GReddy Turbo Kit Installation Manual page 4

1. Parts List
28. Vacuum Hose (Blue) 5∅ x 200mm
29. Rubber Hose
30. Rubber Hose
31. Rubber Hose
32. Silicone Hose
33. Reducer Hose
34. Reducer Hose
35. Hose band
36. Hose band
36. Hose band
38. Hose band
39. Hose band
40. Hose band
41. Gasket Turbo in
42. Gasket Turbo out
43. Gasket Turbine in
44. Gasket Turbine out
45. Gasket Down Pipe
46. Gasket Oil Return Flange Tube
47. Heat Shield
48. Heat Shield
49. Thermo-cloth
50. Zip ties
51. Zip ties 200mm
52. Three-way Vacuum Tee 10∅-6∅-10∅
53. Suction pipe bracket
54. Oil return hose bracket
55. Airinx hose fitting 8∅-M18
56. Intake Air Temperature Grommet
8Ø X 500mm (for Idle controller)
16Ø X 400mm (for Oil return)
19Ø X 190mm (for Blow by)
60Ø x70mm
50Ø – 60Ø
60Ø – 70Ø
8Ø
16Ø
19Ø
50Ø
60Ø
70Ø
Turbine
Down pipe
100mm X 1000mm sheet
150mm
(for Actuator)
Tridon #4
Tridon #10
Tridon #12
Tridon #32
Tridon #36
Tridon #44
Small
1
1
1
1
2
1
1
2
2
2
1
7
1
2
1
1
1
1
1
1
1
4
10
5
1
1
1
1
1
