Foxconn 600A01 series User Manual page 11

Onboard 1394 (optional)
Supports hot plug
With rate of transmission up to 400Mbps
Self-configured addressing
Can connect with 2 independent 1394 units synchronously at most, such
as HDD, CD-ROM
Onboard LAN
VIA VT6103L 10/100Mbps Ethernet PHY
LAN interface built-in on board
Onboard Audio
AC' 97 2.2 Specification Compliant
Supports 48KHz of S/PDIF output
Onboard Line-in jack, Microphone jack, Line-out jack
Supports 5.1 channels audio (setting via software)
AGP 8X support
AGP 8X (AGP 3.0) is the VGA interface specification that enabled enhanced
graphics performance with high handwidth speeds up to 2.12 GB/s
Expansion Slots
Five PCI slots
One AGP slot
One CNR slot (optional)
BIOS
Licensed advanced AWARD (Phoenix) BIOS, supports flash ROM, plug-
and-play ready
Supports HDD, CD-ROM, SCSI HDD, LAN or USB device boot up
600A01-FOXCONN-V1.0-HW-en.p65
Chapter 1
600A01 Series User Manual
3
Product Introduction
2004-4-12, 13:29
3
