TOUCH-SCREEN WEATHER STATION MODEL
1
Shipping Contents
The shipping contents of the touch-screen weather station WS-
3510 include the touch-screen weather station, a remote
temperature/humidity sensor, the respective connecting cables,
an AC adapter and the PC software package on CD-ROM.
2
Connections
The use of the direct cable connection between the touch-screen
weather station and remote temperature/humidity sensor depends on
the chosen operating mode (see Item 3 Power Supply).
3
Power Supply
Depending on the type of data transmission from remote tempera-
ture/humidity sensor to touch-screen weather station, the units can be
supplied with power in the following possible combinations:
•
With cable connection or 433 MHz wireless transmission: touch-
screen weather station batteries, remote temperature/humidity
sensor batteries.
•
With 433 MHz wireless transmission: touch-screen weather station
AC adapter, remote temperature/humidity sensor batteries.
•
With cable connection: Both units supplied by AC adapter.
The last mentioned cable connection avoids battery wear-out and
allows data transmission less prone to interferences.
4
Putting into Operation
For transmission security, first the remote temperature/humidity sensor
and in immediate after the touch-screen weather station must be put
into operation by power being applied to it.
By doing this full scale operation of the total system of the touch-screen
weather station is ensured.
WS-3510
QUICK OPERATION GUIDE
5
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for La Crosse Technology WS-3510
Summary of Contents for La Crosse Technology WS-3510
- Page 1 TOUCH-SCREEN WEATHER STATION MODEL WS-3510 QUICK OPERATION GUIDE Shipping Contents The shipping contents of the touch-screen weather station WS- 3510 include the touch-screen weather station, a remote temperature/humidity sensor, the respective connecting cables, an AC adapter and the PC software package on CD-ROM.
-
Page 2: System Start
It is beneficial to tentatively put the system into operation in close proximity (e. g. on a table) in order to ensure correct function in the configuration it is intended to be used. System Start After inserting the batteries or respectively connecting the AC adapter the LCD of the touch-screen weather station will for a few seconds display all possible segments. - Page 3 Setting Up • All settings of the touch-screen weather station are performed by means of menu steps in the text section of the touch-screen weather station (last two lines on the lower part of the LCD). This menu for basic settings and basic displays is started by slightly touching (not pressing!) the center of the text display during normal display mode.
- Page 4 And further utilization of the PC program refers to the "Help" file (opened by clicking the Ques- tion mark button in menu bar) of the Heavy Weather program. (The Wind and Rain measurements are not applicable to the model WS-3510.)
- Page 5 TOUCH-SCREEN WEATHER STATION MODEL WS-3512 Operation Manual...
-
Page 6: Table Of Contents
Table of Contents 1 ....General 2 ....Important Touch-screen Operating Notes 3 ....Putting into Operation 3.1.... Wiring the System 3.2.... Power Supply 3.2.1 ..Batteries 3.2.2 ..AC Adapter 3.2.3 ..Cable Connection 3.3.... System Start 3.4.... Placement 4 ....Setting Up 5 .... -
Page 7: General
General Important Note: Before inserting batteries please carefully read the entire operation manual. The shipping contents of the touch-screen weather station WS-3512 include the touch-screen weather station, a remote temperature/humidity sensor, the respective connecting cables, an AC adapter and the PC software package on CD- ROM. -
Page 8: Putting Into Operation
Putting into Operation It first must be decided whether battery or AC (using the included adaptor) power will be used to operate the system. Both methods allow the connection of remote temperature/humidity sensor and touch-screen weather station by cable or 433 MHz wireless signal. -
Page 9: Power Supply
-The flexibility of 433 MHz wireless transmission is not needed. -Data transmission absolutely free of any environmental interference is wanted. Power Supply Power to the touch-screen weather station can be supplied by batteries or the included AC adapter. 3.2.1 Batteries: First insert two AA 1.5 V batteries into the battery compartment of the remote temperature/humidity sensor. -
Page 10: Placement
After powering up both the remote temperature/humidity sensor and touch-screen weather station the LCD of the touch- screen weather station will for a few seconds display all possible segments (to ensure all parts of the display can be seen). Immediately after this the unit will enter the check mode phase in which for about 15 minutes all measured and received weather data be cycled through, updated and displayed. - Page 11 WWVB Radio-Controlled Clock (RCC) → ON/OFF. In setting “OFF“ the clock is operating as a normal Quartz clock (Default RCC ON). 12/24-hour Time Display Format (Default 12-h Format). Units • Temperature Display (Temp) in °F or °C (Default °F). • Air Pressure (Press) in inHg (inches of mercury –...
-
Page 12: Display Of Stored Min/Max Values And Alarm Value Settings
Default Settings (Factory Reset) → Allows a reset of all weather data from the non-volatile buffer memory (EEPROM) and reset of all set and/or stored values to the factory settings set prior to shipment → Acknowledge with ٭CONFIRM.٭ Note: It will take about 5 minutes for the factory reset process. During this period, the text “Factory Reset In Progress” will be shown. -
Page 13: Radio Controlled Wwvb Clock
Because of the constant access to the opposite menu items, ٭MINMAX ٭and ٭ALARMS ,٭it is possible at any time to toggle between the MIN/MAX and ALARMS value displays. Any action can immediately be terminated through ٭EXIT.٭ Radio-controlled WWVB Clock The radio-controlled WWVB clock is controlled by the radio signal of the WWVB time code sensor and will thus set time and date automatically. -
Page 14: Weather Tendency
Press ٭ALARM ٭in the menu section (last two lines on the LCD). Set hours and minutes of the wake-up time. Leave the mode with ٭EXIT.٭ Note: The wake-up alarm is activated/deactivated by twice touching the TIME section. Here the alarm symbol (((•))) will •... - Page 15 Indoor Humidity (Indoor Humidity) • Outdoor Temperature (Outdoor Temp), Dew Point • Outdoor Humidity (Outdoor Humidity) • Important Note! Since the operating procedures and settings are similar for all steps to be carried out on the touch-screen weather station for the above functions, the procedure shall be explained only once by means of the following example “Air Pressure”.
-
Page 16: El Backlight
Proceed with ٭ON/OFF.٭ Activate or deactivate the alarm with ٭ON ٭or ٭OFF.٭ Terminate with ٭EXIT.٭ Note: Activation or deactivation of the alarm (Display or deletion of the (((•))) symbol) only pertains to the presently displayed value. End of Example Note: Twice touching the PRESSURE section toggles the displays of the Relative (rel) and Absolute (abs) air pressure. -
Page 17: Pc Connection
For further details to the subject “PC Connection“ and Program utilisation, please see the "Help" File (under the Question mark button in menu bar) of the Heavy Weather Program. (The Wind and Rain measurements are not applicable to the model WS-3510.) Technical Data 13.1... -
Page 18: Data Transmission By 433 Mhz Signal
Transmission Range in Open Field:..330 feet max (100 meters) Measuring Intervals Outdoor Data: ..every 128 seconds Temperature Range:……………………-40°F to +139.8° F (-40 °C to +59.9 °C) (Display “OFL” if outside this range) Resolution: ...........0.2°F (0.1 °C) Measuring Range Rel. Humidity: ..1% to 99% Resolution: ...........1% 13.2 Data Transmission by 433 MHz Wireless Signal:... -
Page 19: Warranty Information
Warranty service can only be performed by a La Crosse Technology, Ltd authorized service center. The original dated bill of sale must be presented upon request as proof of purchase to La Crosse Technology, Ltd or La Crosse Technology, Ltd’s authorized service center.
