Mad Catz CONTROL PAD PRO User Manual

CONTROL PAD PRO
FOR THE XBOX VIDEO GAME SYSTEM
™
Thank you for purchasing the Mad Catz Control Pad Pro for use with the Xbox
video game system. The Mad Catz Control Pad Pro will help you get the most
out of your Xbox games because it is comfortable and highly responsive to your
commands. This user guide will help you understand how to use your Control Pad
Pro and get the most from the features it has to offer.
The Mad Catz Control Pad Pro is one of the most durable and reliable accessories
you can buy. Be sure to visit www.madcatz.com to register your product and
check out our full line of other quality video game accessories.
TABLE OF CONTENTS

SET-UP

LAYOUT

FEATURES
USING THE MACRO FEATURE
CAUTIONS
TROUBLESHOOTING
TECHNICAL SUPPORT
WARRANTY
SET-UP
IMPORTANT! Before using this product, read the Xbox video game system
instruction manual for safety, health, and other information.
1. Turn the power to your game console OFF, as described in the Xbox owner's
manual.
2. Make sure the break-away connector on the Control Pad Pro cable is
securely connected.
3. Insert the controller into the controller port on the game console, see below.
4. Insert the game disk as described in the Xbox owner's manual.
5. Turn the power to your game console ON and begin play.
1
2
3
4
6
6
6
7
1
LAYOUT
EXPANSION
BAYS
ANALOG
STICKS
D-PAD
BACK
MACRO
BUTTON
Directional Pad
The D-Pad controls the direction in which the character moves. It is also used
for navigating menu screens and is the preferred control for precision directional
macro moves.
Analog Sticks
The two analog sticks each control two axes (X-axis and Y-axis). Different software
titles will allow you to modify the way that the analog sticks react in the games.
The analog stick allows you to move your character with great movement depth.
Analog joysticks offer more variability in motion than the D-pad and are the
preferred method of control for many driving and action games. The left analog
controller is the most commonly used analog joystick for games.
Each analog stick has a button that is activated by pressing down on the stick.
These buttons are used to perform various actions, depending on the software. For
more details, see the software instruction manual.
