1
1
Chapter
Thank you for your buying Foxconn's 650/651M02 series mother-
board. This series of motherboard is one of our newest products,
and offers superior performance, reliability and quality, at a
reasonable price. This motherboard adopts the advanced SiS
650GX/ 651+962L/962 chipsets, providing users a computer
platform with a high integration-compatibility-performance price
ratio.
This chapter includes the following information:
Main Features
Motherboard Layout

Advertisement

Table of Contents
loading

Related Manuals for Foxconn 650M02 Series

Summary of Contents for Foxconn 650M02 Series

  • Page 1 Chapter Thank you for your buying Foxconn’s 650/651M02 series mother- board. This series of motherboard is one of our newest products, and offers superior performance, reliability and quality, at a reasonable price. This motherboard adopts the advanced SiS 650GX/ 651+962L/962 chipsets, providing users a computer platform with a high integration-compatibility-performance price ratio.

  • Page 2: Chapter 1 Product Introduction

    Chapter 1 Product Introduction Main Features Size mATX form factor of 9.6” x 8.5” Microprocessor ® ® Supports Intel Pentium 4 Socket 478 (Willamette/Northwood) processors ® ® Supports Intel Celeron Socket 478 (Willamette/Northwood) processors Supports FSB at 400MHz/533MHz (FSB 533MHz Supported on 651M02 only) Supports up to 2.8GHz Socket 478 Northwood processor Chipset 650M02: SiS650GX (North Bridge) + 962L/962 (South Bridge)
  • Page 3 Chapter 1 Product Introduction Onboard IDE Supports up to four independent drives Supports Ultra DMA 133/100/66 Two IDE interfaces can connect with four IDE units, including hard disk and CD-ROM/DVD-ROM etc. Onboard I/O One FDD interface; supports two 3.5” or 5.25” FDDs with 360K/720K/1.2M/ 1.44M/2.88M format One high-speed 16550 COM interface with 16-byte FIFO buffer One infrared interface (optional)
  • Page 4 Chapter 1 Product Introduction Expansion Slots Three PCI slots One AGP slot One CNR slot (optional) Advanced Features PCI 2.2 Specification Compliant Supports Windows 98/2000/ME/XP soft-off Supports Wake-on-LAN 650M02 and 651M02 Series User Manual...
  • Page 5 Chapter 1 Product Introduction Motherboard Layout Note: The above motherboard layout is provided for reference only; please refer to the physical motherboard. 650M02 and 651M02 Series User Manual...
  • Page 6 Chapter 1 Product Introduction 1394 PHY (optional) The RTL8801B is IEEE 1394a 100/200/400 Mbps 2-Port Cable Transceiver/ Arbiter (PHY) Chip. Provides two fully compliant cable ports at 100/200/400 Mbps. ATX 12V connector This power connector connects the 4-pin 12V plug from the ATX 12V power supply.
  • Page 7 Chapter 1 Product Introduction Floppy disk connector This connector accommodates the provided ribbon cable for the floppy disk drive. One side of the connector is slotted to prevent incorrect insertion of the floppy disk cable. IDE connectors These dual-Channel bus master IDE connectors support Ultra DMA 133/ 100/66, PIO Modes 3 &...

