FireplaceXtrordinair 44 DV XXL EF Manual

Built-in direct vent fireplace

Hide thumbs Also See for 44 DV XXL EF:

Owner's manual (58 pages)

Table Of Contents

Table of Contents

Quick Links

Need help?

Do you have a question about the 44 DV XXL EF and is the answer not in the manual?

Questions and answers

Summary of Contents for FireplaceXtrordinair 44 DV XXL EF

Page 1 Mobile Homes, CAN/CSA Z240 MH. This appliance is only for use with the type(s) of gas indicated on the rating plate. A conversion kit is supplied with the appliance. 44 DV XXL EF Manual Installer: After installation give this manual to the home-owner and explain operation of this heater.
Page 2: Introduction & Important Information
Today, and Save Your Bill of S a l e . To receive full warranty coverage, you will need to show evidence of 44 DV XXL EF the date you purchased your heater. Do not mail your Bill of Sale to us.
Page 3: Table Of Contents
Safety Precautions Introduction Introduction & Important Information...2 Safety Precautions Safety Precautions ...4 Features & Specifications Features ...6 Installation Options ...6 Heating Specifications ...6 Dimensions...6 Installation Installation Warnings ...7 Packing List...7 Additional Items Required for Installation ...7 Installation Overview ...8 Recommended Installation Procedure ...8 Fireplace Placement Requirements...9 Minimum Framing Dimensions ...9 Clearances ...10...
Page 4: Safety Precautions
Safety Precautions • IF YOU SMELL GAS: * Do not light any appliance * Extinguish any open flame * Do not touch any electrical switch or plug or unplug anything * Open windows and vacate building * Call gas supplier from neighbor's house, if not reached, call fire department •...
Page 5 Safety Precautions • Do not place clothing or other flammable items on or near the heater. Because this heater can be controlled by a thermostat there is a possibility of the heater turning on and igniting any items placed on or near it. •...
Page 6: Features & Specifications
Features and Specifications Features: Works During Power Outages (millivolt system) High Efficiency Optional Thermostat or Remote Control Realistic "Wood Fire" Look Two Quiet Blowers for Effective Heat Distribution Convenient Operating Controls Variable-Rate Heat Output Low Maintenance Heating Specifications: Approximate Heating Capacity (in square feet)* BTU Input Per Hour (from high to low) BTU Output on High (with blowers on) Efficiency** (with blowers on)
Page 7: Installation
Installation Installation Warnings: Failure to follow all of the requirements may result in property damage, bodily injury, or even death. This heater must be installed by a qualified installer who has gone through a training program for the installation of direct vent gas appliances. This appliance must be installed in accordance with all local codes, if any;...
Page 8: Installation Overview
Installation Installation Overview See "Power Heat Vent" in the optional equipment section. 3-1/2" Min. Drywall Non-combustible facing (see the section "Facing Requirements") See the section "Mantel Requirements" See the section "Hearth Requirements" See the section "Fireplace Placement Requirements" Recommended Installation Procedure Frame the opening for the fireplace.
Page 9: Fireplace Placement Requirements
Installation Fireplace Placement Requirements Minimum Framing Dimensions A 1" clearance is required along the sides and back of the fireplace. The 1" stand-offs on the sides and 10- 1/2" stand-offs on the top of the fireplace are designed to separate the fireplace from the framing members. These stand-offs may contact the framing members but no material may be placed between the stand-offs 5-1/2"...
Page 10: Clearances
Installation Clearances • When installed, walls in front of the fireplace must be a minimum 3-1/2" to the side of the faceplate. • Due to the high temperature, the heater should be located out of traffic and away from furniture and draperies. •...
Page 11: Corner Installations
Installation Corner Installations A typical 45° installation uses the minimum framing dimensions shown in the illustration below (NOTE: all clearances still apply). 19-1/2" 60-3/8" Raised Fireplaces • The fireplace (and hearth, if desired) may be placed on a platform designed to support the fireplace (approximately 300 Lbs.) and vent.
Page 12: Gas Line Requirements
Installation Gas Line Requirements The gas line must be installed in accordance with all local codes, if any; if not, follow ANSI 223.1 and the requirements listed below. The fireplace and gas control valve must be disconnected from the gas supply piping during any pressure testing of that system at test pressures in excess of 1/2 psig.
Page 13: Electrical Connection
Installation Electrical Connection Make sure the household breaker is shut off prior to working on any electrical lines. The appliance, when installed, must be electrically grounded in accordance with local codes or, in the absence of local codes, with the National Electrical Code, or ANSI NFPA. •...
Page 14: Vent Requirements
