Page 1: User Manual
USER MANUAL GOLDMUND TELOS 150 Analog Power Amplifier... - Page 2 The guiding principle at Goldmund is to produce a precise sound with the least possible loss of quality through the different stages. Goldmund will never adopt a technology before it is sufficiently developed to satisfy the high quality standards we set.
- Page 3 No connection or manipulation must be done before reading those instructions. Damage of the amplifier may result if the following instructions are not consciously understood and applied. This extremely high quality amplifier pos- sesses new technical features which are a necessity for accurate sound reproduc- tion in the best audio systems.
-
Page 4: Table Of Contents
CONTENTS UNPACKING CHOICE OF AMPLIFIER LOCATION AND COOLING LINE VOLTAGE ADJUSTMENT CONNECTIONS AMPLIFIER CONTROLS SOUND QUALITY OPTIMIZATION SAFETY AND PRECAUTIONS MAINTENANCE TECHNICAL DATA User manual – Telos 150 Analog Power Amplifier... -
Page 5: Unpacking
CHOICE OF AMPLIFIER LOCATION AND COOLING The Goldmund Telos 150 Amplifier, as all the high quality amplifiers, may generate a large amount of heat if driven at high power. It is mandatory to allow a proper cooling of the heat sink. -
Page 6: Line Voltage Adjustment
ATTENTION: On the 220 V position, the sponding to your voltage. Goldmund Telos 150 amplifier will func- tion properly for AC voltages between 200 V Please check the value of the mains line fuse. This fuse is located in the power cord receptacle. -
Page 7: Amplifier Controls
AMPLIFIER CONTROLS On the front plate of the Goldmund Telos 150 Amplifier you will find only one switch: the “POWER” key, used to power the amplifier ON and one power LED. When turned ON the 2 channels are immediately connected and the front panel “POWER” LED lights up. - Page 8 Be patient… MAINS LINE PHASE INVERSION The sonic quality of your Goldmund Telos 150 can be greatly improved if the mains AC line is properly connected. Try to invert the AC plugs of both your amplifiers, using special adapters.
-
Page 9: Safety And Precautions
PROTECTION AGAINST DC ATTENTION: the Goldmund Telos 150 is an The Goldmund Telos 150 is a DC-coupled amplifier without protection. If it is associated with extremely high speed amplifier. a badly designed or defective analog preamplifier (often true for tube preamplifiers and some Any bad ground connection can generate 5 channel processors), the speakers could easily be damaged by the DC. -
Page 10: Technical Data
TECHNICAL DATA POWER • Maximum power: > 300 W RMS (3 Ω). • Maximum voltage: 55 V peak. These values are for both driven channels. FREQUENCY RESPONSE These figures are valid for the amplifier operating with a 200 mV RMS input and a 8 Ω resis- tive load.