  • Page 8: Chapter 2 Installation Instructions

    Chapter 2 Installation Instructions Chapter This chapter introduces the hardware installation process, including the installation of the CPU, memory, power supply, slots, rear panel and pin headers, and the mounting of jumpers. Caution should be exercised during the installation of these modules. Please refer to the motherboard layout prior to any installation and read the contents in this chapter carefully.
  • Page 9 Chapter 2 Installation Instructions Notes: Take note of the following precautions before you install motherboard Components or change any motherboard settings. 1. Unplug the power cord form the wall socket before touching any component. 2. Use a grounded wrist strap or touch a safely grounded object or to a metal object, such as the power supply case, before handling components to avoid damaging them due to static electricity.
  • Page 10 Chapter 2 Installation Instructions This motherboard supports socket 478 CPU with a FSB 400/533 MHz (FSB 533MHz Supported on 651M02 only). Attention: The CPU pins must be properly aligned with the slots in the socket, otherwise the CPU may be damaged. Installation of CPU Follow these steps to install a CPU.
  • Page 11 Chapter 2 Installation Instructions Installation of CPU Fan New technology allows processors to run at higher and higher frequencies. To avoid problems arising from high-speed operation, for example, overheating, you need to install the proper fan. The following procedures are provided for reference only, please refer to your CPU fan user guide to install it.
  • Page 12 Chapter 2 Installation Instructions Attention: 1. Position the fan with the retention mechanism on top of the heatsink. Align and snap the four hooks of the retention mechanism to the holes on each corner of the module base. 2. Make sure that the fan and retention mechanism assembly perfectly fits the heatsink and module base, otherwise you cannot snap the hooks into the holes.
  • Page 13 Chapter 2 Installation Instructions Attention: 1. Push down the locks on the retention mechanism to secure the heatsink and fan to the module base. 2. When secure, the retention locks should point to opposite directions. CPU Qualified Vendor List The following table lists the CPU modules that have been tested and quali- fied for use with this motherboard.
  • Page 14 Chapter 2 Installation Instructions Memory This motherboard includes two 184-pin slots with 2.5 V DDR DIMM, so you can install PC 1600/PC 2100/PC 2700 (PC 2700 supported on 651M02 only) memory module. You must install at least one memory module to ensure normal operation.
  • Page 15 Chapter 2 Installation Instructions Warning : Be sure to unplug the AC power supply before adding or remov- ing expansion cards or other system peripherals, especially the memory devices, otherwise your motherboard or the system memory might be seriously damaged. Memory Qualified Vendor List The following table lists the Memory modules that have been tested and quali- fied for use with this Motherboard.
  • Page 16 Chapter 2 Installation Instructions Vender Type Size Apacer PC2700 (DDR 333) 256M, 512M A-DATA PC2100 (DDR 266) 256M A-DATA PC2700 (DDR 333) 256M Nanya PC2100 (DDR 266) 128M, 256M, 512M Nanya PC2700 (DDR 333) 128M, 256M, 512M Winbond PC2700 (DDR 333) 256M, 512M Note: Make sure to use only the tested and qualified DDR DIMMS...

  • Page 17: Power Supply

    Chapter 2 Installation Instructions Power Supply This motherboard uses an ATX power supply. In order to avoid damaging any devices, make sure that they have been installed properly prior to connecting the power supply. 20-pin ATX power connector: PWR1 PWR1 is the ATX power supply connector. Make sure that the power supply cable and pins are properly aligned with the connector on the motherboard.

  • Page 18: Rear Panel

    Chapter 2 Installation Instructions Rear Panel This motherboard provides the ports as below: 1394 Port Parallel Port (optional) connector (Printer Port) Line-in jack PS/2 Mouse Connector Line-out jack PS/2 Keyboard Microphone Connector jack Serial Port VGA Connector USB 2.0 Port x4 (COM1) PS/2 Mouse Connector This green 6-pin connector is for a PS/2 Mouse.
  • Page 19 Chapter 2 Installation Instructions LAN connector This port allows connection to a Local Area Network (LAN) through a network hub. Line-in jack, Line-out jack, Microphone jack When using a two-Channel sound source, the Line-out jack is used to connect to speakers or headphones;...
  • Page 20 Chapter 2 Installation Instructions Connectors This motherboard includes connectors for FDD, IDE HDD, USB, CPU fan, system fan and others. This motherboard includes a standard FDD connector, supporting 360K, 720K, 1.2M, 1.44M and 2.88M FDDs. FDD connector HDD connectors: PIDE & SIDE These connectors supports the provided UltraDMA 133/100/66 IDE hard disk ribbon cable.
  • Page 21 Chapter 2 Installation Instructions SIDE PIDE Front Panel Connector: FP1 This motherboard includes one connector for connecting the front panel switch and LED indicators. PWR-SW PWR-LED 2 + - 1 + - HD-LED RESET Hard Disk LED Connector (HD-LED) The connector connects to the case’s HDD indicator LED indicating the activity status of IDE hard disk.
  • Page 22 Chapter 2 Installation Instructions IrDA Header: JP15 (optional) This connector supports wireless transmitting and receiving device. Before using this function, configure the settings for IR Address, IR Mode and IR IRQ from the “INTEGRATED PERIPHERALS” section of the CMOS SETUP. IRTX IRRX Empty...
  • Page 23 Chapter 2 Installation Instructions Fan Connectors (CPU_FAN, FAN1) The speed of CPU_FAN and FAN1 can be detected and viewed in “PC Health Status” section of the CMOS SETUP. These fans will be automatically turned off after the system enters suspend mode. CPU_FAN +12V SENSE...
  • Page 24 Chapter 2 Installation Instructions 1394 Header: F_1394 (optional) The 1394 expansion cable can be connected to either the front (provided that the front panel of your chassis is equipped with the appropriate interface) or real panel of the chassis. Empty F_1394 Wake-Up On LAN: WOL Through the Wake-Up On LAN function, a wake event occurring from the net-...
  • Page 25 Chapter 2 Installation Instructions Audio Interface: F_AUDIO The audio interface provides two kinds of audio output choices: the Front Audio, the Rear Audio. Their priority is sequenced from high to low (Front Audio to Rear Audio). If headphones are plugged into the front panel of the chassis (using the Front Audio), then the Line-out (Rear Audio) on the rear panel will not work.
  • Page 26 Chapter 2 Installation Instructions Slots This motherboard includes three 32-bit Master PCI bus slots, one AGP slot, one CNR slot (optional). PCI Slots The expansion cards can be installed in the three PCI slots. When you install or take out such cards, you must make sure that the power plug has been pulled out.

