performed by an
electrician or qualified service personnel,
and all applicable electrical codes must
be adhered to.
• Turn off and completely disconnect all
power sources to the machine before
installing the switch.
• Do not use this switch in wet or damp
locations, or near explosive fumes or
flammable liquids. it is not sealed or rated
for these environments.
• Make sure there is a verified machine
ground on the circuit this switch is
installed.
Copyright © FEBrUAry, 2011 By grizzly indUstriAl, inC., rEVisEd April, 2011 (ts)
Warning: no portion of this instrUCtion shEEt may bE rEprodUCEd in any shapE
or form WithoUt thE WrittEn approval of grizzly indUstrial, inC.
figure 1. h8243 on/oFF paddle switch.
introduction
the Model h8243 features a recessed stArt
button that can be disabled with a padlock and a
large stop paddle that ensures fast shut off. the
switch assembly mounts on a standard electrical
box.

specifications

rated hp @ 120V ....................................... 2 hp
rated hp @ 240V ....................................... 3 hp
rated Voltage range ......................... 120V/240V
rated Current @ 125V ..................................35A
rated Current @ 250V .................................. 20A
resistive rating .................................... 600V/15A
padlock shaft size .........................................
#ts13815 printEd in ChinA
modEl h8243
120v/240v on/off
paddlE sWitCh
instrUCtions
⁄ "
3
16