Installation Vent Requirements The vent must maintain the required clearance to combustible materials to prevent a fire (see “Clearances” below). Do not fill air spaces with insulation. The gas appliance and vent system must be vented directly to the outside of the building, and never be attached to a chimney serving a separate solid fuel or gas-burning appliance.
Page 15: Vent Installation
Installation Vent Installation • In addition to the requirements below, follow the requirements provided with the vent. Vertical Vent Requirements Use a roof flashing and storm collar whenever passing through the roof Use the Simpson ceiling firestop (#1263) whenever passing through a ceiling (or enclosure and at every floor penetration.
Page 16: Approved Vent Configurations
Installation Approved Vent Configurations Restrictor Position • A vent restrictor is built into the appliance to adjust the flow rate of exhaust gases. This ensures proper combustion for all vent configurations. Depending upon the vent configuration, you may be required to adjust the restrictor position.
Page 17: Vertical Term. 0,2 Or 4 45° Offsets
Installation Vertical Terminations with 0, 2, or 4 45° Offsets Offset Length Hor. Offset None 5" 1' Section 2' Section 1' 9" 3' Section 2' 5" 4' Section 3' 2" • The termination must fall within the shaded area shown in the chart. Use the indicated restrictor position. Zero or Two 45°...
Page 18: Horizontal Term. With One Vert. Elbow
Installation Horizontal Terminations with One Vertical Elbow The termination must fall within the shaded area shown in the chart. Use the indicated restrictor position. N O T E : If you are installing this fireplace with a minimum of vent rise, and are experiencing intermittent pilot outages, you may need to install a pilot shield (SKU 250-00028).
Page 19: Horizontal Term. With Three Vert. Elbows
Installation Horizontal Terminations with Three Vertical Elbows The termination must fall within the shaded area shown in the chart. Use the indicated restrictor position. NOTE: • A total of three elbows must be used. • No horizontal elbows may be used (a horizontal elbow is defined as an elbow that directs the vent from a horizontal direction to another horizontal direction).
Page 20: Vertical Term. With Two Elbows
Installation Vertical Terminations with Two Vertical 90° Elbows The termination must fall within the shaded area shown in the chart. Use the indicated restrictor position. 40' (max) 35 feet 30 feet 25 feet 20 feet 15 feet 10 feet (min.) 5 feet 0 feet NOTE:...
Page 21: Vent Termination Requirements
Installation Termination Requirements (see the illustration below) Venting terminals shall not be recessed into a wall or siding. Minimum 9" clearance from any door or window Minimum 12" above any grade, veranda, porch, deck or balcony Minimum 12" from outside corner walls Minimum 12"...
Page 22: Hearth Requirements
Installation Hearth Requirements 6-1/4" Min. 3/4” Max. 15/16” 12” Min. Fireplaces Travis Industries (for qualified installers only) Floor Mounted Fireplaces Do not build the hearth above this ledge. Tile, Marble, Brick, or other Non-Combustible Decorative Trim (may be combustible) 53" Min. Cement Board (required) Raised...
Page 23: Facing Requirements
Installation Facing Requirements NOTE: The combustible area above the facing must not protrude more than 3/4" from the facing. If it does, it is considered a mantel and must meet the mantel requirements listed in this manual. WARNING : Do not use adhesive to secure the cement board or facing. The high temperatures of the fireplace may cause adhesives to emit odors.
Page 24: Face Dimensions
Installation Face Dimensions Modifying the Face Angle for Rectangular Faces If using a rectangular face, adjust the face angles at the top corners of the glass (see illustration below). Remove these four screws from the face angle. Front of Fireplace Straighten the face angle.
Page 25: Fireplace Facing Detail
Installation Fireplace Facing Detail 4 " Do not tuck tile underneath the face on the bottom (there will be a 1/2" air space below the access door). You may do this on the sides and top, but not on the bottom. Make sure these shaded areas are faced over when using the arched face.
Page 26: Facing Example - Facing Under 1" Thick
Installation Facing Example - Facing Under 1” Thick • To achieve a facing that is flush with the drywall to the side of the fireplace, recess the framing directly next to the fireplace. See the illustration below. Top View Fireplace 1"...
Page 27: Facing Example - Facing Over 1" Thick
Installation Facing Example – Facing Over 1” Thick Arched Faces: For facing material over 1" thick (e.g. brick, river rock), install the facing around the perimeter of the set-up face shipped with the fireplace. See the illustration below. Rectangular Faces: For facing material over 1” thick (e.g. brick, river rock), install the facing material with a 1/8” gap to side side of the face and 3/8”...
Page 28: Travis Industries
Installation Mantel Requirements • The combustible area above the facing must not protrude more than 3/4" from the facing. If it does, it is considered a mantel and must meet the mantel requirements listed in this manual. Max. Mantel Depth is 12” See “Minimum Mantel Clearance”...
Page 29: Finalizing The Installation