  • Page 27: Installing An Expansion Card

    Chapter 2 Installation Instructions Warning: Note the notches on the card golden fingers to ensure that they fit the AGP slot on your motherboard. Installing an expansion card 1. Before installing the expansion card, read carefully the documentation that came with it and make the necessary hardware settings for the card. 2.
  • Page 28 Chapter 2 Installation Instructions CNR Slot (optional) The motherboard provides this Communication and Networking Riser (CNR) interface which can support audio and modem functions. Mechanically the CNR shares the PCI3 slot, thus when you insert the CNR card, the neighbor- ing PCI3 slot cannot be used.
  • Page 29 Chapter 2 Installation Instructions Jumpers The users can change the jumper settings on this motherboard if needed. This section explains how to use the various functions of this motherboard by chang- ing the jumper settings. Users should read the following contents carefully prior to modifying any jumper settings.
  • Page 30 Chapter 2 Installation Instructions Warning: 1. Disconnect the power cable before adjusting the jumper settings. 2. Do not clear the CMOS while the system is turned on. BIOS-Protection Jumper: FWH_EN If the jumper FWH_EN is set as disable (Pin2 & Pin3), the system BIOS is protected from being attacked by serious virus, such as the CIH virus.

  • Page 31: Starting Up For The First Time

    Chapter 2 Installation Instructions Starting up for the first time 1. After making all the connections, replace the system case cover. 2. Be sure that all switches are off. 3. Turn on the devices in the following order. a. Monitor b.

  • Page 32: Chapter 3 Bios Description

    Chapter 3 BIOS Description Chapter This chapter tells how to change system settings through the BIOS Setup menus. Detailed descriptions of the BIOS parameters are also provided. You have to run the Setup Program when the following cases occur: 1. An error message appears on the screen during the system POST process.

  • Page 33: Enter Bios Setup

    Chapter 3 BIOS Description Enter BIOS Setup The BIOS is the communication bridge between hardware and software, correctly setting up the BIOS parameters is critical to maintain optimal system performance. Power on the computer, when the following message briefly appears at the bottom of the screen during the POST (Power On Self Test), press <Del>...
  • Page 34 Chapter 3 BIOS Description Advanced BIOS Features The advanced system features can be set up through this menu. Advanced Chipset Features The values for the chipset can be changed through this menu, and the system performance can be optimized. Integrated Peripherals All onboard peripherals can be set up through this menu.

