World Time Center
Introduction
Congratulations on purchasing this state-of-the-art World Time Center as an example of superior design and
engineering. Providing radio controlled time, indoor temperature and humidity displays, outdoor temperature, this unit will
never keep you guessing on time, date or current and future weather conditions. Operation of this product is simple and
straightforward. By reading this operating manual, the user will however receive a better understanding of the WorldTime
Center together with the optimum benefit of all its features.
World Time Center
LCD1
LCD2
LCD3
SET-Key
WORLDTIME-Key
TIMEZONE-Key
Outdoor temperature sensor
LCD display
Features
World Time Center
•
4 digits showing Hour and Minute in the main display
•
WWVB time signal radio-controlled clock with manual time display
•
12/24 hour display
•
Time zone selectable
•
World time display with specific place represented by 3 sucessive characters
•
Calendar display
•
Display of weekday (8 languages to choose from)
•
Display of current indoor temperature
•
Display of current indoor relative humidity
•
Three weather icons for weather forecasting
•
Weather tendency indicators
•
°C or °F temperature display selectable
•
LCD contrast changeable to 8 different tones
•
Low battery indicator
•
Wall Mounting
Hanging Hole
Battery cover
+ -Key
HYGRO-Key
Holder
Outdoor temperature sensor
•
Remote transmission of outdoor temperature via 433MHz to base World Time Center.
•
LCD display showing current outdoor temperature in Fahrenheit (ºF)
•
Shower proof casing
•
Wall mounting case
Getting started
Remove all parts from the packaging and place onto a table in front of you. Ensure that the following parts are included:
1.
World Time Center (main unit)
2.
Outdoor temperature sensor
3.
Instruction manual
If any one of the above mentioned parts is missing please contact your supplier.
Please follow all further explanations and descriptions in this manual in order to ensure that your World Time
Center and Outdoor temperature sensor work correctly.
Important Note:
For all users wanting to get additional informations on the function of the World Time Center there is an
alphabetically sorted subject index at the end of this manual offering a number of technical and functional
explanations. For use and operation of this product however the knowledge of this index is not necessary.
Putting into Operation
Basic Setup
Battery
Compartment
1.
Open the battery cover of the World Time Center and - checking the correct polarities –
insert 3 x AA, IEC LR6 1.5V batteries into the battery compartment as indicated above and replace the cover.
Battery
compartment
2.
Unscrew the screw on the back of the Outdoor temperature sensor compartment and remove the cover.
3.
Insert the 2 x AAA, IEC LR3, 1.5V batteries observing correct polarity.
4.
Replace battery cover on unit and seal by re-screwing
5.
When replacing the battery covers, ensure that the batteries do not spring free from the contacts.
6.
Your World Time Center and Outdoor temperature sensor are now operational.
Reset
Battery Cover
Battery cover
Advertisement
Table of Contents
Related Manuals for La Crosse Technology WS-7098U
Summary of Contents for La Crosse Technology WS-7098U
- Page 1 Outdoor temperature sensor • Remote transmission of outdoor temperature via 433MHz to base World Time Center. World Time Center • LCD display showing current outdoor temperature in Fahrenheit (ºF) • Shower proof casing • Wall mounting case Introduction Getting started Congratulations on purchasing this state-of-the-art World Time Center as an example of superior design and engineering.
- Page 2 • To reset the World Time Center and the Outdoor temperature sensor, simply take out the batteries from both unit. Wait In normal mode display of radio controlled, highly accurate time of day depending on programming - 12 or 24 hours for at least 30 seconds and repeat the setup procedure above.
- Page 3 WORLDTIME Key 12/24 Hours Setting • Serves the selection of the displays of current date with weekday, worldtime with location or alternating display of both above modes every 5 seconds on LCD 1. After entering the programming mode as described above the 12/24 hours display can be selected on LCD 2 in the following way: TIMEZONE Key The “12h”...
- Page 4 World Time Setting When reception is successful, the WWVB transmission tower icon will start flashing in the upper center of LCD 2 as a sign that the signal has been located and is about to be received. Once the signal has been locked, the WWVB tower icon will stay fixed on the LCD and the received time will then update and correct the manually set time.
- Page 5 • • Avoid placing the World Time Center where it can be exposed to sudden changes in temperature, i.e. direct The manufacturer and supplier cannot accept any responsibility for any incorrect readings and any consequences sunlight, extreme cold and wet/moist conditions since the design of this product is for indoor use only. This will help that occur should any inaccurate reading take place.
- Page 6 La Crosse Technology, Ltd or La Crosse Technology, Ltd’s authorized service center. La Crosse Technology, Ltd will repair or replace this product, at our option and at no charge as stipulated herein, with new or reconditioned parts or products if found to be defective during the limited warranty period specified above. All replaced parts and products become the property of La Crosse Technology, Ltd and must be returned to La Crosse Technology, Ltd.
- Page 7 World Time Center Operating Manual Canada Mountain Time (-7h GMT) Pacific Time Central Time (-8h GMT) (-6h GMT) Eastern Time (-5h GMT) United States Mexico THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS: THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE, AND THIS DEVICE MUST ACCEPT INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION.
