ENGLISH
Action Buttons
(A, B, X, Y, BLACK, WHITE)
These buttons are used to perform various actions, depending on the software.
For more details, see the software instruction manual.
Triggers
These buttons are pressed using the index finger and allow variable levels of
action. The function depends on the software being used. Pull the trigger in
completely for full action, or depress slightly for reduced button activity. The
variable triggers add great depth to many games.
Start Button
This button is generally used to make selections in the menus and for pausing the
game. For more details, see the software instruction manual.
Back Button
This is a standard button that allows you to do various tasks, depending on the
software. For more details, see the software instruction manual.
Macro Button
Used for recording a series of commands to a single button (see details under

"Features").

Expansion Bays
There are two expansion bays on the Control Pad Pro. These ports are available
to add specific devices to your controller such as a memory card and headphone
device. Refer to the device instruction manual for further details.
FEATURES
The Control Pad Pro boasts state of the art features and technology to help you
experience games in the best way possible. The product is easy to use and built
to last for countless hours of enjoyment. The Mad Catz Control Pad Pro has the
following features:
3
• Officially licensed for Xbox means guaranteed compatibility.
• 6 action buttons and 2 triggers with over 200 levels of sensitivity each.
• 2 expansion bays for upgrades and game enhancements.
• Intense vibration function that shakes the controller in compatible games.
• Extra-long 9 foot cable lets you sit back from your TV.
• Ergonomic and compact design for maximum comfort.
• A macro feature that lets you program sophisticated moves.

USING THE MACRO FEATURE

Overview
The Control Pad Pro features a powerful macro function that will allow you
to easily activate secret moves in many games. When playing certain games,
especially fighting games, a combination of directional pad and action button
presses execute special moves for more intricate attacks.
The Macro function allows that a series of buttons will execute with the press of a
single button without failure. For example, some special fighting moves will require
detailed and specific button presses, ie. "left, left, right, down, A" which makes
the character activate a special move. This same move can be recorded with the
macro function and be flawlessly activated by pressing a single button, saving you
time and eliminating the risk of incorrect button presses.
Programming Macros
1. Press the Macro Button (macro button illuminates red)
2. Press the button to which the macro is to be assigned (macro button will start
flashing). There are four buttons available to program, BLACK, WHITE, LT, and
RT (see "Layout" for button location).
3. Press the button sequence desired. When a button is pressed the Macro light
will stop flashing until the button is released.
4. When finished, press the Macro button again and the Macro light will stop
flashing and turn OFF. Note: there is a limit of 32 commands. If you reach this
limit the macro light will stop flashing and turn OFF.
ENGLISH
4