  • Page 35: Standard Cmos Features

    Chapter 3 BIOS Description Standard CMOS Features This sub-menu is used to set up the standard CMOS features, such as the date, time, HDD model and so on. Use the arrow keys select the option to set up, and then use the <PgUp> or <PgDn> keys to choose the setting values. Standard CMOS Features Menu Date This option allows you to set the desired date (usually as the current day) with...
  • Page 36 Chapter 3 BIOS Description Award (Phoenix) BIOS can support 3 HDD modes: CHS, LBA and Large or Auto mode. For HDD<528MB For HDD>528MB & supporting LBA (Logical Block Addressing) Large For HDD>528MB but not supporting LBA Auto Recommended mode Drive A/B This option allows you to select the kind of FDD to be installed, including “None”, [360K, 5.25 in], [1.2M, 5.25 in], [720K, 3.5 in], [1.44M, 3.5 in] and [2.88 M, 3.5 in].
  • Page 37 Chapter 3 BIOS Description Memory This is a Display-Only Category, determined by POST (Power On Self Test) of the BIOS. Base Memory The BIOS POST will determine the amount of base (or conventional) memory installed in the system. Extended Memory The BIOS determines how much extended memory is present during the POST.

  • Page 38: Bios Features

    Chapter 3 BIOS Description BIOS Features BIOS Features Menu [SuperBoot] SuperBoot (Default: Disabled) SuperBoot allows system-relevant information to be stored in CMOS upon the first normal start-up of your PC, and the relevant parameters will be restored to help the system start up more quickly on each subsequent start-up. The available setting values are: Disabled and Enabled.

  • Page 39: Advanced Bios Features

    Chapter 3 BIOS Description Advanced BIOS Features Advanced BIOS Features Menu Virus Warning (Default: Disabled) Allows you to choose the VIRUS warning feature for IDE hard disk boot sector protection. If this function is enabled and someone attempt to write data into this area, BIOS will show a warning message on screen and an alarm will beep.
  • Page 40 Chapter 3 BIOS Description First/Second/Third Boot Device (Default: Floppy/HDD-0/CDROM) This option allows you to set the boot device’s sequence. The available setting values are: Floppy, LS120, HDD-0, SCSI, CDROM, HDD-1, HDD-2, HDD-3, ZIP100, USB-FDD, USB-ZIP, USB-CDROM, USB-HDD, LAN and Disabled. Boot Other Device (Default: Enabled) With this function set to enable, the system will to boot from some other devices if the first/second/third boot devices failed.
  • Page 41 Chapter 3 BIOS Description Security Option (Default: Setup) When it is set to “Setup”, a password is required to enter the CMOS Setup screen; When it is set to “System”, a password is required not only to enter CMOS Setup, but also to start up your PC. APIC Mode (Default: Enabled) This option is used to enable or disable APIC functionality.

  • Page 42: Advanced Chipset Features

    Chapter 3 BIOS Description Advanced Chipset Features Advanced Chipset Features Menu Advanced DRAM Control 1 Press enter to set the items about advanced DRAM control 1. Please refer to page 43. Prefetch Caching (Default: Disabled) This option allows you to enable or disable prefetch caching. The available setting values are: Enabled and Disabled.
  • Page 43 Chapter 3 BIOS Description Graphic Window WR Combin (Default: Disabled) (optional) This Item is used to disable or enable Graphic Window Write Combine mode. Advanced DRAM Control 1 Menu System Performance (Default: Normal Mode) This option is used to set system performance mode. The available setting values are: Safe Mode, Normal Mode, Fast Mode, Turbo Mode, Ultra Mode.

