Salus CT100 Instruction Manual

salus-tech.
Sales
:
Email: sales@salus-tech.com Tel: 01226 323961
Technical
Email: tech@salus-tech.com Tel: 01226 323961
Salus Controls plc, Salus House, Dodworth Business Park South,
Whinby Road, Dodworth, Barnsley S75 3SP
MAINTENANCE
The CT100 thermostat requires no special
maintenance. Periodically, the outer casing can be
wiped clean using a dry cloth (please DO NOT use
solvents, polishes, detergents or abrasive cleaners,
as these can damage the thermostat).
There are no user serviceable parts within the unit;
any servicing or repairs should only be carried out
by Salus Controls or their appointed agents.
Should the CT100 thermostat fail to function
correctly, check:
•
The CT100 temperature has been set correctly.
•
Heating system time switch or programmer
is switched on.
7 CT100 INSTRUCTION MANUAL
WARRANTY
Salus Controls warrants that this product will be
free from any defect in materials or workmanship,
and shall perform in accordance with its
specification, for a period of two years from the
date of installation. Salus Controls sole liability for
breach of this warranty will be (at its option) to
repair or replace the defective product.
8 CT100 INSTRUCTION MANUAL
PRODUCT SPECIFICATION
Model: CT100
Type: Surface mounted mechanical
thermostat designed for hot water
cylinder or pipe applications.
Dimensions
Height: 105 mm
Width: 45 mm
Depth: 50 mm
Switching
Switching Voltage: 230V AC, 50Hz
Switching Current: 16A resistive, 4A inductive
Contact Type: Single Pole Double Throw (SPDT)
Temperature
Range: 40 ºC to 80 ºC
Environment
Operating Temperature: 0 ºC to + 55 ºC
Storage Temperature: - 20 ºC to + 60 ºC
9 CT100 INSTRUCTION MANUAL
Cylinder / Pipe Thermostat
Instruction Manual
Model No CT100