Finalizing the Installation Remove the glass (and arch covers) following the directions below. Warning: The appliance must be completely cool before removing the glass. Warning: To prevent damage, do not abuse, strike, or slam the glass shut. Note: Attach the arch covers after re-installing the glass. Open the six latches holding the glass frame in place (start with the bottom three) - follow the directions shown to...
Page 30 Finalizing the Installation Glass Frame Removal and Installation (continued) The spring pin can come loose from the latch assembly. This occurs when it is turned 1/4 turn when it is disengaged. Follow the directions below to re-install the spring pin if it becomes loose. NOTE: The spring pins can be installed with the glass frame in place or...
Page 31: Log Installation
Finalizing the Installation If converting this unit to propane, do so now (see the instructions on page 47). Install the rock wool, log set, kibbles, and embers (if using the decorative fireback, install it prior to the log set). Warning: Failure to position the parts in accordance with these diagrams or failure to use only parts specifically approved with this appliance may result in property damage or personal injury.
Page 32 Finalizing the Installation (b) Place the Middle Logs Line up the hole in the left middle log with this pin. After placing the logs, push them backwards to the outside edges contact the rear log Travis Industries (for qualified installers only) Line up the two holes in the right middle log with these bolts (or pins) 4050114...
Page 33 Finalizing the Installation (for qualified installers only) (c) Placing the Front Log Line up the hole in the front log with this bolt (or pin) The front log rests on the right middle log. Travis Industries 4050114 1 0 0 - 0 1 1 4 9...
Page 34 Finalizing the Installation (d) Placing the Twigs Line up the hole in the left twig with this pin. When in position the twigs should look like this. Travis Industries (for qualified installers only) Line up the two holes in the right twig with these pins 4050114 1 0 0 - 0 1 1 4 9...
Page 35: Replace The Glass
Finalizing the Installation We recommend you purge the gas line at this time (with the glass removed). This allows gas to be detected once it enters the firebox, ensuring gas does not build up. Replace the glass (and arch covers when using arched faces - see page 29). Turn on the gas to the fireplace.
Page 36: Explain Operation To Home-Owner
Finalizing the Installation configuration is correct, yet the flames are lifting or ghosting, shut off gas to the fireplace and contact the dealer for information on remedying the problem. This fireplace has been tested at altitudes up to 8,000 feet. In this testing we have found that the fireplace, with its standard orifice, burns correctly with just an air shutter adjustment.
Page 37: Operation
Before You Begin Warning: Read this entire manual before you use your new fireplace (especially the section "Safety Precautions" on pages 4 & 5). Failure to follow the instructions may result in property damage, bodily injury, or even death. Warning: Do not operate appliance with the glass front removed, cracked or broken. Replacement of the glass should be done by a licensed or qualified service person.
Page 38: Starting The Pilot
Starting The Pilot Flame The pilot flame is required to ignite the main burners (it also plays a safety role). It should be left on once lit. It will stay lit unless the gas control valve is turned to "OFF". However, the pilot will go out if the gas is shut off, the propane tank runs out (or low) or if the stove malfunctions.
Page 39: Starting The Fireplace For The First Time
Starting the Fireplace for the First Time Burn the heater at a high setting with the blower off for an extended period (up to 48 hours). This will cure the painted surfaces. Fumes from the paint curing and oil burning off the steel will occur. This is normal. We recommend opening a window to vent the room.
Page 40: Adjusting The Blower Speed
Adjusting the Blower Speed The internal blower helps transfer the heat from the fireplace into the room. It will not turn on until the fireplace is up to temperature (approximately 10 minutes after starting). See the illustration below for instructions on adjusting the blower speed.
Page 41: Maintenance
Maintenance Maintaining Your Fireplace's Appearance Fingerprints or other marks left on the optional plated surface may become etched in place if they are not wiped clean prior to turning the heater on. Clean plated surfaces with denatured alcohol and a soft cloth (make sure the fireplace is cool). Other cleaners may leave a film that may become etched into the plated surface.
Page 42: Troubleshooting Table
Maintenance Troubleshooting Table Problem: Pilot Will Not Light Main Burners Will Not Start Remote Control Does Not Work Thermostat Does Not Work Fireplace Will Not Distribute Heat Pilot Goes Out Once A Month Or More Flames Are Too Blue Flames Are Too Short (Under 6") Thin Layer of Soot Covers the Glass...
Page 43: How This Fireplace Works
Maintenance How this Fireplace Works This fireplace was designed with safety as the primary concern. Many of the components inside this fireplace are for safety purposes. Therefore, only certified gas service technicians should service this fireplace. What Turns the Main Burners On and Off This fireplace uses a millivolt system to control its operation (a millivolt is a very small amount of electricity).