  • Page 44: Integrated Peripherals

    Chapter 3 BIOS Description Integrated Peripherals Integrated Peripherals Menu SIS Onchip IDE Device Press enter to set onchip IDE device. Please refer to page 46. SIS Onchip PCI Device Press enter to set onchip PCI device. Please refer to page 47. Onboard SuperIO Device Press enter to set onboard SuperIO device.
  • Page 45 Chapter 3 BIOS Description USB0/1/2/2.0 Access Interface (Default: EDB Bus) (optional) This option is used to set USB0/1/2/2.0 Access Interface. The available set- ting values are: PCI Bus and EDB Bus. MAC Access Interface (Default: EDB Bus) This option is used to set MAC access interface. The available setting values are: PCI Bus and EDB Bus.
  • Page 46 Chapter 3 BIOS Description SIS Onchip IDE Device Menu Internal PCI/IDE (Default: Both) This option is used to set the ports of onboard IDE. The available setting values are: Disabled, Primary, Secondary and Both. IDE Primary/ Secondary Master/Slave PIO (Default: Auto) These four items let you assign which kind of PIO (Programmed Input/Output) is used by IDE devices.
  • Page 47 Chapter 3 BIOS Description SIS OnChip PCI Device Menu SIS USB Controller (Default: Enabled) This option is used to enable or disable SIS USB controller. USB Ports Number (Default: 6 ports) (optional) This option is used to set the USB ports number. USB 2.0 Supports (Default: Enabled) This option is used to enable or disable USB 2.0.
  • Page 48 Chapter 3 BIOS Description Onboard SuperIO Device Menu Onboard FDC Controller (Default: Enabled) This option is used to set whether the onboard FDC controller is enabled. The available setting values are: Disabled and Enabled. Onboard Serial Port1/2 (Default: 3F8/IRQ4 / 2F8/IRQ3) This option is used to assign the I/O address and interrupt request (IRQ) for the onboard serial port 1/2.

  • Page 49: Power Management Setup

    Chapter 3 BIOS Description Power Management Setup Power Management Setup Menu ACPI function (Default: Enabled) ACPI stands for “Advanced Configuration and Power Interface”. ACPI is a standard that defines power and configuration management interfaces be- tween an operating system and the BIOS. In other words, it is a standard that describes how computer components work together to manage system hardware.
  • Page 50 Chapter 3 BIOS Description Video Off Method (Default: DPMS Supported) This option is used to define the video off method. “Blank Screen” mode means that after the computer enters power saving mode, only the monitor will close, however, the vertical and horizontal scanning movement of the screen continues.
  • Page 51 Chapter 3 BIOS Description PM Wake UP Events Menu IRQ [3-7,9-15], NMI (Default: Enabled) This option is used to enable or disable IRQ[3-7,9-15], NMI. IRQ 8 Break Suspend (Default: Disabled) This option is used to enable or disable IRQ8 break suspend. RING Power Up Control (Default: Enabled) If this option is enable, it allows the system to resume from a software power down or power saving mode whenever there is an incoming call to an in-...
  • Page 52 Chapter 3 BIOS Description Month Alarm This option is used to set the timing for the start-up month. The setting values contain 1 - 12 and NA. Day of Month Alarm This option is used to set the timing for the start-up day of the month. The setting values contain 0 - 31.

  • Page 53: Pnp/Pci Configurations

    Chapter 3 BIOS Description PnP/PCI Configurations PnP/PCI Configurations Menu Reset Configuration Data (Default: Disabled) This option is used to set whether the system is permitted to automatically distribute IRQ DMA and I/O addresses when each time the machine is turned on.

  • Page 54: Pc Health Status

    Chapter 3 BIOS Description PC Health Status PC Health Status Shutdown Temperature (Default: Disabled) This option is used to set the system temperature upper limit. When the temperature exceeds the setting value, the motherboard will automatically cut off power to the computer. The setting values are and 60 C/140 F, 65 F, 70...

  • Page 55: Frequency/Voltage Control

    Chapter 3 BIOS Description Frequency/Voltage Control Frequency/Voltage Control Menu CPU Clock Ratio (Default: based on CPU specifications) This option is used to set the ratio of an unlocked CPU. Using different CPU, the setting values are different. Note: This option is invisible for locking frequency CPU. Auto Detect DIMM/PCI Clk (Default: Enabled) This option is used to set whether the clock of an unused DIMM/PCI slot will be disabled to reduce electromagnetic interference.

  • Page 56: Load Fail-Safe Defaults

    Chapter 3 BIOS Description Load Fail-Safe Defaults Press <Enter> to select this option. A dialogue box will pop up that allows you to load the default BIOS settings. Select <Y> and then press <Enter> to load the defaults. Select <N> and press <Enter> to exit without loading. The defaults set by BIOS set the basic system functions in order to ensure system stability.

  • Page 57: Save And Exit Setup

    Chapter 3 BIOS Description If you do not want to set a password, just press <Enter> when prompted to enter a password, and in the screen the following message will appear. If no password is keyed in, any user can enter the system and view/modify the CMOS settings. Password Disabled!!! Press any key to continue …...
  • Page 58 Chapter The utility CD that came with the motherboard contains useful software and several utility drivers that enhance the motherboard features. This chapter includes the following information: Utility CD content Start to install drivers Install IDE Driver Install AGP Driver Install VGA Driver Install Direct X Install USB2.0 Driver...

  • Page 59: Chapter 4 Driver Cd Introduction

    C. Norton Internet Security 2004 3. Browse CD Click here to browse CD content. 4. Homepage Click here to visit Foxconn motherboard homepage. Note: 1. Install the latest patch first if your OS is Windows XP or Win- dows 2000.
  • Page 60 Chapter 4 Driver CD Introduction Start to Install divers Select <Install Driver>, and click to enter the install driver screen. You can select the driver that you want to install and begin the setup steps. Note: The following setup steps are based on Windows XP environment. There may be some differences with other operating systems.
  • Page 61 Chapter 4 Driver CD Introduction Install AGP Driver Click <Install Driver> from the main menu and enter the install driver menu (as shown in fig. 1). Click <AGP Driver> to start the installation. Click here Click here Select this option Select this option Click here Click here...
  • Page 62 Chapter 4 Driver CD Introduction Click here Click here Select this option Click here Click here Install DirectX Click <Install Driver> from the main menu and enter the install driver menu (as shown in fig. 1). Click <DirectX> to start the installation. Click here Click here Select this option...
  • Page 63 Chapter 4 Driver CD Introduction Click here Click here Install USB 2.0 Driver Click <Install Driver> from the main menu and enter the install driver menu (as shown in fig. 1). Click <USB 2.0 Driver> to open the USB 2.0 Installation guide. Please read the guide carefully and select the relevant installation method.
  • Page 64 Chapter 4 Driver CD Introduction Click here Attaching Speakers To perform multichannel audio operation, connect multiple speakers to the system. You should connect the same number of speakers as the audio chan- nels you will select in the software utility. 2-Channel Analog Audio Output The audio connectors on the rear panel already provide 2-Channel analog au- dio output.
  • Page 65 Chapter 4 Driver CD Introduction 4-Channel Analog Audio Output Line-out (Rear channels) Line-out (Front channels) M icrophone Description: Line-in is converted to Line-out under the 4-Channel configuration. 6-Channel Analog Audio Output Line-out (Rear channels) Line-out (Front channels) Line-out (Center and Subwoofer channels) Description: Both Line-in and Microphone are converted to Line-out under the 6-Chan- nel configuration.
  • Page 66 Chapter 4 Driver CD Introduction Digital Audio Output 6CH_Bracket (optional) S/PDIF Cable (optional) Coaxial S/PDIF jack Description: Connect the S/PDIF speakers to the Coaxial S/PDIF jack. Selecting 4- or 6-Channel Setting 1. Click the audio icon from the Windows tray bar at the bottom of the screen.
  • Page 67 Chapter 4 Driver CD Introduction 3. Click the Speaker Configuration tab. Click here 4. The following window appears. Click here 5. Select the multi-Channel operation you prefer from No. of Speakers. 6. Click OK. 650M02 and 651M02 Series User Manual...
  • Page 68 Chapter 4 Driver CD Introduction Testing the Connected Speakers To ensure 4- or 6-Channel audio operation works properly, you may need to test each connected speaker to make sure every speaker works properly. If any speaker fails to sound, then check whether the cable is inserted firmly to the connector or replace the bad speakers with good ones.
  • Page 69 Chapter 4 Driver CD Introduction Click here 4. Click OK. Install LAN Driver Click <Install Driver> from the main menu and enter the install driver menu (as shown in fig. 1). Click <LAN Driver> to start the installation. Click here Click here 650M02 and 651M02 Series User Manual...