Page 44: Wiring Diagram
Maintenance Wiring Diagram Caution: Label all wires prior to disconnection when servicing controls. Wiring errors can cause improper and dangerous operation. Millivolt Wiring (for gas control valve) 120 Volt Wiring Ground Ground (green) (green) Power In Common Common Molex (white) (white) Connector (black)
Page 45: Safety (Listing) Label
The safety (listing) label is on a plate chained to the gas control valve. A copy of the safety label is shown below. Fireplace Xtrordinair 44DVXXL Vented Gas Fireplace Heater Report No. 028-S-26b-5 Certified for USA Tested to: ANSI Z21.88-2002 “Vented Gas Fireplace Heater” and UL 307b-1995 “Gas Burning Heating Appliances for Manufactured Homes”.
Page 46: Warranty
Limited 7 Year Warranty To register your TRAVIS INDUSTRIES, INC. 7 Year Warranty, complete the enclosed Warranty card and mail it within ten (10) days of the appliance purchase date to: TRAVIS INDUSTRIES, INC., 4800 Harbour Pointe Blvd. SW, Mukilteo, WA 98275. TRAVIS INDUSTRIES, INC. warrants this gas appliance (appliance is defined as the equipment manufactured by Travis Industries, Inc.) to be defect-free in material and workmanship to the original purchaser from the date of purchase as follows: Check with your dealer in advance for any costs to you when arranging a warranty call.
Page 47: Lp Conversion Instructions
Optional Equipment LP Conversion Instructions Install the conversion kit prior to installing the gas line to ensure proper gas use. Remove the glass (see page 29). Remove the logs (if installed - page 31) Remove the burner (see illustration to the right).
Page 48 Optional Equipment Follow the directions below to replace the orifices. Slide the three air shutters all the way to the left. Use a 1/2” open end wrench to unscrew all three orifices. 1/2" Wrench Screw the LP orifice in so the orifice shoulder protrudes 5/16”...
Page 49 Optional Equipment Remove the pilot orifice following the instructions below. Replace with the propane pilot orifice Lift the pilot hood off the pilot assembly. Install the logs and embers. Replace glass and face. Remove the regulator from the front of the gas control valve. Replace with the propane regulator, using the new gasket and screws included with the regulator.
Page 50: Power Heat Duct
Optional Equipment POWER HEAT DUCT The optional heat duct allows the fireplace to transfer heat to separate locations in the home. One or two ducts may be used . Installation should take place prior to installing drywall. Warning: This kit must be installed as specified in these instructions. Do not modify any component. Warning: Use of any external blower other than the Travis Power Heat Duct Blower will void the warranty and listing of this appliance and may create a fire hazard.
Page 51: Wall Or Ceiling Mounting
Optional Equipment Attach the blower box to the framing or floorboards of the home following the instructions below. Wall or Ceiling Mounting Cut a hole between wall framing members for the blower assembly. 16"* 5-1/4" * This blower was designed for framing on 16" centers - construct additional framing if needed.
Page 52 Optional Equipment Attach the starter ring to the fireplace following the directions below (use the most convenient side). Install the air duct. Each section, when joined, must be attached with three screws and duct tape (U.L. 181A-P or equivalent). Secure the duct if it is in an area where it may sag or become dislodged. NOTE: The air duct has a 0”...
Page 53 Optional Equipment Attach the grill (and wall adapter, if necessary). Screws (included with this kit) Phillips Screwdriver WIRING DIAGRAM Warning: All wiring should be done by a qualified electrician and shall be in compliance with local codes and with the current National Electric Code ANSI/NFPA 70 (in the U.S.), or with the current CSC22.1 Canadian Electric Code (in Canada).
Page 54 Optional Equipment Follow the directions below to wire the blower box. Remove the cover from the blower box. Attach the hot (black) and common (white) wires to the leads coming from the wires (use wire nuts). Follow the directions below to wire the rheostat. NOTE: There are two types of junction boxes, use the appropriate junction box for your installation.
Page 55: Modulating Remote Installation
Optional Equipment Run the free wire from the rheostat junction box to the fireplace. Follow the directions below to connect the heat duct circuit to the fireplace. Remove the cover from the fireplace junction box. Note: you may need to loosen this cable clamp to ease removal of the cover plate.
Page 56: Index
Approved Vent Configurations...16 Adjusting the Blower Speed...40 Adjusting the Flame Height ...39 Air Shutter Adjustment...35 Altitude Considerations...14 Blower Control...40 BTU Input...6 BTU Output...6 Cap (see vent termination)...21 Chimney Cap (see vent termination)...21 Chimney Installation (see Vent Requirements)...14 Clearances...10 Condensation on Glass...39 Corner Installation...11 Dimensions...6 Dura-Vent (part numbers)...14...