  • Page 70: Install Norton Internet Security 2004

    Chapter 4 Driver CD Introduction Install Norton Internet Security 2004 From the main menu, select <Accessories> (as shown in following fig. 1). Click <Norton Internet Security 2004> to start the setup. Click here Click here Click here Click here Click here Click here Note: If your system is Windows 98 or Window ME, please make sure...
  • Page 71 Chapter 4 Driver CD Introduction Chapter This chapter will introduce how to use attached software. This chapter provides the following information: SuperStep SuperLogo SuperUpdate 650M02 and 651M02 Series User Manual...

  • Page 72: Directions For Bundled Software

    4. Simple and easy to operate, with a user-friendly graphics interface. Using SuperStep: System Fan1 Go to Fan System Fan2 speed page speed (optional) CPU Fan Link to Foxconn website speed Exit Program Minimize Window Adjust CPU SuperStep On-Line Help Fan warning criteria About SuperStep...
  • Page 73 Chapter 5 Directions for Bundled Software Adjust voltage warning Go to Voltage page criteria (upper limit) Current voltage readings Reset the warning Adjust voltage Apply the criteria to default warning criteria adjustments settings (lower limit) Go to Temperature page Current CPU Adjust CPU tem- perature warning temperature...
  • Page 74 Chapter 5 Directions for Bundled Software Go to Clock page Current CPU Current AGP Clock Clock Current PCI Clock Adjust the Adjust the CPU FSB CPU Ratio Reset to the default settings Apply the adjustments Note: When CPU overclock is failed, please do use cold boot to restart your computer.
  • Page 75 The best resolution is 136 x 84 for top-right logo and 640 x 480 or 800 x 600 for full screen logo. Using SuperLogo: Go to ROM Info. page Display the Flash Information Link to Foxconn website Exit Program Minimize Window SuperLogo On-Line Help About SuperLogo...
  • Page 76 Chapter 5 Directions for Bundled Software Go to Change Logo page Full screen mode Top-Right mode Follow the Boot without logo Wizard to complete the logo update Go to Update BIOS page Browse a BIN file BIOS image for updating BIOS file location Follow the Wizard to complete the...
  • Page 77 3. Simple and easy to operate, with a user-friendly graphics interface. Using SuperUpdate: Perform the BIOS update Browse BIOS bin file from local HDD from local image Link to Foxconn website Exit Program Minimize Window SuperUpdate On-Line Help About SuperUpdate Backup system BIOS...
  • Page 78 Chapter 5 Directions for Bundled Software Backup BIOS to local image: 1. Click <Backup> to backup current BIOS file. 2. Click <OK> to finish the bakeup process. Update BIOS from local image: 1. Click <Load> to load a new BIOS file. 650M02 and 651M02 Series User Manual...
  • Page 79 Chapter 5 Directions for Bundled Software 2. Click <Update>, the following message will appear. 3. Click <Yes> to backup the current BIOS, then start to update the BIOS. 4. Click <Restart >to finish the update process. 650M02 and 651M02 Series User Manual...
  • Page 80 Chapter 5 Directions for Bundled Software Update BIOS On-line: 1. Click <Liveupdate> to automatically update the BIOS from the internet. 2. Click <Yes> to backup the current BIOS. 650M02 and 651M02 Series User Manual...
  • Page 81 Chapter 5 Directions for Bundled Software 3. Click <OK> to update BIOS. 4. Click <Restart >. 650M02 and 651M02 Series User Manual...

  • Page 82: Chapter 6 Special Bios Functions

    Chapter 6 Special BIOS Functions Chapter This chapter will introduce special functions of BIOS and how to use them in detail. It can further exert the max potential of motherboard to bring you super-value enjoyment. This chapter introduces the following special functions of BIOS: SuperBoot SuperBIOS-Protect 650M02 and 651M02 Series User Manual...
  • Page 83 Chapter 6 Special BIOS Functions SuperBoot SuperBoot technology greatly reduces the long boot process time of computers. A BIOS without SuperBoot has to perform many routines every time when the system starts, such as checking the system core and initializing system peripherals.
  • Page 84 Chapter 6 Special BIOS Functions SuperBIOS-Protect The BIOS of the motherboard is contained inside the Flash ROM. Severe viruses, such as the CIH virus, are so dangerous that they may overwrite the BIOS. If the BIOS has been damaged, the system will be unable to boot. We provide the following solution which protects the system BIOS from being attacked by such viruses.
